Eizo FlexScan S2410W User Manual

Eizo nanao user's manual color lcd monitor s2410w

Hide thumbs Also See for FlexScan S2410W:

Setup manual (60 pages)

Brochure & specs (4 pages)

Table of Contents

Quick Links

Summary of Contents for Eizo FlexScan S2410W

Page 1 SAFETY SYMBOLS PRECAUTIONS 1. Introduction 1-1. Features 1-2. Package Contents 1-3. Controls & Connectors 2. CABLE CONNECTION 2-1. Before Connecting 2-2. Connecting the Signal Cable 2-3. Connecting Two PCs to the Monitor 3. ScreenManager 3-1. How to use the ScreenManager 3-2.
Page 2 10. GLOSSARY APPENDIX About TCO'03 (Applicable white) About TCO'99 (Applicable black) FCC Declaration of Conformity Hinweis zur Ergonomie / Recycle Auskunft / Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor...
Page 3: Safety Symbols
Indicates a prohibited action. Indicates to ground for safety. Copyright© 2005 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
Page 4 As an ENERGY STAR® Partner, EIZO NANAO CORPORATION has determined that this product meets the ENERGY STAR guidelines for energy efficiency.
Page 5 PRECAUTIONS IMPORTANT! This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below).
Page 6 Keep small objects or liquids away from the unit. Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet may result in fire, electric shock, or equipment damage. If an object or liquid falls/spills into the cabinet, unplug the unit immediately.
Page 7 Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord.Not doing so may result in fire or electric shock. To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electric shock.
Page 8 Never touch the plug and power cord if it begins to thunder. Touching them may result in electric shock. When attaching an arm stand, please refer to the user's manual of the arm stand and install the unit securely with the enclosed screws. Not doing so may cause the unit to come unattached, which may result in injury or equipment damage.
Page 9: Lcd Panel
Do not block the ventilation slots on the cabinet. Do not place any objects on the ventilation slots. Do not install the unit in a closed space. Do not use the unit laid down or upside down. Blocking the ventilation slots prevents proper airflow and may result in fire, electric shock, or equipment damage.
Page 10 In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The screen may have defective pixels. These pixels may appear as slightly light or dark area on the screen. This is due to the characteristics of the panel itself, and not the product.
Page 11: Package Contents
The utility software "ScreenManager Pro for LCD" (for Windows) which can control the monitor from a PC with a mouse or keyboard is included (refer to the EIZO LCD Utility Disk). The ArcSwing Stand enables to adjust the monitor height and monitor angle freely 1-2.
Page 12: Controls And Connectors
1-3. Controls & Connectors Front (1) ScreenManager® (2) FineContrast Menu (3) Input Signal Selection Switch (SIGNAL) Switch the input signals when connecting 2 PCs. (4) Auto Adjustment Switch (AUTO) (5) Enter Switch (ENTER) (6) Directing Switch (Left, Down, Up, Right) (7) Power Switch (8) Power Indicator Rear...
Page 13 2855 Campus Drive, San Mateo, CA 94403 USA Tel.: 800-650-4242, x3348, Intl: 650-572-2700, x3348 Fax: 650-572-9675 http://www.kensington.com House the cables. Connect the power cord. USB Port upstream is used when using the software EIZO LCD Utility Disk. Making Use of USB Section.
Page 14: Cable Connection
2. CABLE CONNECTION 2-1. Before Connecting Before connecting your monitor to the PC, change the display screen settings in accordance with the charts below. When your computer and display support VESA DDC, the suitable resolution and the refresh rate are set by just plugging your display into the computer without any manual settings.
Page 15: Connecting The Signal Cable
720×400 70Hz 800×600 60Hz 1024×768 60Hz 162 MHz 1280×960 60Hz (Max) 1280×1024 60Hz 1600×1200 60Hz 1680×1050 60Hz 1920×1200 60Hz 2-2. Connecting the Signal Cable Be sure that the power switches of both the PC and the monitor are OFF. 1. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC.
Page 16 Signal Cable (FD-C16 enclosed) Signal Cable (FD-C16 enclosed) + Macintosh Adapter (Optional) Digital Input Signal Cable Signal Cable (FD-C39 enclosed) The monitor is not compatible with a Power Mac G4/G5 ADC (Apple Display Connector). 2. Plug the power cord into the power connector on the rear of the monitor. 3.
Page 17 4. Lead the power cord and signal cable into the cable holder at rear of the monitor. The cables are recommended to lead with slight sag for the smooth motion of the stand and the Portrait/ Landscape display. 5. Adjust the "height", "front and back position" and "angle" of the monitor. Grip both side of the center part of the monitor and move slowly (refer to the right figure.) (1) Adjust the height of the monitor.
Page 18 (3) If necessary, fine adjust the height of the monitor. 6. Turn on the monitor's Power switch and then turn on the PC's power. The monitor's power indicator will light up (blue). If an image does not appear, refer to the Whenever finished, turn off the PC and the monitor.
Page 19: Connecting Two Pcs To The Monitor
2-3. Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-I and the D-Sub mini 15 pin connector on the back of the monitor. Connecting Examples SIGNAL 1 Signal Cable D-Sub (FD-C16 enclosed) (Ex.1) Analog mini 15 Signal Cable...
Page 20 This function is used to select which PC will have priority to control the monitor when utilizing two PCs. The monitor constantly checks the input signals and switches automatically in accordance with the "Input Priority" setting (see table below). Once a priority is set, whenever a change of signal is detected at the selected input, the monitor will switch the input to that signal.
Page 21: How To Use The Screenmanager
3. ScreenManager 3-1. How to use the ScreenManager ScreenManager allows you to adjust screen performance though the main menu and select a FineContrast mode easily. Main Menu and FineContrast Menu cannot be activated at the same time. 1. Entering the ScreenManager Touch the Enter switch once to display the main menu of the ScreenManager.
Page 22: Screenmanager Adjustments And Settings
FineContrast Menu Directly touching the left or right switch allows you to select the best suited mode for screen display from 5 FineContrast modes; Custom, Movie, Picture, Text and sRGB. To exit the menu, touch the Enter switch. 3-2. ScreenManager Adjustments and Settings The following table shows all the ScreenManager's adjustment and setting menus.
Page 23 Menu Settings Power Indicator Reset Information Information English, German, French, Spanish, Italian, Language Swedish and Japanese The adjustable functions on the <Color> menu depend on the selected FineContrast mode. The above table shows the sub menus when the "Custom" mode is selected Due to the inspection on the factory, the usage time may not "0 hour"...
Page 24: Useful Functions
Custom To adjust the color settings according to your preference Movie Animated images Picture Photo or picture image Text Text on word processor or spreadsheet software sRGB To display the screen images based on those original colors (ex. over the Internet) Color Adjustment of the Mode Settings <Brightness>, <Temperature>...
Page 25: Power Indicator Setting
1. Select <Power Indicator> in the ScreenManager <Others> menu. 2. Select "Disable". EIZO Logo Appearing Function When turning on the monitor, the EIZO logo is displayed for a while. If you desire to display or undisplay this logo, use this function. (Default is logo appearing.) [To undisplay] 1.
Page 26: Screen Adjustment
Adjustment 2. Run the "Screen Adjustment Program". Having read the "Readme.txt" file, run the "Screen Adjustment Program" in the enclosed EIZO LCD Utility Disk. Step by step, adjustment is provided by the wizard guide. (If using the Windows, the program can be directly run from the menu screen of the CD-ROM.)
Page 27 pattern to that as shown in the diagram on the following. 3. Adjust by using <Screen> menu in the ScreenManager. (1) Vertical bars appear on the screen Use the <Clock> adjustment. Select the <Clock> and eliminate the vertical bars by using the Right and Left of the Directing switches.
Page 28 pixels are fixed. The <Position> adjustment moves the image to the correct position. Select <Position> and adjust the position by using the Up, Down, Right and Left switches. If vertical bars of distortion appear after finishing the <Position> adjustment, return to <Clock> adjustment and repeat the previously explained adjustment procedure.("Clock"...
Page 29: Displaying Lower Resolutions
4-2. Displaying Lower Resolutions The lower resolutions are enlarged to full screen automatically. Using the <Screen Size> function in the <Others> menu enables to change the screen size. 1. Enlarge the screen size when displaying a low resolution. Select the <Screen Size>. Select the <Screen Size>...
Page 30: Color Adjustment
Set the <Border Intensity>. In the <Enlarge> mode or <Full Screen> mode, the outer area (border) is usually black. Select <Border Intensity> in the <Others> menu and adjust by using the right and left switches. 4-3. Color Adjustment Color settings of each FineContrast mode can be adjusted and saved by using the <Color> menu of the ScreenManager.
Page 31 Allow the LCD monitor to stabilize for at least 20 minutes before making image adjustments. (Allow the monitor to warm up for at least 20 minutes before making adjustments.) Performing the <Reset> of the <Color> menu returns the color settings of the selected mode to the default settings.
Page 32: Power-Save Setup
Using <Hue> adjustment may not obtain proper tone reproduction. To change each color (red, green and blue) Gain The values shown in the percentage are available only as a reference tool. Setting the <Temperature> invalidates the <Gain> adjustment. <Gain> setting returns to the defaul.
Page 33 Operation Operation STAND-BY Power saving SUSPEND Power saving [Power Resumption Procedure] Operate the mouse or keyboard to return to a normal screen. Digital Input This monitor complies with the [Procedure] 1. Set the PC's power saving settings. 2. Select "DVI DMPM" from the <PowerManager> menu. [Power Saving System] Monitor Power Indicator...
Page 34: Making Use Of Usb (Universal Serial Bus)
5. MAKING USE OF USB (Universal Serial Bus) This monitor provides a hub which supports the USB standard. When connecting to a USB compliant PC or another hub, the monitor functions as a hub to which the USB compliant peripherals can be easily connected.
Page 35 Connecting Examples ScreenManager Pro for LCD (for Windows) For further details about the "ScreenManager Pro for LCD (for Windows)", refer to the EIZO LCD Utility Disk.
Page 36: Attaching An Arm
6. ATTACHING AN ARM The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm stand to the LCD monitor. If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting.
Page 38: Troubleshooting
7. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. No picture problems Imaging problems Other problems USB problems Problems 1. No picture Indicator status: Off Indicator status: Blue Indicator status: Yellow 2. Error messages shown below will remain on the screen for 40 seconds.
Page 39 3. Display position is incorrect. 4. Screen image is smaller or larger than the actual screen images. 5. Vertical bars of distortion appear. 6. The characters and images have several vertical bars on their right side. 7. Horizontal bars of distortion appear. 8.
Page 40 12. The screen has defective pixels (e.g. slightly light or dark). 13. Fingerprints remain on the screen. 14. The noise appears on the screen. 15. The <Smoothing> cannot be selected. 16. The Main menu of ScreenManager does not operate. 17. The FineContrast mode does not operate. 18.
Page 41 Check the downstream ports by connecting the peripherals to other downstream ports. If the problem is solved by doing this, contact an EIZO dealer. (For details, refer to the manual of the PC.) Try executing the following method. Restarting the PC...
Page 42 8. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. Cabinet To remove stains, wipe the cabinet with a soft, lightly moistened cloth using a mild detergent.
Page 43: Specifications
9. SPECIFICATIONS LCD Panel Dot Pitch Analog Horizontal Scan Frequency Digital Analog Vertical Scan Frequency Digital Resolution Analog Dot Clock (Max.) Digital Display Colors Display Area Power Supply Power Consumption Input Connector Analog Input Signal (Sync) Analog Input Signal (Video) Input Signal (Digital) Analog Signal registration...
Page 44 Temperature standard USB port Communication Speed 480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low) Power Supply 100-120 VAC Certifications and Standards 200-240 VAC Applicable to white color version only. Applicable to black color version only. Default settings Brightness 100% Smoothing FineContrast Mode Custom Analog input : VESA DPMS...
Page 45 Monitor not connected correctly. 4 short beeps PC turned off. Monitor received unsupported signal frequency. Monitor is in the advance notice mode of the Off Timer. 2 short beeps every 15 sec. The power will be off within fifteen minutes. Dimensions Pin Assignment DVI-I Connector...
Page 46 Pin No. Signal TMDS Data2- TMDS Data2+ TMDS Data2/4 Shield 13 DDC Clock (SCL) DDC Data (SDA) Analog Vertical Sync 18 TMDS Data1- TMDS Data1+ USB Port Upstream Series B Connector No. Signal Signal Cable power - Data Serial Data + Data Serial Data 4 Ground Cable Ground...
Page 47 Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry. To convert the signal correctly, the LCD monitor needs to produce the same number clock pulse as the dot clock of the graphics system. When the clock pulse is not correctly set, some vertical bars of distortion are displayed on the screen.
Page 48 The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. This model display panel consists of 1920 horizontal pixels and 1200 vertical pixels. At a resolution of 1920 x 1200, all pixels are displayed as a full screen. sRGB (Standard RGB) "International Standard for Red, Green, and Blue color space"...
Page 49 APPENDIX/ANHANG/ANNEXE Preset Timing Chart for Analog input Timing-Übersichten für Analog Eingang Synchronisation des Signaux pour Analog numerique Based on the signal diagram shown below 30 factory presets have been registered in the monitor's microprocessor. Der integrierte Mikroprozessor des Monitors unterstützt 30 werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme).
Page 50 VESA 40.0 800 × 600 @ 60 Hz VESA 50.0 800 × 600 @ 72 Hz VESA 49.5 800 × 600 @ 75 Hz VESA 56.3 800 × 600 @ 85 Hz VESA 65.0 1024 × 768 @ 60 Hz VESA 75.0 1024 ×...
Page 51 [Applicable to white cabinet version only.] Congratulations! The display you have just purchased carries the TCO'03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.
Page 52 [Applicable to black cabinet version only.] Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Page 53 Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tcodevelopment.com/ Environmental Requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire.
Page 54 The relevant TCO'99 requirement states that neither CFCs nor HCFCs may be used during the manufacture and assembly of the product. CFCs (freons) are sometimes used for washing printed circuit boards. CFCs break down ozone and thereby damage the ozone layer in the stratosphere, causing increased reception on earth of ultraviolet light with e.g.
Page 56 Hinweis zur Ergonomie : Dieser Monitor erfüllt die Anforderungen an die Ergonomie nach ISO13406-2 mit dem Videosignal, 1920 Punkte 1200 Zeilen, RGB analog, 0,7 Vp-p und mindestens 60,0 Hz Bildwiederholfrequenz, non interlaced. Weiterhin wird aus ergonomischen Gründen empfohlen, die Grundfarbe Blau nicht auf dunklem Untergrund zu verwenden (schlechte Erkennbarkeit, Augenbelastung bei zu geringem Zeichenkontrast.) Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen.
Page 57 Recycle Auskunft Die Rücknahme dieses Produktes nach Nutzungsende übernimmt EIZO in Deutschland zusammen mit dem Partner eds-r gmbh rucknahmesysteme. Dort werden die Geräte in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugeführt werden. Um einen Abholtermin zu vereinbaren und die aktuellen Kosten zu erfahren, benutzen Sie bitte folgende Rufnummer: 02153-73 35 00.
