ELAR EX TRIFLOOD
User Instructions
5/10
Elation Architectural
©
6122 S. Eastern Ave.
Los Angeles CA. 90040
www.elationlighting.com
ELAR EX TRIFLOOD
Unpacking:
Thank you for purchasing the ELAR EX TRIFLOOD by
Elation Architectural
®
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
fixture for any damage and be sure all accessories necessary to oper-
ate the unit has arrived intact. In the case damage has been found or
parts are missing, please contact our customer support number for
further instructions. Do not return this unit to your dealer without first
contacting customer support.
Introduction:
The ELAR EX TRIFLOOD is part of Elation Architec-
tural
continuing pursuit for creating high quality affordable intelligent
®
fixtures. The ELAR EX TRIFLOOD is a powerful DMX intelligent RGB
LED wash. This wash is light weight and compact which makes it a
great piece for mobile DJ's and clubs. The unit has 4 operating modes;
Auto Run mode, Program mode, RGB mode, and DMX Controlled. This
unit can be used as a stand alone unit or in a master-slave configura-
tion.
Customer Support:
provide set up help and to answer any question should you encounter
problems during your set up or initial operation. You may also visit us
on the web at www.elationlighting.com for any comments or sugges-
tions. Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m.
Pacific Standard Time.
Voice:
Fax:
E-mail:
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
Elation customer support.
©
®
PLEASE recycle the shipping carton when ever possible.
Elation Architectural - www.elationlighting.com - ELAR EX TRIFLOOD User Manual Page 2
. Every ELAR EX TRIFLOOD has been thoroughly
Elation
provides a customer support line, to
©
®
(323) 582-3322
(323) 832-9142
support@elationlighting.com
Introduction
Advertisement
Table of Contents
Related Manuals for Elation Work Light
Summary of Contents for Elation Work Light
- Page 1 ELAR EX TRIFLOOD User Instructions 5/10 ELAR EX TRIFLOOD Unpacking: Elation Architectural tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your fixture for any damage and be sure all accessories necessary to oper- ate the unit has arrived intact.
- Page 2 ELAR EX TRIFLOOD To optimize the performance of this product, please read these operat- ing instructions carefully to familiarize yourself with the basic operations of this unit. These instructions contain important safety information regarding the use and maintenance of this unit. Please keep this manual with the unit, for future reference.
-
Page 3: Power Supply
ELAR EX TRIFLOOD ower Supply: The Elation ELAR EX TRIFLOOD contains an elec- tronic ballast, which will auto sense the voltage when it is plugged into the power source. With the electronic power supply unit you do not need to worry about wall voltage, this unit can be plugged in any- where. - Page 4 ELAR EX TRIFLOOD The ELAR WR IR translater has many differnet functions and gives you complete control of your Elation® Architectural fixtures. To control the your desired fixture you must aim the controller at the front of the fixture and be no more the 30 feet away. BLACkOUT - Pressing this button will blackout the fixture.
- Page 5 ELAR EX TRIFLOOD 3 Channel - DMX Values & Functions Channel Value 1 - 255 1 - 255 1 - 255 ELAR EX TRIFLOOD 4 Channel - DMX Values & Functions Channel Value 1 - 255 1 - 255 1 - 255 MASTER DIMMER 1 - 255 Elation Architectural - www.elationlighting.com - ELAR EX TRIFLOOD User Manual Page 9...
-
Page 6: Master Dimmer
ELAR EX TRIFLOOD 6 Channel - DMX Values & Functions Channel Value 1 - 255 1 - 255 1 - 255 MASTER DIMMER 1 - 255 0 - 15 16 - 255 MACROS & PROGRAMS 0 - 15 16 - 31 32 - 47 48 - 63 64 - 79... -
Page 7: Troubleshooting
ELAR EX TRIFLOOD Due to fog residue, smoke, and dust cleaning the external optical lenses must be carried out periodically to optimize light output. Never open the unit. This unit is sealed at the factory and designed to withstand outside elements. 1. -
Page 8: Specifications
ELAR EX TRIFLOOD Model: ELAR EX TRIFLOOD SPECIFICATIONS: Working Position: Any safe working position Voltage: 90V ~ 240V/60~50Hz LED’s: 15 x 3 Watt Tri LED’s Power Consumption: IP Rating: Beam Angle: 40 Degrees Weight: 9.5lbs./ 4.5Kgs. Dimensions: 7.0” (L) x 12” (W) x 9.5” (H) Colors: RGB Color Mixing DMX Channels:...
