Edelbrock 5291 Installation Instructions

PostScript Picture
(Edelbrock B/W Logo.eps)
Please study these instructions carefully before installing your new sub-frame connectors. If you have any
questions or problems, contact our Technical Hotline at: 1-800-416-8628 from 7 am - 5 pm, Monday through
Friday, Pacific Standard Time or e-mail us at: edelbrock@edelbrock.com.
Application: Designed for 1994-2002 Mustang GT and 1999-2002 Mustang Cobras. Edelbrock Subframe
Connectors have been designed to add strength to the vehicle by connecting the front subframe from the front
suspension cradle mounting points to the rear suspension trailing arm mounts. The Edelbrock subframe
connector has large welding area to resist flex, heavy wall 1 5/8 diameter tubing for stability, and is contoured
to the floor pan of the vehicle so as not to reduce ground clearance.
Tools Required:
1. Common hand tools
2. Drive-on lift (preferred) or floor jack & stands
3. Soft-backed angle grinder / sander
4. C-clamps or Vice grips
5. MIG welder
Notes:
1. Weld-on subframe connectors should be installed by a professional welder with a proper wire feed or
MIG welder. The installer should have an understanding of welding dissimilar metals. The subframe
is formed from thin gauge sheet metal. The bracket of the Edelbrock subframe connectors are made
form 1/8 thick hot rolled steel that has been laser cut and formed to the required shape allowing for
minimum of gap.
2. Subframe connectors should not be installed on a vehicle with subframe damage due to accident or
vehicles that have weak, unequal rate, or improper springs.
3. Due to high production tolerances and wear from age, some vehicles may require fitting of the
subframe connectors. This may require reshaping of the vehicles floor pan or subframe, or minor
grinding of the subframe connectors.
©2002 Edelbrock Corporation
For 1994-2002 Mustang GT & 1999-2002 Mustang Cobra
Qty. Part #
2 68-5710
2 23-2057
2 23-2104
1 23-2106
1 23-2107
4 68-8702
4 60-0242
8 82-5592
2 82-4100
1 25-4056
1 25-4057
INSTALLATION INSTRUCTION
KIT CONTENTS
Description
5/16 - 18 x 1" hex head cap screw
Nut tab
Cross member reinforcement plate
Left seat reinforcement bracket
Right seat reinforcement bracket
10mm - 1.50 x 40mm bolt
10mm - 1.50 nyloc nut
7/16 Flat washer
5/16 Flat washer
Left subframe connector
Right subframe connector
Page 1 of 3
EDELBROCK SUSPENSION
Sub-Frame Connectors
Catalog #5291
Rev. 1/02
