Page 1 OWNER’S INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’UTILISATION MANUAL DE INSTRUÇÕES ISTRUZIONI PER L'USO AZ09FASEA AZ09AASEA AZ09FAJEA AZ09AAJEA AZ12FAJEA AZ12AAJEA AZ18FAMEA AZ18AAMEA AZ18FAMEB AZ18AAMEB AZ22FAMEA AZ22AAMEA AZT18FAMEA AZT18AAMEA AZT24FAMEA AZT24AAMEA Window-type Room Air Conditioner ( Cool and Heat ) Acondicionador de aire doméstico sistema de tipo ventana ( Refrigeración y Calefacción ) Climatiseur de type Fenêtre ( Refroidissement et Chauffage )
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when installing and using your air conditioner. The air conditioner must be plugged into its own specific power source, which must be installed in compliance with national wiring, earthing and safety regulations. Depending on national regulations and your specific installation, you may need to install: A circuit breaker For further information on electrical requirements, contact a professional electrician.
Page 3: Table Of Contents
Contents REPARING ONDITIONER Safety Precautions ..................Air Conditioning Unit - Main Parts, Buttons and Display ....... Remote Control Buttons ................. Getting Started ....................Inserting the Remote Control Batteries ............PERATING ONDITIONER Cooling Your Room ..................Heating Your Room ..................Airing Your Room ................... 10 Adjusting the Air Flow Direction Horizontally ..........
Page 4: Air Conditioning Unit - Main Parts, Buttons And Display
Air Conditioning Unit - Main Parts, Buttons and Display The design and shape are subject to change according to the model. Inner air flow blades (right/left orientation) Air outlet Air inlet (inside) Outer air flow blades (up/down orientation) Air filter (The air filter is Air inlet (Outside) located inside)
Page 5: Remote Control Buttons
Remote Control - Buttons Timer setting button Temperature adjustment buttons Sleep timer setting button Operating mode Fan speed adjustment selection buttons buttons Air flow blade swing button ON/OFF button...
Page 6: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contain valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s functions. This Owner’s Instructions is just for using your air conditioner correctly.
Page 7: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when: You purchase the air conditioner The remote control does not work correctly Use two AAA, LR03 1.5 V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used.
Page 8: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to lower the temperature in your room. You can also set the fan speed. Remote Control Control Panel If necessary, press the (On/Off) button. Result: The operating mode indicator (COOL, FAN or HEAT) on the unit comes on.
Page 9: Heating Your Room
Heating Your Room You must select the Heat mode if you wish to heat your room to a specific temperature. You can also set the fan speed. Remote Control Control Panel If necessary, press the (On/Off) button. Result: The operating mode indicator (COOL, FAN or HEAT) on the unit comes on.
Page 10: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air it using the Fan feature and if necessary, evacuate the stale air outside. If you wish to evacuate stale air outside, push the ventilation lever on the front of the unit to the right and the open position ( Result: The air inside the room circulates and stale air is evacuated outside.
Page 11: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the Remote Control Control Panel unit, thus increasing the efficiency of the air conditioner. Press the on the unit) button on the remote control.
Page 12: Setting The On Timer
Setting the On timer The On Timer enables you to switch on the air conditioner automatically after a given period time. You can set the period of time from 1 hour to 24 hours. You can set the period of time from 1 hour to 24 hours. Remote Control Control Panel You can select the On timer only when the air conditioner is off.
Page 13: Setting The Off Timer
Setting the Off Timer The Off Timer enables you to switch off the air conditioner automatically after a given period of time. You can set the period of time from 1 hour to 24 hours. Remote Control Control Panel You can select the Off timer only when the air conditioner is on. Check that the air conditioner has been switched on;...
Page 14: Setting The Sleep Timer
Setting the Sleep timer The Sleep Timer can be used when you are cooling or heating your room to switch the air conditioner off automatically after a period of 8 hours. Remote Control Control Panel If you wish to switch the unit off at a specific time, refer to page 13. Make sure that you have selected either COOL or HEAT mode.
Page 15: Recommendations
Operating Recommendations Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation Heating performances The heat pump inside the air conditioner absorbs heat from outside air and brings it indoors. If the temperature of the outside air drops, the air conditioner will heat less.
Page 16: Temperature And Humidity Ranges
Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges within which the air conditioner can be used. Mode Indoor Temperature Outdoor Temperature Indoor Humidity Cooling 21°C to 32°C approx. 21°C to 43°C approx. 80% or less Heating 28°C or less 0°C to 21°C approx.
Page 17: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner models) Be sure to clean the air filter periodically to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out IMPORTANT the power plug.
Page 18 Cleaning Your Air Conditioner models) Be sure to clean the air filter periodically to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out the power plug.
Page 19: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary call. Problem Explanation/Solution The air conditioner does not Check that the circuit breaker used for the air conditioner has not been operate at all triggered.
Page 20: Method Of Installation
Method of Installation Before installation, be sure to check the installation area or the air conditioner, and drain hose. Checkpoints prior to installation Check the cabinet and front grille of the unit for any harmful defects such as scratches. Be sure to check the power supply. - Refer to the specifications on the label attached to the unit.
Page 21 Installation of the Drain Tube Rear Fix the drain tube as shown in the figure. Rubber cap Gasket Drain Tube Screws(2EA) Installation of the Drain Pan The procedure for installing the drain pan should be determined by the condition of the installing area. In the case of an area where the drain pan can not be directly installed on the rear side of the unit after installing the air conditioner.
Page 22 THIS AIR CONDITIONER IS MANUFACTURED BY: ESTE ACONDICIONADOR DE AIRE HA SIDO FABRICADO POR: CE CLIMATISEUR EST FABRIQUÉ PAR: ESTE APARELHO DE AR CONDICIONADO É FABRICADO POR: QUESTO CONDIZIONATORE D’ARIA È PRODOTTO DA: Printed in Korea...
