- Page 1 Instructions for Use CID1300P Panel PC with Touchscreen and Software Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.
-
Page 2: Legal Information
Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Table Of Contents
Logging on as admin .................... 23 7 Operation......................... 24 Switching on / off .................... 24 Touchscreen ...................... 24 8 Cleaning and disinfecting.................... 26 Recommended cleaning agents and disinfectants .......... 26 9 Troubleshooting ...................... 27 10 Technical specifications .................... 28 10.1 Dimension drawing .................... 28 CID1300P Instructions for Use, 02/2023... - Page 4 11 Appendix ......................... 31 11.1 Guidelines and manufacturer's declaration – electromagnetic emissions .... 31 11.2 Warranty ......................... 31 11.3 Repairs ........................ 31 11.4 Environmental protection .................. 31 11.5 Additional devices.................... 31 11.6 Contact ........................ 31 11.7 Manufacturer's information .................. 31 11.8 Trademarks...................... 32 Index .......................... 33 CID1300P Instructions for Use, 02/2023...
-
Page 5: Introduction
1.2 Intended use The CID1300P is a panel PC with touchscreen and appropriate software, and is used as an interface to select and switch among various predefined layouts in the EIZO video manage- ment system, which are then displayed on the corresponding monitors. -
Page 6: Safety Information
2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO devices requires professional transport, storage, instal- lation, and connection, as well as careful operation and servicing. The devices may only be used for applications for which they are intended. - Page 7 Connection in China Only use power cables approved for China. These power cables are identified by the labels “CCC” or “CQC”. Observe the country-specific regulations Observe all regulations of the country in which the device is used. CID1300P Instructions for Use, 02/2023...
- Page 8 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Other- wise, the device could be damaged. CID1300P Instructions for Use, 02/2023...
-
Page 9: Product-Specific Safety Instructions
2.2 Product-specific safety instructions NOTICE Network security The CID1300P has been secured with a BIOS password, blocked network ports, and other security measures. Nevertheless, the CID1300P is based on standard computer and net- work technology. • Make sure the network environment is secure. -
Page 10: Description
Description 3.1 Scope of delivery 3 Description 3.1 Scope of delivery The CID1300P is a panel PC with touchscreen and tailored application software. The scope of delivery consists of the device and supplementary items. Device Product Order number Description Panel PC CID1300P... -
Page 11: Features
Easy to operate The higher resolution and improved touch responsiveness of modern panel PCs provides the new CID1300P with fast and intuitive selection of video sources directly through the view management of the LMM or via “LMM Control”. Integrates easily into the video management system network The introduction of simple input screens means that only basic IT administrator knowledge is required. -
Page 12: Setup And Installation
NOTICE Device connections accessible at all times The power supply connector of the CID1300P is the only way to fully disconnect the panel PC from the power network. • The power supply connection or the cable to the external power supply unit has to be installed such that it is accessible to the user at all times. -
Page 13: Installation In A Vesa Holder
Ensure that such mechanical influences are avoided. Movable installation If the CID1300P is installed such that it can move, make sure that persons or objects in the facility are not endangered by the range of movement of the CID1300P. 4.2 Installation in a VESA holder The Panel PC is installed such that the main interfaces point downward. -
Page 14: Connecting
• Externally connected cables can represent a trip hazard. Make sure that all incoming cables are safely routed. • If the device offers strain relief mechanisms for the cables, use them to prevent unin- tended loosening of connected cables. CID1300P Instructions for Use, 02/2023... -
Page 15: Device Connectors
• On/off switch IT network connector (RJ45) The RJ45 connector is required to connect the CID1300P to the IT network of the video management system. USB ports A USB port can be used to connect a keyboard when configuring the CID1300P. -
Page 16: Connecting To The It Network
Connecting 5.3 Connecting to the IT network Power supply connector The voltage input of the CID1300P is required for the power supply using an external power supply unit. On/off switch The device can be switched on/off with the on/off switch. When doing so, please note that the power supply unit remains energized in standby mode and the device is not fully discon- nected from line power. -
Page 17: Connecting The Power Supply And Switching On
5.5 Connecting the power supply and switching on NOTICE Validated external power supply unit Only power supply units validated by the manufacturer or EIZO, such as the one provided with the device, may be used. Note • EIZO recommends not connecting the power supply until all other connections have been made. -
Page 18: Commissioning
• LMM0804 with the firmware 4.0.0-Extended or higher 6.2 Setup procedure For the CID1300P to be used with the EIZO video management system, it has to be config- ured for access to the LMM and the appropriate network environment. Prerequisite •... - Page 19 ð Windows is installed and you are logged on as “Admin” to the CID1300P. The “Setup” dialog is displayed. 3. DHCP is pre-configured for the network settings of the CID1300P. If you opt to use a static network address, you must Changing the network settings of the CID 1300P [} 20].
-
Page 20: Changing The Network Settings Of The Cid 1300P
6.3 Changing the network settings of the CID 1300P 6.3 Changing the network settings of the CID 1300P The CID1300P is pre-configured to obtain its IP address from a DHCP server. To assign a static IP address to the CID1300P, proceed as follows. - Page 21 – LMM56800: 169.254.213.44:8080 – LMM56800 with current user interface and LMM0801: 169.254.213.144 2. Select “OK” to connect the CID1300P to the LMM under the entered address. If you cannot connect within 30 seconds, the process is interrupted with an error message.
-
Page 22: Entering The Ip Address For Access Via "Lmm Control
• LMM0802 with the firmware 4.0.0-Extended or 4.1.0 or higher • LMM0804 with the firmware 4.0.0-Extended or higher Note Network address Ensure that the network address set in the CID1300P uses the same network prefix and subnet as the LMM, for example, 169.254.213.xxx. Prerequisite Note Open the entry dialog for the new IP address When starting the CID1300P with the “LMM Control”, a preset IP address is automatically... -
Page 23: Changing The Application For Access To The Lmm
1. Enter the current network address of the LMM as the “IP address”. Ask the network ad- ministrator if necessary. 2. Select “OK” to connect the CID1300P to the LMM under the entered address. If you cannot connect within 30 seconds, the process is interrupted with an error message. -
Page 24: Operation
Full separation from line power To fully separate the CID1300P from line power, the power cable of the power supply unit must be disconnected from the line power. Either pull the power cable plug from the line power socket or use a switch-disconnector. - Page 25 Operation 7.2 Touchscreen Perform the following operations on the touchscreen of the CID1300P in an LMM system: • Select the active layout from the predefined layouts. • Select the video sources and assign the output to the monitor. Note Additional information regarding View Management and other topics can be found in the instructions for use for the LMM.
-
Page 26: Cleaning And Disinfecting
Tap water Distilled water Cleaning agent Ammonium solution 1.65 vol% Alkaline solution Limewash, saturated Ca(OH) -solution Note Information on cleaning or disinfection of other system components can be obtained from the respective instructions for use. CID1300P Instructions for Use, 02/2023... -
Page 27: Troubleshooting
To ensure proper and safe operation of the device, the ambient temperature must remain within the permissible ambient temperature range. • Observe the information from the panel PC manufacturer. Note Observe the troubleshooting information in the manufacturer’s panel PC instructions for use. CID1300P Instructions for Use, 02/2023... -
Page 28: Technical Specifications
Medical grade power supply unit (FSP Technology Int. / FSP065M- DBA(9NA0656405)) Input: AC 100V to 240V, 47–63 Hz; output: DC 19V, 3.43A Complies with the following certifications: • IEC 60601-1 • ANSI/AAMI ES60601-1 • CAN/CSA-C22.2 no. 60601-1 CID1300P Instructions for Use, 02/2023... -
Page 29: Power Supply
Audio connector supports: • 1x microphone input • 1x loudspeaker output 10.6 Certificates, approvals, and standards Note Refer to the manufacturer’s panel PC instructions for use for information on the certifi- cates, approvals, and standards. CID1300P Instructions for Use, 02/2023... -
Page 30: Electromagnetic Compatibility (En60601-1-2)
10.7 Electromagnetic compatibility (EN60601-1-2) 10.7 Electromagnetic compatibility (EN60601-1-2) Secure network with CID1300P If a network of electrical devices is operated, the user is responsible for ensuring that the entire system meets the requirements of the following guidelines for medical electrical de-... -
Page 31: Appendix
Support during installation and for technical questions www.eizo-or.com 11.7 Manufacturer's information EIZO is the distributor of the CID1300P. Additional information on the device hardware is available in the manufacturer's instructions for use. The CID1300P name plate contains the name of the manufacturer. -
Page 32: Trademarks
ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, Radi- Force, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corpora- tion in Japan and other countries. -
Page 33: Index
Index Index Ambient temperature 12, 27 Contact 31 Dimensions 28 Disposal 31 Environment 12 General safety instructions 6 Keyboard 16 Keyboard layout 16 Shielding measures 14 Target address 20 Warranty 31 CID1300P Instructions for Use, 02/2023... - Page 34 Distributed by: Carl-Benz-Straße 3 76761 Rülzheim Germany Instructions for Use, 02/2023 CID1300P Copyright © 2023 EIZO GmbH. All rights reserved. 1086250-002...
