Eizo eClient 531L User Manual

Eizo eClient 531L User Manual

Lcd monitor integrated windows-based terminal
Hide thumbs Also See for eClient 531L:
Table of Contents

Advertisement

Quick Links

Download this manual
LCD Monitor integrated
Windows-based Terminal

Touch Panel

LCD Monitor integrated
Windows-based Terminal
Please confirm the version of the software built in eClient, and refer to
the suited User's Manual (Refer to the User's Manual Version List on
next page).
This is the manual for the following software version.
* Microsoft Windows CE: 2.12 Rev.3.53 or later
* Microsoft Terminal Server Client: Ver.5.60 or later
* ICA Client: Ver.6.30 [Build 1078] or later
For Microsoft Windows CE 2.12
Version C
