JVC DLA-X75R Specifications

UPC Code: 046838066764
The New JVC DLA-X75R
THX 3D Certi ed D-ILA Front Projector
DLA-X75R Key Features
The DLA-X75R delivers stunning picture detail thanks to JVC's new 4K
3D-enabled Full HD D-ILA projector, the DLA-X75R uses three 1920 x 1080 D-ILA devices and provides a native contrast ratio of 90,000:1 for peak
whites and deep blacks. Also o ered is on-screen gamma control to ne-tune the image and a range of adjustments to tailor set up to virtually
any room.

Speci cations

2
: : NEW - 4K e-Shift system displays images in 4k precision for on
screen resolution of 3840x2160*
: : New 2K to 4K Scaling with 8 Band Detection & New MPC Control
with 5 selectable 4K pro les
: : NEW - Exceptional Native Contrast Ratio - 90,000:1
: : 2D-3D Conversion
: : 3D Anamorphic Capable
: : NEW - 3D Crosstalk Elimination
: : 3D Enabled with 3-chip 0.7-inch 1920x1080 D-ILA devices
: : NEW - Supports Frame Sequential 3D, Side-by-Side 3D and
Top-Bottom 3D methods
: : NEW - Lens Memory with 10 user adjustable presets
: : Exclusive Real Color Imaging Technology with Xenon Lamp
Color Presets
: : 7-Axis Color Management System (R,G,B,C,M,Y and Orange)
: : Fan Noise: 23db
: : 24p capable 120Hz Clear Motion Drive
: : 4th Generation Optical Engine w/Improved Wire Grid Polarizer
: : Customized Gamma Control On-screen
: : Wide Lens Shift Functionality (V: 80%, H: 34%)
: : 2x Motorized Zoom Lens (1.4:1 – 2.8:1)
: : 3D Parallax Adjustment
: : Optional RF Active Shutter Glasses (PK-AG3)
: : Optional RF 3D Emitter (PK-EM2)
: : 2 Year Warranty
*4k precision (3840x2160 on screen resolution) does not work when 3D or Clear Motion Drive are engaged
Distributed By:
THX 3D Certi ed D-ILA Front Projector
e-Shift 2 technology that displays 2D HD content with full 4K precision. A
Inputs & Outputs
: : Dual HDMI 1.4a Digital Inputs
: : HD Component Video Input
: : LAN Connection
: : RS-232C
: : 12-Volt Trigger
: : D-sub 15-pin PC Input
Weights & Measurements
Top
17 / " | 455
7
8
Weight: 33.95 lbs. /15.4 kg.
Notes:
• Specifications are subject to change without notice.
• HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
JVC Consumer A/V Group
DLA-X75R
www.jvc.com
Front
1 / " 1
1
4
45
Side
ø60
18 / " | 472
1
2
|
A Division of JVC Americas Corp.
1700 Valley Road, Wayne, NJ 07470
/ "
1
4
45
