JVC DLA-X900R Instructions Manual

D-ila projector
Hide thumbs Also See for DLA-X900R:
Table of Contents

Advertisement

Quick Links

.
D-ILA
PROJECTOR
DLA-X900R
DLA-X700R
DLA-X500R
.
http://manual3.jvckenwood.com/projector/mobile/global/
The Mobile User Guide can be viewed on mobile internet devices including
smartphones and tablets.
.
For Customer use :
Enter below the serial No. which is
located on the side of the cabinet.
Retain this information for future
reference.
Model No.
DLA-X900R / DLA-X700R /
DLA-X500R
Serial No.
.
Not suitable for household room illumination.
INPUT
Mobile User Guide
Pour utilisation par le client :
Entrerci-dessous le N°de série qui
est situé sous le boîtier. Garder
cetteinformation comme référence
pour le futur.
N° de modèle
DLA-X900R / DLA-X700R /
DLA-X500R
N° de série
ESPAÑOL/CASTELLANO
INSTRUCTIONS
Instrucción para el cliente :
Introduzca a continuación el nº de
serie que aparece en la parte
inferior lateral de la caja. Conserve
esta información como referencia
para uso ulterior.
Modelo Nº
DLA-X900R / DLA-X700R /
DLA-X500R
Nº de serie
ENGLISH
FRANÇAIS
PC027183199-1

Advertisement

Table of Contents
loading

Related Manuals for JVC DLA-X900R

Summary of Contents for JVC DLA-X900R

  • Page 1 Conserve reference. pour le futur. esta información como referencia para uso ulterior. Model No. DLA-X900R / DLA-X700R / N° de modèle DLA-X900R / DLA-X700R / Modelo Nº DLA-X900R / DLA-X700R / DLA-X500R DLA-X500R DLA-X500R Serial No.

  • Page 2: Safety Precautions

    This product has a High Intensity CAUTION: Dis-charge (HID) lamp that contains mercury. Changes or modification not approved by JVC could void the user’s authority to operate the equipment. Disposal of these materials may be NOTE: regulated in your community due to environmental considerations.

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS Power source indicated on the label. If you are not sure of the type of power supply to your home, consult your Electrical energy can perform many useful functions. product dealer or local power company. This unit has been engineered and manufactured to This product is equipped with a three-wire plug.
  • Page 4 Be sure to ask your dealer to install the unit replacement, please consult your dealer, or the nearest (e.g.attaching it to the ceiling) since special authorized JVC service center. technical knowledge and skills are required for When fixing the unit to the ceiling, Please note that we do installation.

  • Page 5: Power Connection

    THIS APPARATUS MUST BE EARTHED. Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11 61118 Bad Vilbel...
  • Page 6 ENGLISH Information for Users on Disposal of Old Equipment and Batteries [European Union only] These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.
  • Page 7 ITALIANO Informazioni per gli utenti sullo smaltimento delle apparecchiature e batterie obsolete [Solo per l’Unione Europea] Questi simboli indicano che le apparecchiature a cui sono relativi non devono essere smaltite tra i rifiuti domestici generici. Se si desidera smaltire questo prodotto o questa batteria, prendere in considerazione i sistem i o le strutture di raccolta appropriati per il riciclaggio corretto.
  • Page 8 SVENSKA Information för användare gällande bortskaffning av gammal utrustning och batterier [Endast den Europeiska unionen] Dessa symboler indikerar att utrustning med dessa symboler inte ska hanteras som vanligt hushållsavfall. Om du vill bortsk affa produkten eller batteriet ska du använda uppsamlingssystem eller inrättningar för lämplig återvinning. Observera: Märkningen Pb under symbolen för batterier indikerar att detta batteri Batteri innehåller bly.
  • Page 9 MAGYAR Felhasználói információ az elhasznált be rendezések és akkumulátorok elhelyezéséről [Csak az Európai Unióban] Ez a szimbólum azt jelzi, hogy a berendezés nem helyezhető az általános háztartási hulladék közé. Ha meg szeretne szabadulni a terméktől vagy az akkumulátortól, akkor legyen tekintettel az gyűjtő rendszerre vagy intézményekre a megfelelő...

  • Page 10: Table Of Contents

    Symbols used in this manual Converting 2D Movies to 3D Movies for Viewing ..34 Adjusting 3D Movies .......... 34 S indicates a function that is supported by DLA-X900R. R indicates a function that is supported by DLA-X700R. Adjust/Set Q indicates a function that is supported by DLA-X500R.

  • Page 11: Accessories/Optional Accessories

    Accessories/Optional Accessories Check the Accessories Lens cover Q ..............1 piece * It is attached to the main unit at the time of shipment. Remote control ............... 1 piece AAA-size batteries (for operational check) ......2 pieces Power cord (for USA) (about. 2 m) ......... 1 piece Power cord (for UK) (about.

  • Page 12: Main Features

    Main Features New, impressive image quality with the 4K resolution By employing JVC’s unique image-processing technology (MPC), focus and blurring can be detected and adjusted in real time, allowing viewers to enjoy the enhanced expressiveness of 4K images. (p. 39) The photos are for illustrative purposes only.
  • Page 13 For more details, please refer to the isf website. http://www.imagingscience.com/ Intelligent Lens Aperture JVC has developed an image analysis algorithm, which analyzes the state of the video image in real time, and controls the aperture dynamically according to the image information.

  • Page 14: Controls And Features

    Controls and Features Main Unit - Front A Lens D Indicator This is a projection lens. Do not look through the lens Refer to “Indicator Display on the Main Unit”p. 78. while an image is projected. E Exhaust vent B Lens cover S R Warm air is discharged to cool down the internal temperature.

  • Page 15: Main Unit - Rear

    Main Unit - Rear I Input terminals L Remote Sensor (rear) In addition to the video input terminal, there are also Please aim the remote control at this area when using other connection terminals for devices such as controllers and optional equipment. * There is also a remote sensor at the front.

  • Page 16: Main Unit - Input Terminals

    Main Unit - Input Terminals Enlarged View of Rear Face A [HDMI 1] input terminal F [TRIGGER] terminal (E) Output terminal for DC 12 V, 100 mA power supply. It B [HDMI 2] input terminal is used for sending output signals to control devices such as an elevating screen that is equipped with a For connecting to devices that support HDMI output.

  • Page 17: Remote Control

    Remote Control A B [STAND BY] O [LIGHT] Illuminates the buttons on the Turns off the power. (p. 26) remote control. B C [ON] P [JKH I] keys Turns on the power. (p. 25) For selecting an item. C [INPUT] Q [OK] INFO.

  • Page 18: Loading Batteries Into The Remote Control

    Loading Batteries into the Remote Control If the remote control has to be brought closer to the projector to operate, it means that the batteries are wearing out. Replace the batteries with new ones (AAA). Insert the batteries according to the t s marks. Be sure to insert the s end first. If an error occurs while using the remote control, remove the batteries and wait for five minutes.

  • Page 19: Installing The Projector

    Installing the Projector Precautions during Installation Please read the following carefully before installing this Using the projector unit. This unit uses a projection lamp, which will heat up when in use. Do not install at the following Please refrain from projecting in the following circumstances.

  • Page 20: Precautions During Mounting

    Take the necessary actions to prevent the main unit from falling off such as during an earthquake. Regardless of the warranty period, JVC is not liable When this unit is to be mounted to a fixed position for for any product damage caused by mounting the unit use, install it horizontally.

  • Page 21: Adjusting The Position

    Adjusting the Position Adjusting the elevation angle of the projector Adjusting the position of the image The height and inclination of the unit (0 to 5 mm) can be By using the lens shift feature of this unit, you can shift adjusted by turning the feet.

  • Page 22: Connecting The Projector

    Connecting the Projector Do not turn on the power until connection is complete. The connection procedures differ according to the device used. For details, please refer to the instruction manual of the device to be connected. This projector is used for projecting images. To output the audio of connected devices, please connect a separate audio output device, such as an amplifier or speaker.

  • Page 23: Connecting To The Lan Terminal

    Connecting to the LAN Terminal This Unit To [LAN] Terminal Network Connection Cable (Sold Separately) Server Desktop PC, etc. The network is used to control this unit. It is not used for sending or receiving video signals. Please contact your network administrator for information concerning the network connection. Set “ECO Mode”...

  • Page 24: Connecting To The Trigger Terminal

    Connecting to the TRIGGER Terminal Screen This Unit To [TRIGGER] Terminal Trigger Input Terminal (Ø3.5) Trigger Cable (Sold Separately) Do not use it to supply power to other devices. Connecting to the audio terminal of another device may cause the device to malfunction or break down. Using beyond the rated value will cause the unit to malfunction.

  • Page 25: Viewing Videos

    Viewing Videos MEMO LAMP WARNING STANDBY/ON When you are using Q, be sure to remove the lens cover. Connect the power cord, and ensure that the “STANDBY/ON” indicator lights up in red. Turn on the power Remote control: press the C [ON] button Projector unit: press the A [STANDBY/ON] button The “STANDBY/ON”...

  • Page 26: Turn Off The Power

    Turn off the power Remote control: press the B [STAND BY] button Projector unit: press the A [STANDBY/ON] button While the “Are you sure you want to turn off?” message is displayed, press the button again. The lamp turns off, and the “STANDBY/ON” indicator switches from a green light to a red blinking light. After the light goes off, the fan will run for about 100 seconds to cool down the lamp (Cool-down mode).

  • Page 27: Adjusting The Projector Screen

    Adjusting the Projector Screen Adjusting the Lens According to the Projection Position Press the [LENS CONTROL] button, and use the [JKH I] keys to adjust Focus, Zoom (screen size), and Shift (screen position) Focus INPUT Pressing the [LENS CONTROL] or [OK] button each time switches the mode in the following sequence: “Focus”"“Zoom”"“Shift”"“Focus”...

  • Page 28: Saving And Retrieving Adjustment Settings

    Saving and Retrieving Adjustment Settings The Focus, Zoom, and Shift settings can be saved or retrieved, so you can switch easily to a different aspect ratio (screen size) according to the image. Pressing the [LENS MEMORY] button each time switches the mode in the following sequence: “Lens Memory Save”"“Lens Memory Select”"“Lens Memory Name Edit”"“Lens Memory Save”...
  • Page 29 Retrieving an adjustment data Press the [LENS MEMORY] button to display “Lens Memory Select” Pressing the [LENS MEMORY] button each time switches the mode in the following sequence: “Lens Memory Select”"“Lens Memory Save”"“Lens Memory Name Edit”"“Lens Memory Select”... You can also retrieve an adjustment data by selecting “Installation”"“Lens Control”"“Lens Memory Select” from the menu.

  • Page 30: Adjusting Image Quality Automatically According To The Viewing Environment

    Adjusting Image Quality Automatically According to the Viewing Environment By configuring “Environment Setting” according to the viewing environment, image quality adjustment and Set Screen Adjust correction according to environmental differences are performed automatically to minimize any influence on the By selecting the optimal correction mode image quality.

  • Page 31: Adjusting The Screen Size (Aspect)

    Adjusting the Screen Size (Aspect) The screen size of the projected image can be adjusted Example of input image and screen size optimally according to the original screen size (aspect) that has been input. HDMI Signal Input Press the [MENU] button to display Output Image the menu Setting...

  • Page 32: Viewing 3D Movies

    Viewing 3D Movies By using the 3D GLASSES (PK-AG1, PK-AG2, or PK-AG3) and 3D SYNCHRO EMITTER (PK-EM1 or PK-EM2), both sold separately, you can enjoy 3D video images. For 3D GLASSES and 3D SYNCHRO EMITTER that are compatible with this unit, please refer to “Optional Accessories”p.

  • Page 33: Viewing 3D Movies

    Viewing 3D Movies Connect this unit to a 3D-compatible Pressing the [3D FORMAT] button each time switches the mode in the following sequence: HDMI device, and turn on the power “Auto”"“Side by Side”"“Top and to play back the 3D video image Bottom”"“2D”"“Auto”...

  • Page 34: Converting 2D Movies To 3D Movies For Viewing

    Converting 2D Movies to 3D Movies for Viewing Press the [3D SETTING] button to Press the [MENU] button to exit display “3D Setting” MEMO The [3D SETTING] button is positioned differently on the remote control depending on Depending on the movies, 3D effect may be less than the model in use.

  • Page 35: Selecting An Image Quality According To The Video Type

    Selecting an Image Quality According to the Video Type Setting the Picture Mode You can adjust the image quality according to the type of video image you are viewing. Press the [PICTURE MODE] button to select “Picture Mode” You can also perform setting from “Picture Adjust”"“Picture Mode” in the menu.

  • Page 36: Setting The Color Profile

    Setting the Color Profile By setting the “Color Profile” (color space information) according to the “Picture Mode”, you can fine-tune the image quality according to the movie you are viewing. After configuring “Picture Mode” (p. 35), press the [COLOR P.FILE] button Pressing the [COLOR P.FILE] button each time switches the “Color Profile”...
  • Page 37 List of “Color Profile” for “Picture Mode” S R Picture Mode 2D Signal Input 3D Signal Input Description Film Film 1 Color space that is close to the characteristics of Eastman Kodak Company movie films. — Film 2 Color space that is close to the characteristics of FUJIFILM Corporation movie films. —...

  • Page 38: Adjusting To The Preferred Color (Color Management)

    Adjusting to the Preferred Color (Color Management) Based on the setting of the selected “Color Profile”, you can adjust each of the following colors according to your preference: Red, Orange, Yellow, Green, Cyan, Blue, and Magenta. Press the [ADVANCED MENU] button to display the “Color Profile” menu Set “Color Management”...

  • Page 39: Adjusting Movies For Increased Expressiveness (Multiple Pixel Control)

    Adjusting Movies for Increased Expressiveness (Multiple Pixel Control) The new image-processing algorithm developed by JVC In the default “Original Resolution” setting (“Auto”), the helps to create a natural impression that is sharper at resolution is set automatically. areas in focus, and softer at areas that are not in focus,...
  • Page 40 About the analysis screen Pressing the [P.ANALYZER] button on the remote control displays the analysis screen. The operation varies with the state of the OSD. Press the [P.ANALYZER] button The frequency components of the input image are displayed. The frequency components are distinguished using different colors. When setting the “Original Resolution”...

  • Page 41: Fine-Tuning The Image Quality

    Fine-tuning the Image Quality Adjusting the Output Value of the Projected Image (Gamma) You can adjust the output value of the projected image with respect to the video signal input. Example of gamma adjustment The overall image appear brighter with respect to the original image, making the dark areas more visible. Input Value The photos are for illustrative purposes only.

  • Page 42: Fine-Tuning To The Preferred Gamma Setting

    Gamma Settings for Different “Color Profile” S R Color Profile Selectable Settings Description Film 1 Film 1 Image is close to the characteristics of Eastman Kodak Company movie films. Film 2 Places more emphasis on the gradation compared to the “Film 1” setting. Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s preference.
  • Page 43 Adjust to the preferred setting Item Description Setting Color Selection Select “Color Selection”, and select the color to adjust White/Red/Green/Blue Picture Tone Adjusts the overall brightness automatically for a well-balanced -16 (darkens image for an result without compromising the gradation of the image. underexposed effect) to +16 (brightens image for an overexposed effect)

  • Page 44: Reducing The After-Image Of Fast-Moving Images (Clear Motion Drive (C.m.d.))

    (p. 17) Viewing High Contrast Images (Intelligent Lens Aperture) JVC has developed an image analysis algorithm, which analyzes the state of the video image in real time, and controls the aperture intellectually according to the image information.

  • Page 45: Adjustments And Settings In The Menu

    Adjustments and Settings in the Menu Pressing the [MENU] button displays the menu. Press the [JKH I] keys to select an item, followed by pressing the [OK] button to confirm the selection. List of Menu Items Picture Adjust Picture Mode ..............................p. 35 9 Clear Black ..............................
  • Page 46 Installation Lens Control ..............................p. 27 9 Focus ................................p. 27 9 Zoom ................................p. 27 9 Shift ................................p. 27 9 Image Pattern ............................. p. 52 9 Lock ................................p. 52 9 Lens Memory Select ........................... p. 28 9 Lens Memory Save ............................. p. 28 9 Lens Memory Name Edit ..........................

  • Page 47: Picture Adjust

    Continuous use at the “High” setting may cause the lamp to darken faster. Lens Aperture JVC has developed an image analysis algorithm, which analyzes the state of the video image in real time, and controls the aperture dynamically according to the image information.

  • Page 48: Color Profile

    Color Profile By setting the “Color Profile” (color space information) according to the “Picture Mode”, you can fine-tune the image quality according to the movie you are viewing. Æ “Setting the Color Profile” （p. 36） Color Management Each of the colors is adjustable according to the user’s preference. Æ...

  • Page 49: Mpc Level

    MPC Level You can enjoy natural, expressive 4K images with a stronger sense of depth. Æ “Adjusting Movies for Increased Expressiveness (Multiple Pixel Control)” （p. 39） 4K e-shift Switches the display resolution. Setting values: On (4K), Off (2K) Original Resolution For selecting a resolution for the content you are viewing.

  • Page 50: Input Signal

    Tint For adjusting the hue of the video image. Setting range: -50 (reddish) to +50 (greenish) * Adjustment cannot be made when “Color Profile” is set to “x.v.Color”. Input Signal Input Level For setting the dynamic range (gradation) of the video input. If the dynamic range is not appropriate, the bright areas become overexposed, and the dark areas become underexposed.

  • Page 51: Aspect

    Aspect The screen size of the projected image can be adjusted optimally according to the original screen size (aspect) that has been input. Æ “Adjusting the Screen Size (Aspect)” （p. 31） Progressive For converting the interpolation setting of the interlaced signals. Setting Description Auto...

  • Page 52: Installation

    Installation Lens Control Focus / Zoom / Shift For adjusting the lens according to the projection position Æ “Adjusting the Lens According to the Projection Position” （p. 27） Image Pattern Setting Description Displays the lens adjustment pattern. Displays external signals, and does not display the lens adjustment pattern. Lock Setting Description...

  • Page 53: Pixel Adjust

    Pixel Adjust Adjust For setting the adjustment feature to On (Memory 1 or Memory 2) or Off. * You can save the settings separately when an anamorphic lens is used and when you are using the projector with a screen. Adjust Area Setting Description...

  • Page 54: Installation Style

    Installation Style For setting to “Front”, “Ceiling Mount (F)”, “Rear”, or “Ceiling Mount (R)” according to the installation status of the projector. “Front” or “Ceiling Mount (F)” is set when projector is installed in the front with respect to the screen. “Rear”...
  • Page 55 Whole Adjust (Pixel) Operation Procedure For making general adjustments to slight color fringing in the horizontal/vertical directions of the video image. A Set “Adjust Area” to “Whole” B Select “Adjust Color” and “Adjust Pattern Color” C Select “Adjust(Pixel)”, and press the [OK] button The selected adjustment pattern and Adjustment (Pixel) window are displayed.
  • Page 56 Whole Adjust (Fine) Operation Procedure For making general adjustments on the misalignment of the entire screen using “Adjust(Pixel)”, followed by making fine adjustments. A Set “Adjust Area” to “Whole” B Select “Adjust Color” and “Adjust Pattern Color” C Select Adjust(Fine), and press the [OK] button The selected adjustment pattern and Fine window are displayed.
  • Page 57 Zone Adjust Operation Procedure For fine-tuning misalignments on a part of the screen after adjusting the overall screen misalignment using “Adjust(Pixel)” and “Adjust(Fine)”. The screen can be divided vertically and horizontally into 10 sections for partial adjustments to be made. A Set “Adjust Area”...

  • Page 58: Display Setup

    Display Setup Back Color For setting the color of the background to “Blue” or “Black” when there is no signal input. Menu Position For setting the display position of the menu. Signal Display Setting Description Shows the input terminal for 5 seconds when input is switched. Not displayed.

  • Page 59: Function

    Function Trigger For setting whether to supply a 12 V output to devices such as an external screen equipped with a trigger function. Setting Description No output. On (Power) Outputs control signals (12 V) from the trigger terminal when the power is turned After the power is turned off, output stops when the unit shifts to the Standby mode after cooling is complete.

  • Page 60: Information

    Glossary of Network Terminology DHCP : Abbreviation for Dynamic Host Configuration Protocol. This is a protocol for the network to assign an IP address automatically to the connected device. IP Address : Numeric characters for identifying the device that is connected to the network. Subnet Mask : Numeric characters that define the bit count used for the network address that is a segment of the IP address.

  • Page 61: Replacing The Lamp

    Replacing the Lamp The lamp is a consumable item. If the image appears dark or the lamp goes out, replace the lamp unit. When the lamp replacement time approaches, the user is notified with a message displayed on the screen and by the indicator.
  • Page 62 Install the new lamp unit MEMO Usable lamp life When the lamp is used with “Lamp Power” set to “Low”, the lamp life on this unit is approximately 4000 hours. This is the average usable time and not a guaranteed value. The lamp life may not reach 4000 hours depending on Handle the operating conditions.

  • Page 63: Resetting The Lamp Time

    Resetting the Lamp Time Reset the lamp time when you have replaced the lamp. Resetting the lamp time using the remote It provides an estimated timing for lamp replacement control Resetting the lamp time from the menu Insert the power plug into the power screen outlet Press the [MENU] button to display...

  • Page 64: Cleaning And Replacing The Filter

    Cleaning and Replacing the Filter Clean the filter regularly Otherwise, the air intake efficiency may deteriorate, and malfunction may occur. Reinstall the inner filter CAUTION Make sure that you pull out the power plug from the Check that the left outlet before cleaning or replacing the filter.

  • Page 65: Troubleshooting

    Troubleshooting Before sending the unit to your authorized dealer for repair, please check the following points. The following symptoms are not malfunctions. You do not need to worry about the following symptoms if there is no abnormality on the screen. A part of the top or front surface of the unit is hot.
  • Page 66 Check Action Refer to Is “Control with HDMI” set to “On”? If the video image does not appear when “Control with p. 50 HDMI” is set to “On”, change the setting to “Off” and power on this unit and the external device again. Is the video image temporarily hidden? Press the [HIDE] button p.
  • Page 67 Video image is fuzzy Check Action Refer to Is the focus correctly adjusted? Adjust the focus. p. 27 Is the unit placed too near or too far away Set the unit at a correct distance from the screen. p. 75 from the screen? Video image flickers Check...
  • Page 68 Remote control does not work Check Action Refer to Are the batteries correctly loaded? Match the polarities (t s) correctly when loading the p. 18 batteries. Are the batteries exhausted? Replace with new batteries. p. 18 Is there an obstructing object between Remove any obstructing object.

  • Page 69: When The Following Messages Appear

    When the following messages appear... Message Description Action No device is connected to the input Input the video signals. terminal No Input The input terminal is connected but there is no signal A video signal that cannot be used with Input video signals that can be used.

  • Page 70: External Control

    External Control It is possible to control this unit by connecting it to a PC using an RS-232C cross cable (D-sub 9-pin). The projector can be controlled by connecting it to a PC through the computer network with a LAN cable for control commands to be sent to the projector.

  • Page 71: Command Format

    Command Format The command between this unit and the computer consists of “Header”, “Unit ID”, “Command”, “Data” and “End”. Header (1 byte), Unit ID (2 bytes), Command (2 bytes), Data (n bytes), End (1 byte) Header This binary code indicates the start of communication. Binary Code Type Description...

  • Page 72: Remote Control Code

    Remote Control Code Binary code is sent during communication. The following applies to the case when the remote control code is “A”. In the case of “B”, add “36” to the beginning of the code. Remote Control Button Name Binary Code Remote Control Button Name Binary Code STAND BY...

  • Page 73: Communications Example

    Communications Example This section shows the communication examples of RS-232C. Operating command Type Command Description Connection check PC " This unit: 21 89 01 00 00 0A Connection check This unit " PC: 06 89 01 00 00 0A Power (On) PC "...

  • Page 74: Specifications

    Specifications Product Name D-ILA Projector Model Name DLA-X900RB, DLA-X700RB, DLA-X500RB/W*1,2 Display Panel/Size D-ILA device *3, 4 0.7" (1920 x 1080 pixels) x 3 (total no. of pixels: approx. 6.22 million) Projection Lens 2.0 x power zoom lens (1.4:1 to 2.8:1), motorized zoom and focus Light-source Lamp 230 W ultra-high pressure mercury lamp [model no.: PK-L2312U] Average lifespan: 4000 hours (“Low”...

  • Page 75: Screen Size And Projection Distance

    Design and specifications are subject to change without prior notice. Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order to aid comprehension. Images may differ from the actual product. About Trademarks and Copyrights HDMI, HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LCC.
  • Page 76 When a 4:3 screen is used Screen Size Projection Distance Diagonal (Model) Width (mm) Height (mm) Wide-end (m) Tele-end (m) 1219 2.22 4.49 1422 1067 2.60 5.24 1626 1219 2.98 6.00 1829 1372 3.36 6.75 2032 1524 3.74 7.51 2235 1676 4.11 8.26...
  • Page 77 Types of Possible Input Signals Video Digital Video Signal 480p, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz, 1080p/24 Hz, 1080p/50 Hz, 1080p/60 Hz, 3840×2160/24 Hz, 3840×2160/25 Hz, 3840×2160/30 Hz, 3840×2160/50 Hz(4:2:0), 3840×2160/60 Hz(4:2:0), 4096×2160/24 Hz* 3D Signal Frame Packing 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz Side-by-side 1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz, 1080p/50 Hz, 1080p/24 Hz,...
  • Page 78 Indicator Display on the Main Unit Meaning of the lighting figures The indicator lights up. The indicator appears blinking. Operation mode display Displays using the different colors and solid/blinking light of the “STANDBY/ON” indicator. “STANDBY/ON” lights up (red) “STANDBY/ON” lights up (green) All lights off In standby state During lamp startup...
  • Page 79 Warning display You can tell the details of a warning from the (repeated) displays of the “WARNING” and “LAMP” indicators. The “STANDBY/ON” indicator, which shows the operating mode of the unit, is displayed simultaneously as described above. The Warning mode is activated once the message is displayed. Projection is interrupted, and the cooling fan is turned on for about 100 seconds.
  • Page 80 Dimensions (Unit: mm) Top Surface Bottom Surface Lens Lens Rear Surface Front 227.5 Ø60 Lamp Cover Lens Center The dimensions are identical for all the models.

  • Page 81: Index

    Index HIDE ..............25 A Accessories ............11 High Altitude Mode ..........54 Adjusting Distortion of the Projection Screen ..27 Adjustment and Setting by the Menu ....45 Indicator Display ..........78 Adjustment of the Image Quality ......47 INFO ..............
  • Page 82 RS-232C .............. 23 Troubleshooting ........... 65 S Screen Correction ..........30 U User Name Edit ........... 47 Screen Mask ............51 V Viewing 3D Movies ..........32 Screen Size and Projection Distance ....75 Viewing Videos ............ 25 Shadow/Highlight Correction ....... 43 Shift ..............
  • Page 84 © 2013 JVC KENWOOD Corporation 1010TAY-SW-AO...
