EAW JF60z Specification Sheet

J F 6 0 z S p e c i f i c a t i o n s
DESCRIPTION
•
Compact loudspeaker with no compromise in sound quality
•
For portable use or permanent installation
•
100° conical beamwidth
•
Passive crossover for single amplifier operation
The JF60z is an ultra compact loudspeaker, engineered for
exceptional, near-field performance. It provides surprisingly high
output and exceptional fidelity for foreground and background music
applications. It's speech projection capabilities also make it very
effective as a fill or delay element in larger audio systems. Unlike
many compact loudspeakers, the JF60z produces the high impact,
high definition sound projection expected in professional PA
applications. Its wide angle projection makes audience coverage
easy in a variety of situations. While the JF60z is well suited as is for
many applications, the addition of a subwoofer can expand its
capabilities for more demanding applications.
Foam-backed grilles hide the drivers from view for pleasing
aesthetics. Top, bottom and side mounting points allow enclosures to
be mounted in virtually any configuration using eyebolts or accessory
brackets. Additional mounting points accept an OmniMount® 30.0
Series or similar bracket and a third-party, external, stand adapter for
pole mounting, such as the K&M™ 195/8 or Ultimate Support™
BMB-200K. Standard colors are black and white. Other colors can be
specified as a special order items.
The diverse applications for the JF60z include: band PA, multimedia
systems, retail spaces, presentation suites, shopping malls, smaller
houses of worship, theatres, auditoriums, lecture halls, and theme
parks. Fill/delay applications include arenas, stadiums, concert halls,
theatres, and houses of worship.
Six year warranty.
1 To achieve specified performance, the listed external signal processing with EAW-provided settings is required.
2 For recommendations to select power amplifier size refer to : "HOW MUCH AMPLIFIER POWER DO I NEED?" on the EAW web site.
EAW products are continually improved. All specifications are therefore subject to change without notice.
Eastern Acoustic Works One Main Street Whitinsville, MA 01588 tel 800 992 5013 / 508 234 6158 fax 508 234 8251 www.eaw.com
2-WAY FULL-RANGE
See NOTES TABULAR DATA for details
CONFIGURATION
Subsystem
Transducer
LF 1x 6.5 in cone
HF 1x 1.3 in dome
Operating Mode
Amplifier Channels
Single-amp LF/ HF
1
PERFORMANCE
Operating Range 83 Hz to 20 kHz
Nominal Beamwidth (rotatable)
Horz 100°
Vert 100°
Axial Sensitivity (whole space SPL)
LF/HF 88 dB
Input Impedance (ohms)
Nominal
LF/HF 8
Input Taps (MT version)
70 V
LF/HF 64 W / 32 W / 16 W
High Pass Filter
High Pass =>70 Hz, 12 dB/octave Butterworth
2
Accelerated Life Test
LF/HF 40 V
Calculated Axial Output Limit (whole space SPL)
Average
LF/HF 111 dB
ORDERING DATA
Description
JF60z 2-Way Full-Range Loudspeaker Black
JF60z 2-Way Full-Range Loudspeaker White
JF60zMT Multi-tap 70/100 V Transformer Black
JF60z-16 16 ohm Black
JF60zPL-WP Weather Protected Black
Optional Accessories
Eyebolt/Forged Shoulder (1/4-20 x 1 in)
U-Bracket Black
U-Bracket White
Yoke Bracket Black
Yoke Bracket White
group · J
Loading
Sealed
Waveguide Plate™
External Signal Processing
HPF
83 Hz to 20 kHz
Minimum
7.4 @ 220 Hz
100 V
64 W / 32 W
200 W @ 8 ohm
Peak
117 dB
Part Number
0012618
0013768
0013770
0013794
0014359
104009
0012360
0012362
0012388
0012393
Part Number: RD0287 (A) JF60z June 2005
