- Page 1 VZ-7000P VZ-7000N 7-Inch WIDE TELEVISION INSTALLATION MANUAL © PRINT IN JAPAN B54-4356-00 (M/H)(+) 03/12 11 10 9 8 7 6 5 4 3 2 1 02/12 11 10 9 8 7 6 5 4 3...
-
Page 2: Installation Procedure
Accessories External view External view ..Number of items ..Number of items ..1 ..2 (M4 × 6mm) ..2 ..4 ..1 ..2 ..6 ..1 Installation Procedure 1. To prevent short circuits, remove the key • Do not let unconnected cables or terminals from the ignition and disconnect the ·... -
Page 3: Installing The Main Unit
Installing the Main Unit 2 CAUTION • When mounting the main unit after checking the operation, close the monitor first. • During installation, do not use any screws except for those provided. The use of different screws might result in damage to the main unit. •... - Page 4 Installing the Main Unit ■ Installing in Japanese-Made Cars-2 When the vehicle bracket is attached as in Toyota vehicles that use Not use the Hard a hole in the ● position in the figure below. Rubber Frame Accessory D If this device can’t be fastened with screws in the 2 places on the right and left due to the vehicle bracket shape, use the installation fastener (Accessory C) and fasten the bracket.
- Page 5 Installing and Connecting the Antenna Units • Attach the antenna to the inner glass surface of the rear window using double-sided tape. Carefully check the installation location as the tape can only be stuck on once. • If the surface temperature of the glass of the rear window is low, warm it by turning on the power of the rear defogger.
- Page 6 Connection (Accessory F) Other Monitor or Aux input of the audio unit • Visual (Yellow) • Audio left (White) • Audio right (Red) VCR,etc Back view camera,etc 2 WARNING Do not connect an LX-BUS cable. To parking brake detection switch harness of car 2 CAUTION (Accessory A)
-
Page 7: Removing The Unit
Removing the Unit ■ Removing the Hard Rubber Frame Lock Catch Engage the catch pins on the removal tool and remove the two locks on the lower level.Lower the frame and pull it forward as shown in the figure. Accessory E When the lower level is removed, remove the upper two locations.
