MULTI CHANNEL POWER AMPLIFIER
POA-3012CI
Owner's Manual
Bedienungsanleitung

Advertisement

Table of Contents
loading

Summary of Contents for Denon 3012CI - Power Amplifier

  • Page 1 MULTI CHANNEL POWER AMPLIFIER POA-3012CI Owner’s Manual Bedienungsanleitung...
  • Page 2 FCC requirements. Modification not expressly third prong are provided for your safety. If the provided plug does not fit into approved by DENON may void your authority, granted by the FCC, to use The exclamation point within an equilateral triangle is intended your outlet, consult an electrician for replacement of the obsolete outlet.
  • Page 3: Declaration Of Conformity

    • Avoid high temperatures. Wasser und Staub fern. Allow for sufficient heat dispersion when installed in a rack. DENON Europe • Vermeiden Sie hohe Temperaturen. Beachten Sie, dass eine ausreichende Division of D&M Germany GmbH Belüftung gewährleistet wird, wenn das An der Landwehr 19, Nettetal, Gerät auf ein Regal gestellt wird.
  • Page 4: Table Of Contents

    Using a mobile phone near this unit may result in noise. If so, move Input Connections ··········································································7 Thank you for purchasing this DENON product. To ensure proper the mobile phone away from this unit when it is in use. BUS INPUT Connections ································································7 operation, please read this owner’s manual carefully before using the...
  • Page 5: Part Names And Functions

    ENGLISH Part Names and Functions For buttons not explained here, see the page indicated in parentheses ( ). Front Panel ZONE select buttons ·································· (10) SELECT / ENTER knob ······························· (10) Power operation button (ON / STANDBY) ········································· (17) ZONE operation mode indicators ········· (6, 13) i (Down) button ········································...
  • Page 6: Rear Panel

    ENGLISH Rear Panel ETHERNET connector ··································· (8) TRIGGER IN jacks ········································· (9) RS-232C connector ······································· (9) MASTER TRIGGER OUT jack ························ (9) BUS INPUT connectors ································ (7) Speaker terminals (SPEAKER SYSTEMS) ··································· (5) BUS OUTPUT connectors ···························· (7) AC inlet (AC IN) ··········································· (10) MASTER TRIGGER IN jack ····························...
  • Page 7: Connections

    ENGLISH Preparations Cables Used for Connections Select the cables according to the equipment being connected. Connections Before Connecting Audio cables The POA-3012CI incorporates six sets of 2-channel amplifier from Connections for all compatible audio signal formats are described Audio input connections ZONE1 to ZONE6.
  • Page 8: Speaker Connections

    ENGLISH Speaker Connections Connection Method for BRIDGED Output • In BRIDGED mode, one channel is output from one ZONE. Connection Method When Outputting 2 Channels From One • To set BRIDGED mode, select “BRIDGED” as the “OPERATION MODE” on the “Main Setup” menu. •...
  • Page 9 Tighten the speaker terminal firmly before problems in the ventilation around the set nor in the connections, inserting the banana plug. the set may be damaged. Turn the power off, then contact a DENON service center. NOTE • Use speakers with an impedance of 4 to 16 Ω/ohms. Use a 8 to 16 Ω/ohms speaker for BRIDGED output.
  • Page 10: Input Connections

    ENGLISH Input Connections AUDIO INPUT Connections n When Using in NORMAL MODE n When Using in BRIDGED MODE BUS INPUT Connections To play signals input to the AUDIO INPUT terminal, use “INPUT Input BRIDGED output signals to an even-numbered input SELECT”...
  • Page 11: Connections To Other Devices

    ENGLISH Required System Connections to Other Devices n Broadband Internet Connection For connections to the Internet, contact an ISP (Internet Service Provider) or a computer shop. A broadband line connection to the Internet is required in order to ETHERNET Connections use the POA-3012CI’s firmware update.
  • Page 12: External Controller

    ENGLISH Master trigger input jack External Controller The “POWER CONFIGURATION” setting is valid at the time of a “MASTER TRIGGER” . Voltage input to the MASTER TRIGGER input terminal and operating status of the POA-3012CI: RS-232C connector At DC 3 ~ 30 V ···················· ON This connector is used for an external controller.
  • Page 13: Connecting The Power Cord

    ENGLISH Using the menu Connecting the Power Cord n To select the item to be set Wait until all connections have been completed before connecting the Setup SELECT/ENTER Turn the knob until the item you want to set power cord. appears.
  • Page 14: Menu Map

    ENGLISH Menu Map NORMAL MODE BRIDGED MODE CH 1 CH 2 BTL Main Setup a VOLUME CONTROL BTL 0.0dB 0.0dB CH 2 CH 4 BTL (vpage 13) (vpage 13) CH 3 CH 6 BTL BTL –90.0dB –90.0dB BTL – – –.–dB –...
  • Page 15 ENGLISH Main Setup Network Setup a N etwork DHCP Information (vpage 15) IP Address (vpage 15) Mac Address s Network Setup DHCP IP Address (vpage 15) Subnet Mask Default Gateway Primary DNS Secondary DNS Proxy Address Proxy Address Port Name Proxy Name Port...
  • Page 16: Main Setup

    ENGLISH Main Setup s INPUT SELECT f OPERATION MODE Sets the input terminal for each channel. Sets the output method for channels in each ZONE. F Menu tree F Main Setup [Selectable Channels] [Selectable Channels] a VOLUME CONTROL For details of the channels which can be set in each mode, see Sets each of the following channel pairs.
  • Page 17: Zone Trigger On Mode

    ENGLISH g ZONE TRIGGER ON MODE h DIMMER MODE Sets the operating specifications for the power amplifiers Adjust display brightness of the POA-3012CI. of each ZONE. [Selectable items] [Selectable Channels] Bright : Normal display brightness. For details of the channels which can be set in each mode, see GSelectable ChannelsH in “...
  • Page 18: Network Setup

    This is a system for converting the domain names used when Default Gateway SELECT/ENTER “Proxy” and press the knob (vpage 16 “Proxy browsing Internet sites (for example, “www.denon.jp”) into the settings”). IP addresses actually used for communications (for example, “202.221.192.106”). Primary DNS...
  • Page 19: S Network Setup

    Furthermore, updating the firmware may reset the backup data for Only use this function if so instructed by a DENON serviceperson or ! # % & ’ ( ) * + , - . / : ; = ˉ ? @ [ \ ] (space) the parameters, etc., set for the POA-3012CI.
  • Page 20: Operation

    ENGLISH Check the Status of Each Channel Operating the POA-3012CI Using a Browser (Web control) DISPLAY Press the button. Operation This function lets you operate the POA-3012CI using Internet Explorer. b Zone status is indicated on the bottom line of the display. SELECT/ENTER b Turn the knob to change the display as follows.
  • Page 21: Resetting The Microprocessor

    ENGLISH Operate. GExample: 3H Warning and Protection Data Screen To use the web control function, set the menu “Main Setup”– “POWER GExample: 1H Channel Setup Screen CONFIGURATION” – “ON LINE” (vpage 14). Click when you update to the latest information (z) NOTE •...
  • Page 22: Troubleshooting

    ENGLISH Troubleshooting Specifications Check the following before assuming there is a problem with the set: Rated output: 12-channel driving, NORMAL operation: 1. Are all connections proper? 30 W x 12 ch (8 Ω/ohms, DIN 1 kHz with 0.7 % T.H.D.) 2.
  • Page 24 Denon Brand Company, D&M Holdings Inc. Printed in Japan 00D 511 4719 004...
