Left View

1
No.
1
2
3
4
5
6
7
8
2
Icon Item
DC-in jack
Ventilation slots
External display
(VGA) port
Ethernet (RJ-45)
port
HDMI
USB 2.0 ports
Microphone-in
jack
Headphones/
speaker/line-out
jack
3 4 5
Description
Connects to an AC adapter
Enable the computer to stay cool, even after
prolonged use.
Connects to a display device
(e.g. external monitor, LCD projector).
Connects to an Ethernet 10/100-based
network.
Connect to HDMI devices
Connect to USB 2.0 devices (e.g. USB mouse,
USB camera).
Accepts input from external microphones.
Connects to audio line-out devices
(e.g. speakers, headphones).
6 7
