- Page 1 DVD-VCR DVD-V7500 Instruction Manual ANGLE AUDIO OPEN/CLOSE EJECT STANDBY/ON SELECT COPY PROG LINE IN 2 VIDEO AUDIO www.samsung.com.au...
-
Page 2: Table Of Contents
Contents Contents (cont.) OREWORD Disc Type and Characteristics............... LAYING Playing a Cassette..................DVD-VCR O VERVIEWS Adjusting Picture Alignment Automatically ............ Front View of the DVD-VCR ................Adjusting Picture Alignment Manually ............Rear View of the DVD-VCR................Selecting the Audio Output Mode..............Infrared Remote Control ................ -
Page 3: Safety Instructions
Contents Safety Instructions (cont.) The following illustrations represent precautions. OLVING ROBLEMS Technical Specifications ................Problems and Solutions (VCR)..............Troubleshooting Guide (DVD) ............... The lightning bolt is a warning sign alerting you to dangerous voltage inside the product. DO NOT OPEN THE DVD-VCR. Refer to service personnel. This product incorporates copyright protection technology that is protected by method claims of certain U.S. -
Page 4: Disc Type And Characteristics
Disc Type and Characteristics Front View of the DVD-VCR This DVD player is capable of playing the following types of discs with the corresponding logos : STANDBY/ON DVD DECK VIDEO CASSETTE DVD/VCR SELECT COPY EJECT OPEN/CLOSE BUTTON COMPARTMENT BUTTON BUTTON BUTTON BUTTON Max. -
Page 5: Infrared Remote Control
31 MARK, INDEX Accessories 32 DIGEST 33 JOG DIAL 34 SHUTTLE DIAL You have just purchased a SAMSUNG Video Cassette Recorder (DVD-VCR). Together with your DVD-VCR, you will find the following accessories in the box. REMOTE CONTROL AUDIO & VIDEO OWNER’S COAXIAL CABLE &... -
Page 6: Deciding How To Connect Dvd-Vcr
Deciding How to Connect DVD-VCR Connecting DVD-VCR to the TV using the Coaxial Cable To receive television programmes a signal must be received from one of the following sources: You must take into account various factors when connecting audio or video systems: An outdoor aerial An indoor aerial DVD &... -
Page 7: Connecting Other Equipment To Your Dvd-Vcr
Connecting Other Equipment to Your DVD-VCR Plug & Auto Set Up Your DVD-VCR will automatically set itself up when it is plugged You can connect other audio and/or video equipment to your DVD-VCR in different ways. The following into the mains for the first time. TV stations will be stored in illustrations give a few examples of the connection possibilities. -
Page 8: Tuning Your Television For The Dvd-Vcr
Tuning Your Television for the DVD-VCR Deck Control Keys The DVD-VCR uses one set of controls to operate both decks. The following keys are helpful in successfully controlling each deck. You must tune your television for the DVD-VCR only if you are not using a RCA cable STANDBY/ON Button To view pictures from your DVD-VCR when a RCA cable... -
Page 9: Copying From Dvd To Vcr
Copying from DVD to VCR Inserting Batteries in the Remote Control You must insert or replace the batteries in the remote control when you: The DVD-VCR allows you to copy the contents of a DVD to a VHS tape with a press of the COPY button. Purchase the DVD-VCR Find that the remote control is no longer working If the DVD you are attempting to copy is copy... -
Page 10: Menu Language
Menu Language Open “MAIN MENU” With the DVD in stop mode, press the SETUP button. Set “Language” Using the Up/Down and Left/Right buttons, move the selection arrow to Language set then press ENTER button. Set menu Language Move the selection bar to your desired Language, then press ENTER button. -
Page 11: Presetting The Stations Automatically
Presetting the Stations Automatically You do not need to preset the stations if you have already MAIN MENU set them automatically (see Plug & Auto Set Up on page 13). Option Language Your DVD-VCR contains a built-in tuner used to receive television broadcasts. -
Page 12: Presetting The Stations Manually
Presetting the Stations Manually Clearing a Preset Station You do not need to preset the stations manually if you If you have stored a TV station: have already set them automatically. That you do not require MAIN MENU Press the SETUP button on the remote control. At the wrong programme position Result: The MAIN MENU is displayed. -
Page 13: Changing The Preset Station Table
Changing the Preset Station Table Setting the DVD-VCR Output Channel You can rearrange the Station Table and give different programme Your DVD-VCR output channel may need to be changed if the numbers to the stations listed according to your own preferences. pictures suffer from interference or if your TV cannot find the Australia Model pictures. -
Page 14: Selecting The Colour Mode
Selecting the Colour Mode Intelligent Picture Control Before recording or playing back a cassette, you can select the required system standard. The Intelligent Picture Control Feature allows you to adjust the Australia Model sharpness of the image automatically, according to your own Otherwise, the system automatically selects the reception standard preferences. -
Page 15: Auto Power Off
Auto Power Off Selecting the Cassette Type The Auto Power Off feature automatically turns off your DVD-VCR If you wish to use the tape counter to display the time remaining on Australia Model if no signal is received and you do not press any button for the a cassette, you must indicate the type of cassette inserted. -
Page 16: Displaying/Hiding On-Screen Information
Displaying/Hiding On-Screen Information Protecting a Recorded Cassette Your DVD-VCR displays most information both on the DVD-VCR Video cassettes have a safety tab to prevent accidental erasure. and the television. MAIN MENU When this tab has been removed, you cannot record on the tape. You can choose to display or hide this information on the television screen (except for the Index, MAIN MENU and Option... -
Page 17: Recording A Programme With Automatic Stop
Recording a Programme with Automatic Stop Using the G-CODE Feature Before presetting your DVD-VCR: This function enables you to record up to nine hours (LP) of programmes. Switch on both the television and your DVD-VCR Your DVD-VCR stops automatically after the requested length of Check that the date and time are correct time. -
Page 18: Modifying G-Code Programming
Using the Timer Programming Feature Modifying G-CODE Programming The Timer Programming feature allows you to preset the DVD-VCR to record a programme up to one month before that programme is If you wish to correct the programme displayed or modify certain elements, such as the recording to be broadcast. -
Page 19: Checking A Preset Recording
Checking a Preset Recording Playing a Cassette This function allows you to play back any pre-recorded cassette. You can check your preset recordings: When you have finished presetting the DVD-VCR Switch on both the television and your DVD-VCR. If you have forgotten which programmes will be Insert the video cassette to be played. -
Page 20: Selecting The Audio Output Mode
Selecting the Audio Output Mode Playing a Sequence Frame by Frame You can: You can select the mode in which the sound is reproduced on the Stop the cassette at a given frame (image) loudspeakers and AV outputs. The following options are available. Advance one frame at a time No sound is heard when playing back frame by frame. -
Page 21: Picture Search, Fast Forward/Rewind
Picture Search, Fast Forward/Rewind Using the Tape Counter Picture Search enables you to Fast Forward or Rewind and look for a particular part of a tape. The tape counter: Press PLAY, the VCR will enter normal play mode. While in play, Indicates the elapsed time in the play and record modes ❿... -
Page 22: Connecting An Rca Audio/Video Input Cable
Connecting an RCA Audio/Video Input Cable Using the Assemble Edit Function This function allows you to start a new recording at a specific You can connect other audio/video equipment to your DVD-VCR position on the cassette while maintaining a very smooth scene using audio/video cables if the appropriate outputs are available on change. -
Page 23: Audio Dubbing A Pre-Recorded Cassette
Audio Dubbing a Pre-recorded Cassette Using the TV Buttons on the Remote Control Your DVD-VCR remote control will work with Samsung televisions and compatible brands. With the Audio Dubbing function, you erase the previously recorded sound and replace it with a new soundtrack from:... -
Page 24: Sqpb (Super Vhs Quasi Playback)
SQPB (Super VHS Quasi Playback) Choosing a Connection This function is for playback of Super VHS format tapes only, not for recording. The following show examples of connections commonly used to connect the DVD player with a TV ANGLE AUDIO and other components. -
Page 25: Playing A Disc
Playing a Disc Using the Search & Skip Functions Before Playback : During playback, you can search quickly through a chapter or track Turn on a TV and press the TV/VIDEO button to select or use the skip function to jump to the next selection. video mode. -
Page 26: Using The Dvd Setup
Using the DVD Setup Using the Disc Menu Language The Setup menu lets you customize your DVD player by allowing This function changes the text language only on the disc menu you to select various language preferences, set up a parental level, screens. -
Page 27: Setting Up The Audio Language Features
Setting Up the Parental Control Setting Up the Audio Language Features MAIN MENU Using the Audio Language: MAIN MENU The Parental Control function works in conjunction with DVDs that Option Language have been assigned a rating - which helps you control the types of Option Language With the unit in Stop mode, press the SETUP button on the remote. -
Page 28: Setting Up The Audio Options
Setting Up the Audio Options Setting Up the Display Options With the unit in Stop mode, press the SETUP button on the remote. With the unit in Stop mode, press the SETUP button on the remote. Result: The MAIN MENU is displayed. Result: The MAIN MENU is displayed. -
Page 29: A/V Receiver Connections
A/V Receiver Connections Special Playback Features During DVD/CD playback you can select from the following To take full advantage of the movie theater experience that DVD ❿ offers, you may want to connect your DVD-VCR to a complete special playback options. To resume normal playback, press the Surround Sound system, including an A/V Receiver and six (Play/Still) button. -
Page 30: Using The Display Function (Dvd/Vcd/Cd)
Using the Display Function (DVD/VCD/CD) When Playing a DVD During play, press the DISPLAY button on the remote. - Current title, chapter number, elapsed time, audio and subtitle will be displayed. T : 01 • Use the NUMBER buttons to enter a different title, then ➛❿... -
Page 31: Repeat Play
Repeat Play Repeat the current track, chapter, title, a chosen section (A-B), or all of the disc. Press the REPEAT button on the remote. Repeat screen appears. Select Chapter, Title or A-B using the ➛ or ❿ buttons. - Repeat A-B •... -
Page 32: Program Play (Dvd/Vcd/Cd)
Program Play (DVD/VCD/CD) SCREEN FIT Play During play, press SCREEN FIT button on remote control. Press the MODE button. - Allows you to eliminate the black bars in the top and bottom of Use the ➛ or ❿ buttons to select PROGRAM. Press the ENTER the screen when a movie is playing in the Widescreen button. -
Page 33: Digest Play
Digest Play Using the Disc View Function (Track View VCD) Displays the beginning view of each track and the track number. During play, press the DIGEST button. During play, press the TITLE button. - You'll see the 9 individual windows representing each of the chapters on the TV screen. -
Page 34: Selecting The Audio Language (Using The Audio Button)
Selecting the Audio Language (Using the Audio button) Changing the Camera Angle You can select a desired language quickly and easily with the When a DVD contains multiple angles of a particular scene, AUDIO button. you can select the Angle function. Press the AUDIO button. -
Page 35: Recalling A Marked Scene
Using the Bookmark Function (DVD/VCD) Using the Zoom (DVD/VCD) The Bookmark function lets you select parts of a DVD or VCD (MENU OFF mode) so that you can quickly find the section at a During play or still mode, press the ZOOM button on the remote. A later time. -
Page 36: Mp3 Play
MP3 Play MP3 Play ( CD-R MP3 disc requirements) When an MP3 Disc is inserted into the DVD-VCR, the first song file of the first folder plays. When playing CD-R MP3 discs, please follow the recommendations below: Total : 3 Press STOP to stop playback of the first song file, then press music c1 1 music c1... -
Page 37: Technical Specifications
Technical Specifications Problems and Solutions (VCR) Before contacting the Samsung after-sales service, perform the following simple checks. Problem Explanation/Solution Rated voltage 220 - 240V~, 50Hz No power Check that the power plug is connected to a wall outlet. Power consumption... - Page 38 Go to the contents and find the section of the instruction book that If you experience other contains the explanations regarding the current problem, and follow problems. the procedure once again. If the problem still cannot be solved, please contact your nearest authorized service center. www.samsung.com.au AK68-00043B (02)
