Component-Side Connectors Shown In Figure 20 - Intel BOXD945GCZL Technical Product Specification

Table 18 lists the component-side connectors identified in Figure 20.
Table 18.

Component-side Connectors Shown in Figure 20

Item/callout
from Figure 20 Description
A
Rear chassis fan connector
B
Front panel audio connector
C
Parallel ATA IDE connector
D
Chassis intrusion connector
E
Serial ATA connector 0
F
Serial ATA connector 1
G
Serial ATA connector 2
H
Serial ATA connector 3
I
Front panel USB connector
J
Front panel USB connector
K
Main power connector
L
PCI Express x16 bus add-in card connector
M
PCI Conventional bus add-in card connector 1
N
PCI Conventional bus add-in card connector 2
O
PCI Express x1 bus add-in card connector
P
Diskette drive connector
Q
Front panel IEEE-1394a connector (optional)
R
Front panel IEEE-1394a connector (optional)
S
Front panel connector
T
Front chassis fan connector
U
Auxiliary front panel power LED connector
V
Processor core power connector
W
Processor fan connector
