Page 1
00653T-00_COVER.qxd 12/23/04 5:34 PM Page 1 LN32A32B TFT-LCD TELEVISION Owner’s Instructions This device is a Class B digital apparatus. BN68-00653T-00...
Page 2
653T-still Eng.qxd 11/26/04 10:43 AM Page 1 Precautions When Displaying a Still Image A still image may cause permanent damage to the TV screen. • Digital Ready TV: When you Although digital broadcasting must be in the select the regular screen (4:3) wide screen (16:9) HD format, broadcasters mode to watch an SD-grade sometimes show programs made originally...
Page 3
653T-still Eng.qxd 11/26/04 10:43 AM Page 2 • Integrated Digital TV Although digital broadcasting must be in the (Wide-screen): When the TV wide screen (16:9) HD format, broadcasters receives SD-grade (regular) sometimes show programs made originally broadcasting signals (receives in the regular screen format (4:3) by 480p regular signals).
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 1 C h a p t e r O n e O U R List of Features My Color Control: Colors can be set to your preference by adjusting pink, blue and green. Dynamic Contrast: Automatically detects the input visual signal and adjusts to create optimum contrast.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 2 O U R Familiarizing Yourself with Your New TV Right-Side Panel Buttons The buttons on the Right-side panel control your TV’s basic features, including the on- screen menu. To use the more advanced features, you must use the remote control. (POWER) SOURCE Press to turn the TV on and off.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 3 O U R Rear Panel Jacks Use the rear panel jacks to connect an A/V component that will be connected continuously, such as a VCR or a DVD player. For more information on connecting equipment, see pages 7-14. HDMI IN COMPONENT IN 2 Supports connections between HDMI-...
When using the remote, always point it directly at the TV. When using the remote, always point it directly at the TV. You can also use your remote control to operate your VCR, Cable box, DVD player or Samsung Set-top box. POWER MODE Turns the TV on and off.
Page 10
(See page 29) SET BUTTON ADD/DEL Adjusts 5 separate devices - TV, Use to store and delete channels VCR, Cable, DVD, or Samsung to/from memory. (See page 30) Set-top box. DNIe (See pages 23~26) Press to improve the digital video quality.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 6 O U R Installing Batteries in the Remote Control Slide the cover out completely. Make sure to match the “ ” and – “ ” ends of the batteries with the Install two AAA size diagram inside the compartment.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 7 C h a p t e r Tw o N S TA L L AT I O N Connecting VHF and UHF Antennas If your antenna has a set of leads that look like this, see “Antennas with 300-ohm Flat Twin Leads”...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 8 N S TA L L AT I O N Antennas with 75-ohm Round Leads Plug the antenna lead into the ANT IN terminal on the bottom of the back panel. Separate VHF and UHF Antennas If you have two separate antennas for your TV (one VHF and one UHF), you must combine the two antenna signals before connecting the antennas to the TV.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 9 N S TA L L AT I O N Connecting to a Cable Box that Descrambles All Channels This terminal might be labeled “ANT OUT”, “VHF OUT” or Find the cable that is simply, “OUT”.
Page 15
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 10 N S TA L L AT I O N Connect an RF cable between the ANT OUT terminal on the cable box and the B–IN terminal on the A/B switch. Connect another cable between the other OUT terminal on the splitter and the A–IN terminal on...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 11 N S TA L L AT I O N Connecting HDMI Supports connections between HDMI-connection-enabled AV devices (Set Top boxes, DVD players, AV receivers and digital TVs). Connect HDMI cable from the TV to the input terminal of the HDMI device.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 12 N S TA L L AT I O N Connecting a VCR These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the instructions on pages 7-10). Skip step 1 if you have not yet connected to an antenna or a cable system.
N S TA L L AT I O N Connecting an S-VHS VCR Your Samsung TV can be connected to an S-Video signal from an S-VHS VCR. (This connection delivers a better picture as compared to a standard VHS VCR.) To begin, follow steps 1–3 in the...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 14 N S TA L L AT I O N Connecting a DVD Player The rear panel jacks on your TV make it easy to connect a DVD player to your TV. Connect an audio cable between the COMPONENT1 or COMPONENT2...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 15 N S TA L L AT I O N Connecting a PC - Connect the D- Sub cable to “PC (PC IN)” on the rear of your set. - Connect the stereo audio cable to “AUDIO (PC IN)” on the rear of your TFT-LCD and the other end to “Audio Out”...
Please refer to Anynet AV Owner’s Instructions’ that is provided separately for the detailed information on Anynet. 1.What is the Anynet? Anynet is an AV network system that enbles you to easily control Samsung audio-video (AV) devices from your through the Anynet menu via a Samsung TV. [ Anynet Features and Benefits ] •...
Page 17 N S TA L L AT I O N 2.Anynet 1. Anynet System is available only for Samsung Anynet-supported AV devices. 2. See below for Anynet-supported devices. (All devices except for 2 and 4 are soon to be added)
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 18 N S TA L L AT I O N 3. Connecting TV + DVD/VCR Combo: Connecting AV Signal Cables How to Connect the Cables (Connect in the order of numbers shown in the diagram.) 1.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 19 N S TA L L AT I O N 4. Connecting TV + DVD Receiver: Connecting AV Signal Cables How to Connect the Cables (Connect in the order of numbers shown in the diagram.) 1.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 20 N S TA L L AT I O N 5. Connecting TV + DVD Combo + DVD Receiver: Connecting AV Signal Cables How to Connect the Cables. (Connect in the order of numbers shown in the diagram.) 1.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 21 C h a p t e r T h r e e P E R AT I O N Turning the TV On and Off Press the POWER button on the remote. You can also use the Power button on the front panel. Changing Channels Using the Channel Buttons Press the CH...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 22 P E R AT I O N Viewing the Display The display identifies the current channel and the status of certain audio-video settings. The on-screen displays disappear after about ten seconds. Press the INFO button on the Press the INFO button once more remote control.
After it has been set up properly, your remote control can operate in five different modes: TV, VCR, Cable, DVD or Samsung Set-top box. Pressing the corresponding button on the remote control allows you to switch between these modes, and control whichever piece of equipment you choose.
Page 29
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 24 P E R AT I O N Setting Up the Remote to Operate Your Cable Box Turn off your cable box. Press the MODE button and make sure that the CATV appears on the LCD screen. Press the SET button on your TV's remote control using a small pointed object.
Page 30
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 25 P E R AT I O N Setting Up the Remote to Operate Your DVD Setting Up the Remote to Operate Your DVD Turn off your DVD. Press the MODE button and make sure that the DVD appears on the LCD screen.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 27 P E R AT I O N Plug & Play Feature When the TV is initially powered on, two basic customer settings proceed automatically and subsequently: Setting Auto program, Clock. Press the POWER button on the remote control.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 28 P E R AT I O N Memorizing the Channels Your TV can memorize and store all of the available channels for both “off-air” (antenna) and cable channels. After the available channels are memorized, use the CH and CH buttons to scan through the channels.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 29 P E R AT I O N Storing Channels in Memory (Automatic Method) First, select the correct signal source (Air, STD). See steps 1~2 on previous page. Press the UP/DOWN buttons to select “Auto Program”.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 30 P E R AT I O N Adding and Erasing Channels (Manual Method) Use the number buttons to directly select the channel to Add or Delete. Press the MENU button to display the menu. Press the UP/DOWN but- tons to select “Channel”, then...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 31 P E R AT I O N To set-up your Favorite Channels Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Channel”, then press the ENTER button. Press the UP/DOWN buttons to select “Favorite Channel”, then press the ENTER...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 32 P E R AT I O N To Edit the Input Source Name Name the input device connected to the input jacks to make your input source selection easier. Press the MENU button to display the on-screen menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 33 P E R AT I O N Using Automatic Picture Settings Your TV has four automatic picture settings (“Dynamic”, “Standard”, “Movie”, and “Custom”) that are preset at the factory. You can activate either Dynamic, Standard, Movie, or Custom by pressing P.MODE (or by making a selection from the menu).
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 34 P E R AT I O N Customizing the Picture You can use the on-screen menus to change the contrast, brightness, sharpness, color and tint according to personal preference. (Alternatively, you can use one of the “automatic” settings. See the previous page.) Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 35 P E R AT I O N Using Automatic Sound Settings Your TV has five automatic sound settings (“Standard”, “Music”, “Movie”, “Speech”, and “Custom”) that are preset at the factory. You can select “Equalizer”, which automatically recalls your personalized sound settings.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 36 P E R AT I O N Customizing the Sound The sound settings can be adjusted to suit your personal preference. (Alternatively, you can use one of the “automatic” settings. See the previous page.) Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 37 C h a p t e r F o u r P E C I A L E AT U R E S Selecting a Menu Language Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Setup”, then press the ENTER...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 38 P E C I A L E AT U R E S Setting the Blue Screen Mode If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture background.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 39 P E C I A L E AT U R E S Fine Tuning Channels Use fine tuning to manually adjust a particular channel for optimal reception. Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Channel”, then press the ENTER...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 40 P E C I A L E AT U R E S LNA (Low Noise Amplifier) If the TV is operating in a weak-signal area, sometimes the LNA function can improve the reception (a low-noise preamplifier boosts the incoming signal). Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 41 P E C I A L E AT U R E S Viewing Picture-in-Picture You can use the PIP feature to simultaneously watch two video sources. Activating Picture-in-Picture Quick way to access the PIP menu: Press the MENU button Simply press the PIP...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 42 P E C I A L E AT U R E S Selecting a Signal Source (External A/V) for PIP Press the UP/DOWN buttons to select “Source”, then press the ENTER button. Select a source of the sub picture by pressing the UP/DOWN buttons and...
Page 43 P E C I A L E AT U R E S DNIe (Digital Natural Image engine) Samsung’s New Technology brings you more detailed images with contrast, white enhancement and 3D noise reduction. Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 44 P E C I A L E AT U R E S My Color Control My Color Control is to adjust the most preferred colors such as Blue, Green, Pink without interfering with other colors in order for each consumer to enjoy screen color of their choice.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 45 P E C I A L E AT U R E S Detail Control You can adjust Pink, Green and Blue without using the Press the MENU button to predefined settings in custom display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 46 P E C I A L E AT U R E S Dynamic Contrast Dynamic Contrast detects the visual signal input and adjusts to create optimum contrast. Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Picture”, then press the ENTER...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 47 P E C I A L E AT U R E S Brightness Sensor The Brightness Sensor adjusts the screen brightness automatically by using a light detecting sensor. Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 48 P E C I A L E AT U R E S Changing the Screen Size Only wide and size of 4:3 can be selected for PC Press the P.SIZE button to change the screen size. Source.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 49 P E C I A L E AT U R E S Adjusting the Color Tone You can change the color of the entire screen according to your preference. Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 50 P E C I A L E AT U R E S Setting the TruSurround XT (SRS TSXT) Emphasizes midrange and bass and provides a simulated surround-sound experience. Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 51 P E C I A L E AT U R E S Automatic Volume Control Reduces the differences in volume level among broadcasters. Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Sound”, then press the ENTER button.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 52 P E C I A L E AT U R E S Special Sound Options Choosing a Multi-Channel Sound (MTS) Soundtrack Depending on the particular program being broadcast, you can listen to stereo, mono, or a Separate Audio Program.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 53 P E C I A L E AT U R E S Adjusting the Headphone Sound The headphone option is especially useful when simultaneously watching the main screen and the PIP window. Headphones must be purchased separately.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 54 P E C I A L E AT U R E S Selecting the Main or Sub Sound You can select either Main or Sub when PIP is On. Press the MENU button to display the menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 55 P E C I A L E AT U R E S Subwoofer The TV provides an output for hookup to an active (powered) subwoofer. Press the MENU button to display the on-screen menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 56 P E C I A L E AT U R E S Setting the Clock Setting the clock is necessary in order to use the various timer features of the TV. Also, you can check the time while watching the TV. (Just press the INFO button). Press the MENU button to display the on-screen...
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 57 P E C I A L E AT U R E S Setting the On/Off Timer Before using the timer, you must set the TV’s clock. (See “Setting the Clock” Press the MENU button to display the on-screen on page 56)
Page 63
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 58 P E C I A L E AT U R E S To deactivate the “On Timer,” select “Off” during this step. Press the LEFT/RIGHT buttons to select “Setup”. Press the UP/DOWN buttons to On Timer “On”.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 59 P E C I A L E AT U R E S Setting the Sleep Timer Set the timer for the TV to turn off at the preset time automatically. Sleep timer Press the MENU button to display the on-screen menu.
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 60 P E C I A L E AT U R E S Viewing Closed Captions Your TV decodes and displays the closed captions that are broadcast with certain TV shows. These captions are usually subtitles for the hearing impaired or foreign-language translations. All VCRs record the closed caption signal from television programs, so home-recorded video tapes also provide closed captions.
Page 66
653T-01-82 Eng.qxd 11/26/04 10:16 AM Page 61 P E C I A L E AT U R E S Press the UP/DOWN buttons to select “Mode”, then press the ENTER button. Press the UP/DOWN buttons to set “Cation” or “Text”, then press the ENTER button.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 62 P E C I A L E AT U R E S Color Weakness This feature enables those with color weakness to view images as those with normal color vision do. The feature provides nine different color adjustment layers for red, green and blue.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 63 P E C I A L E AT U R E S Selecting the Melody You can hear a melody sound when the television is powered on or off. Press the MENU button to display the on-screen menu.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 64 P E C I A L E AT U R E S Activating the Child Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by muting out video and audio. Child Lock cannot be released using front panel buttons.
Page 70
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 65 P E C I A L E AT U R E S Press the UP/DOWN buttons to select “Channel”, then press the ENTER button. Press the UP/DOWN buttons to select the channels to lock. Press the ENTER button.
Windows and your particular video card. Even if your actual screens look different, the same, basic set-up information will apply in most cases. (If not, contact your computer manufacturer or Samsung Dealer). First, click on “Control Panel” on the Windows start menu.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 67 PC D I S P L AY How to Auto Adjust Use the Auto Adjust function to have the TV set automatically adjust the video signals the monitor receives. The function also automatically fine-tunes the settings and adjusts the frequency values and positions.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 68 PC D I S P L AY Adjusting the Screen Quality The purpose of the picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by fine tuning alone, then do the frequency adjustments to the utmost and fine tune again.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 69 PC D I S P L AY Changing the Screen Position Press the PC button on the remote control to select the PC mode. Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Setup”, then press the ENTER button.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 70 PC D I S P L AY Initializing the Screen Position or Color Settings Press the PC button on the remote control to select the PC mode. Press the MENU button to display the menu. Press the UP/DOWN buttons to select “Setup”, then press the ENTER...
R O U B L E S H O O T I N G If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, call your nearest Samsung service center. Identifying Problems...
Page 77
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 72 R O U B L E S H O O T I N G Problem Possible Solution “Not Supported Mode PC” Check the maximum resolution and the frequency of message. the Video Adapter. Compare these values with the data in the Display Modes Timing Chart.
Page 78
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 73 R O U B L E S H O O T I N G Problem Possible Solution The Anynet does not function. Check to see if the device is an Anynet device. The Anynet System supports only Anynet-enabled devices. The Anynet System supports up to one device from the Receiver product group and two devices from the DVD product group.
Page 79
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 74 R O U B L E S H O O T I N G Problem Possible Solution I would like to turn the Press the [Power] button on the TV remote control while using Anynet device off.
Page 80
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 75 R O U B L E S H O O T I N G Problem Possible Solution See if there are Anynet devices connected. The Anynet System supports only Anynet devices. Check to see if the Anynet devices connected are plugged in properly.
Page 81
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 76 R O U B L E S H O O T I N G Problem Possible Solution Make sure that the devices connected support the Anynet. Remove devices from the new Anynet product groups that are not supported by the Anynet version currently running on your TV.
Page 82
R O U B L E S H O O T I N G Glossary Content The Anynet System A system that allows controlling Samsung AV devices from the TV. Watch TV Broadcast When selected, this Anynet menu item automatically executes the steps involved in watching TV broadcasts on TV.
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 78 P P E N D I X Installing the Stand <1> <2> Lower the TV set in the direction of the arrow and fix the stand. Use the four screws to tightly fix the stand. Maintenance of Your LCD TV WARNING: To avoid risk of electric shock, do not disassemble the TV cabinet (except for gaining access to the cable connectors as described on Chapter 2).
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 79 P P E N D I X Installing the Wall Mount Kit Note: This installation is to be used when attaching the wall mount to a concrete wall. When attaching to other building materials, please contact your nearest dealer. Components (Sold separately) M4 X L15 M4 X L20...
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 80 P P E N D I X Cleaning and Maintaining Your TV With proper care, your TV unit will give you many years of service. Please follow these guidelines to get the maximum performance from your TV. Placement •...
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 81 P P E N D I X Specifications Model Name LN32A32B Panel Size 32” Diagonal Display Size (HxV) 27.06 x 16.24 inches (687.36 x 412.42 mm) Type a-si TFT active matrix Pixel Pitch 0.021(H) x 0.021(V) inches (0.537(H) x 0.537(V) mm) Viewing Angle 170/170 (H/V)
653T-01-82 Eng.qxd 11/26/04 10:17 AM Page 82 P P E N D I X Display Modes If the signal from the system equals the standard signal mode, the screen is adjusted automatically. If the signal from the system doesn’t equal the standard signal mode, adjust the mode by referring to your videocard user guide;...
