Neo-i
Introducing the Neo-i
Be the Center of Attention
Create a theater experience from your media collection almost anywhere with the Optoma Neo-i. Dock your iPod/iPhone directly into the Neo-i
and start projecting videos or photos instantly on most surfaces around your home or office. Powered by LED technology, the Neo-i is capable of
producing 120'' images. With 16 watts of digitally-tuned audio output, amazing space-filling sound is created from a compact, portable design.
HDMI and VGA ports offer even more versatility by providing inputs for AppleTV™, Blu-ray™ players and computers. An optional iPad connection
kit is also available. The Optoma Neo-i allows you to experience your portable media collection in entirely new ways.
Features & Bene ts
• Universal dock compatible with all iPhone models and iPod models with video capability
• 16W stereo audio with DSP and Bass Reflex technologies to maximize sound quality
and bass response
• Truly portable - lightweight, instant on/off and cool operating temperature
• Project large widescreen images of up to 120 '' diagonal
• 2000:1 contrast ratio for detailed images
• LED light source lasts over 20,000 hours while producing excellent color
• DLP Pico technology
• HDMI and VGA ports
• Convenient remote included to control menu and playback options
• iPad kit – share content from the iPad with optional kit (Part #BC-PKAIDUS)
Specifications
Projection Type
DLP
Resolution
Native WVGA (854 x 480)
Maximum Resolution
WXGA (1280 x 800) through VGA Port; HD (1080i) through HDMI
Brightness
50 ANSI Lumens
2000:1 (Full On/Full Off)
Contrast Ratio
Light Source
LED (RGB); Estimated Life of Over 20,000 Hours*
Throw Ratio
1.8:1 (Distance/Width)
8" to 188"
Projection Distance
Image Size (Diagonal)
5" to 120" (16:9 Native)
Aspect Ratio
16:9 Native; 4:3 Compatible
Displayable Colors
100% NTSC Color Gamut
Audio
Two 8-Watt Speakers
Computer Compatibility
WXGA, XGA, SVGA, VGA, VESA, PC and Macintosh Compatible
Video Input Compatibility
NTSC, PAL, SDTV (480i), EDTV (480p), HDTV (720p, 1080i)
User Controls
Complete On-Screen Menu Adjustment in 10 Languages
Universal iPod/iPhone Dock (30-Pin), HDMI, VGA-In, 2.5mm Jack AV
I/O Connectors
Input (Composite Video and Stereo Audio-In)
Projection Method
Front, Rear
Weight
2.2 lbs (1kg)
Dimensions (W x H x D)
12.8" x 3.1" x 8.9"; (324 x 79 x 227mm)
Power Adapter
AC Input 100-240V, 1.0A, Auto-Switching, 50-60 Hz DC Output
19V, 2.1A
Power Consumption
36W (Max)
Noise Level
25 dB
Warranty
1 Year Limited Parts and Labor
Standard Accessories
Power Adapter, Standard A/V Cable (RCA to Mini-Jack), Remote
Control, Battery for Remote, Apple Universal Dock Adapters, CD-ROM
User's Manual, Quick Start Card and Warranty Card
Optional Accessories
iPad Kit with A/V Connector, High-Power Battery Pack, HDMI Cable
Model Number
DV20A
UPC
796435 41 693 5
*Lamp life is dependent upon many factors, including lamp mode, display mode, usage, environmental conditions and more.
Lamp brightness can decrease over time.
All specifications are subject to change without notice. © 2011 Optoma Technology, Inc. iPod
Apple Inc. iPhone™ is a trademark of Apple Inc. DLP
All other names mentioned herein are property of their respective owners. Neoi-DV20A-1210
Video Projector and Speaker System for iPhone & iPod
®
is a registered trademark of
®
®
and the DLP logo are registered trademarks of Texas Instruments.
POWERED BY LED
Optoma is committed to an
environmentally-conscious outlook.
Please visit
www.optoma.com for details.
