Ryobi P730 Operator's Manual

18 volt inflator digital gauge
Hide thumbs Also See for P730:
Table of Contents

Advertisement

Quick Links

Your
inflator
has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNiNG:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAvE THiS MANUAL fOR fUTURE REfERENCE
OPERATOR'S MANUAL
18 vOLT iNfLATOR
DiGiTAL GAUGE
P730
BATTERiES AND
CHARGERS SOLD
SEPERATELY

Advertisement

Table of Contents
loading

Related Manuals for Ryobi P730

Summary of Contents for Ryobi P730

  • Page 1 OPERATOR’S MANUAL 18 vOLT iNfLATOR DiGiTAL GAUGE P730 BATTERiES AND CHARGERS SOLD SEPERATELY Your inflator has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THiS WARRANTY COvERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®...

  • Page 3: General Safety Rules

     Use battery only with charger listed. risk of starting the inflator accidentally. MODEL BATTERY PACk (P100) CHARGER (P110)  Store idle inflators out of reach of children and other P730 130255004 1423701, 140237021 untrained persons. Inflators are dangerous in the hands or 130224028 or 140237023 of untrained users.

  • Page 4: Specific Safety Rules

    GENERAL SAfETY RULES  Never point any inflator toward yourself or others. SERviCE  keep the exterior of the inflator dry, clean, and free  inflator service must be performed only by qualified from oil and grease. Always use a clean cloth when repair personnel.

  • Page 5: Safety Rules For Charger

    SAfETY RULES fOR CHARGER  An extension cord should not be used unless WARNiNG! absolutely necessary. Use of improper extension cord could result in a risk of fire and electric shock. If extension READ AND UNDERSTAND ALL iNSTRUCTiONS. cord must be used, make sure: Failure to follow all instructions listed below, may result in a.

  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESiGNATiON/EXPLANATiON Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 7 If you do not understand ing, use only identical replacement parts. the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance. WARNiNG: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.

  • Page 8: Features

    fEATURES PRODUCT SPECifiCATiONS Maximum Pressure ..150 PSI, 10.34 BAR, 10.55 KG/CM Motor ..............18 Volt DC Charger Input........10 V, 60 Hz, AC only High Pressure Hose Length ........4 in. Charge Rate ..............1 hour Low Pressure Hose Length ........14 in. Gauges ....

  • Page 9: Assembly

    ASSEMBLY UNPACkiNG WARNiNG: This product has been shipped completely assembled. If any parts are damaged or missing do not operate  Carefully remove the inflator and any accessories from this inflator until the parts are replaced. Failure to heed the box. Make sure that all items listed in the packing list this warning could result in serious personal injury.

  • Page 10: Charging The Battery Pack

    OPERATiON LED fUNCTiONS Of CHARGER LED WiLL BE ON TO iNDiCATE STATUS Of GREEN LED CHARGER AND BATTERY PACk:  Red LED on = Fast charging mode.  Green LED on = Fully charged and in maintenance charge mode.  Green LED on = When battery pack is inserted into charger, indicates hot battery pack or that battery pack is out of normal temperature range.
  • Page 11 OPERATiON TO iNSTALL BATTERY PACk See Figure 4.  Place the battery pack in the inflator. Align raised rib on battery pack with groove in the inflator’s battery port.  Make sure the latches on each side of the battery pack snap in place and that battery pack is secured in the inflator before beginning operation.
  • Page 12 OPERATiON SWiTCH TRiGGER LOCK-ON See Figure 7. BUTTON To turn the inflator ON, depress the switch trigger. To turn LOCK it Off, release the switch trigger. UNLOCKED LOCk-ON BUTTON See Figure 7. The inflator is equipped with a lock-on button for continuous inflating over extended periods of time. The lock-on button SWITCH is located on top of the handle.
  • Page 13 OPERATiON iNfLATiNG WiTH THE HiGH PRESSURE AiR HOSE AND ADAPTORS AIR CHUCK UNLOCK See Figure 10 - 13. ADAPTORS The high pressure air hose can be used with the provided adaptors to inflate a variety of items.  Insert adaptor into air chuck and push air chuck clamp down until it locks into place.
  • Page 14 OPERATiON QUiCk SHUTOff SWiTCH See Figure 15. Depress the quick shutoff switch at any time to stop the inflator. DiGiTAL GAUGE AIR PRESSURE See Figures 15. QUICK NOTE: Digital gauge displays pressure of high SHUTOFF pressure hose only. Preset features apply to high pressure SWITCH applications only.

  • Page 15: Maintenance

    MAiNTENANCE Only the parts shown on the parts list are intended to be WARNiNG: repaired or replaced by the customer. All other parts should be replaced at an Authorized Service Center. When servicing, use only identical replacement parts. REPLACEMENT fUSE Use of any other parts may create a hazard or cause product damage.
  • Page 16 When ordering repair parts, always give the following information: P730 • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGiES, iNC. 148 Pearman Dairy Road, Anderson, SC 965 Phone 1-800-55-579 www.ryobitools.com...
