Eizo FlexScan T765 User Manual

Eizo FlexScan T765 User Manual

Color display monitor
Hide thumbs Also See for FlexScan T765:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Eizo FlexScan T765

Summary of Contents for Eizo FlexScan T765

  • Page 2: Safety Symbols

    Eizo Nanao Corporation. Eizo Nanao Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to Eizo Nanao Corporation's receipt of said information.

  • Page 3: Table Of Contents

    CONTENTS PRECAUTIONS ... 4 1. INTRODUCTION ... 8 1-1. Features ... 8 1-2. Package Contents ... 8 1-3. Controls & Connectors ... 9 2. INSTALLATION ... 10 2-1. Connecting the monitor to the PC ... 10 2-2. Getting Ready for Operation ... 12 3.

  • Page 4: Precautions

    PRECAUTIONS IMPORTANT! • This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. •...
  • Page 5 • Place the unit on a strong, stable surface. A unit placed on an inadequate surface may fall, resulting in injury or equipment damage. If the unit falls, disconnect the power immediately and have the unit checked by a qualified service engineer before using it again. Using a unit after it has been dropped may result in fire or electric shock.
  • Page 6 • Use the correct voltage. * The unit is designed for use with a specific voltage only. Connection to another voltage than specified in this User’s Manual may cause fire, electric shock, or other damage. * Do not overload your power circuit, as this may result in fire or electric shock.
  • Page 7 • Handle with care when carrying the unit. Disconnect the power cord and signal cables and remove the optional unit. Moving the unit with the cord or the option attached is dangerous. It may result in injury or equipment damage. •...

  • Page 8: Introduction

    1. INTRODUCTION Thank you very much for choosing an EIZO Color Display Monitor. 1-1. Features • Fully flat screen CRT • Horizontal scanning frequency of 30-115 kHz Vertical scanning frequency of 50-160 Hz • Support to sRGB standard • Max. Brightness 230 cd/m² bright screen (when the movie mode is selected) •...

  • Page 9: Controls & Connectors

    1-3. Controls & Connectors Front Bottom side Rear (1) ScreenManager™ (2) USB Port* with a drop down access lid Downstream port x 1 (3) BNC/D-SUB Selection Button (4) AUTO/FINE MODE Button Push the button lightly: Fine Contrast Mode Selection button Push the button for more than 2 seconds: AUTO-SIZING button (5) QuickSet™...

  • Page 10: Installation

    • Standard graphics board Signal Cable (Enclosed) • Macintosh 2. INSTALLATION Signal Cable (Enclosed) Macintosh Adapter (Optional) Please consult EIZO dealer. Video Output Connector D-Sub mini 15 pin Standard graphics board Video Output Connector D-Sub mini 15 pin Macintosh (Blue & White)
  • Page 11 Plug the power cord into the power connector at the rear of the monitor. Then, plug the other end of the cord into a power outlet. • Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord.

  • Page 12: Getting Ready For Operation

    2-2. Getting Ready for Operation Try each setting procedure if necessary in the following cases. The display image size and/or position is incorrect Press the AUTO/FINE MODE button on the front panel for more than 2 seconds. The AUTO-SIZING function centers the displayed image, aligning the image’s borders with respect to the monitor frame.

  • Page 13: Screen Adjustment

    3. SCREEN ADJUSTMENT • Allow the monitor to stabilize for at least 30 minutes before making image adjustments. 3-1. How to use the ScreenManager Use the control pad on the front panel. The control pad can be pressed in 5 directions, “Enter”, “Up”, “Down”, “Left” and “Right”.

  • Page 14: Adjustments And Settings

    Adjustments and Settings Main menu Contrast Size Position Screen Side Pin Trapezoidal Tilt Uniformity Convergence Moiré Reduction Moiré Fine Contrast Signal Filter 1 Signal Filter 2 Color Color Mode • Standard Temperature • Custom • sRGB Others PowerManager Off Timer Degauss Menu Position Input Priority...

  • Page 15: Color

    3-2. Color By using the <Color Mode> in the <Color> menu, the adjustment mode can be selected from standard mode (to set the color temperature), custom mode (to adjust each color tone, (Red, Green and Blue)) and sRGB mode. These modes allow you to adjust the color settings according to your preference.

  • Page 16: Fine Contrast

    3-3. Fine Contrast The fine contrast modes differ in brightness and contrast settings. Select the mode that is the best suited to the application in use. The mode can be changed with the AUTO/FINE MODE button that is on the front of the monitor. To select the most suitable brightness mode Push AUTO/FINE MODE button lightly.

  • Page 17: Power Save

    3-4. Power Save There are two power save settings. Choose the setting which matches your environment. Set the power saving setting by using <Others> menu. • Do your part to conserve energy, turn off the monitor when you are finished using it.

  • Page 18: Adjustment Lock

    3-5. Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Unlocked function [To lock] Press on the AUTO/FINE MODE button while switching on the monitor’s power. [To unlock] Switch off the monitor’s power, then hold down the AUTO/FINE MODE button once again and turn the power back on.

  • Page 19: Making Use Of Usb (Universal Serial Bus)

    4. MAKING USE OF USB (Universal Serial Bus) This monitor provides a hub which supports the USB standard. When connecting to a USB compliant PC or another hub, the monitor functions as a hub to which the USB compliant peripherals can be easily connected. As an added advantage, the monitor can be controlled from a PC with a mouse or keyboard when utilizing the enclosed utility software “ScreenManager Pro for USB”.
  • Page 20 After setting up, the monitor’s USB hub is available for connecting USB compliant peripherals to the downstream ports of the monitor. (Connection example) USB Cable Digital Camera Keyboard <Front port> Downstream connector ScreenManager Pro for USB (for Windows) For further details about the “ScreenManager Pro for USB”, refer to the readme.txt in the CD-ROM.

  • Page 21: Troubleshooting

    5. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. Problems 1. No picture • Indicator status: Off • Indicator status: Green • Indicator status: Flashing Green / Yellow • Indicator status: Flashing Yellow 2.
  • Page 22 To eliminate the vibration, set the adjustment level to lower percentage or 0%. If the volume level of the EIZO optional i·Sound speaker is too high, it may, in some cases, cause a slight vibration. To eliminate, turn down the volume of the speaker.
  • Page 23 Problems 8. The entire screen appears too dark or bright. 9. Color is abnormal. • The entire screen appears bluish or reddish. • Color purity is not uniform. • Misconvergence of colors(red, green, blue) 10. The Auto sizing function does not work properly. 11.
  • Page 24 Damper wires are used to support the CRT’s aperture grille, and are visible as thin dark lines across the screen. All EIZO aperture grille type CRTs include two such horizontal wires. The aperture grille itself is a grid of taut metal filaments that spans the entire screen from top to bottom.

  • Page 25: Cleaning

    6. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operational lifetime. Clean the cabinet and CRT areas as follows: • Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or CRT.

  • Page 26: Specifications

    (Viewable image size: 452 mm (17.8”)) 100-120/200-240 VAC±10%, 50/60 Hz, 1.8 A/0.9 A Normal/Max.: 140 W/165 W** (** With EIZO optional speaker & USB attached) PowerManager Mode 1: Less than 10 W PowerManager Mode 2: Less than 3 W D-Sub mini 15-pin and BNC × 5 (Switchable)

  • Page 27: Preset Timing

    Preset Timing Resolution fH(kHz) VGA(text) 720 x 400 31.47 VESA 1280 x 1024 91.15 Dimensions (17.8) (14.3) 10° (10.7) 4° (17.9) 129.5 (5.1) φ306 47.5 (φ12.0) (1.9) (2.95) FRONT Pin Assignment * D-Sub mini 15 pin connector * BNC Connector Frequencies Interlace fV(Hz)

  • Page 28: Glossary

    5,000K: Often used in printing industry. 6,500K: Good for video-image display. 9,300K: Default setting for your EIZO monitor. Convergence Convergence is the monitor’s ability to precisely illuminate specific phosphors and line them up properly in order to produce pure color.
  • Page 29 sRGB (Standard RGB) “International Standard for Red, Green, and Blue color space” A color space was defined with the aim of the color matching between applications and hardware devices, such as monitors, scanners, printers and digital cameras. As a standard default space, sRGB allows Internet users to closely match colors.

  • Page 30: Index

    Custom -------------------------------- 14, 15 Cutoff ---------------------------------- 15, 28 Default setting ----------------------- 14, 26 Degauss ------------------------------ 14, 29 Dimensions ------------------------------- 27 Eizo Utility Disk -------------------------- 8 Fine Contrast ------------------------ 14, 16 Gain ------------------------------------ 15, 28 Glossary ----------------------------------- 28 Input Priority ------------------------- 14, 18...
  • Page 31 Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment. The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during their manufacture.
  • Page 32 Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.

  • Page 33: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. -AC Cord -Shielded Signal Cable (enclosed) This Class B digital apparatus complies with Canadian ICES-003.
  • Page 34 Untergrund zu verwenden (schlechte Erkennbarkeit, Augenbelastung bei zu geringem Zeichenkontrast.) Recycle Auskunft Die Rücknahme dieses Produktes nach Nutzungsende übernimmt EIZO in Deutschland zusammen mit dem Partner von Roll MBB Recycling GmbH. Dort werden die Geräte in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugeführt werden.
