- Page 1 OWNER'S MANUAL NETWORK MONITOR Please read the safety information carefully before using the product. Network Monitor Model N1910LZ www.lg.com...
-
Page 2: Table Of Contents
Table of Contents TABLE OF CONTENTS ASSEMBLING AND TROUBLESHOOTING PREPARING Unpacking PRODUCT SPECIFICATION Parts and buttons Preset Mode Setting Up the Monitor set Power Indicator - Attaching the Stand Base - Detaching the stand base PROPER POSTURE - Adjusting the stand height - Adjusting the angle Proper posture for using the monitor - Mounting on a table... -
Page 3: Assembling And Preparing
Adaptor 15-pin D-SUB Signal Cable Stand Base CAUTION Only use an approved LG power adapter. Damage caused by other power adapters is not covered by warranty. NOTE Note that the components may look different from those shown here. Without prior notice, all information and specifications in this manual are subject to change to improve the performance of the product. -
Page 4: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Input Connectors (See p.14 ) Power Indicator LED On : Power is on LED Off: Power is off (Power Button) Front Side Buttons Input Connectors (See p.11 to 14) - Page 5 ASSEMBLING AND PREPARING Button Description MENU Activates the main menu. OSD Lock/Unlock Locks/unlocks the OSD screen. Functions y To lock the OSD screen, press and hold the MENU button for several seconds. The "OSD LOCKED" message will be displayed and the screen will be locked. y To unlock the OSD screen, press and hold the MENU button again for several seconds.
-
Page 6: Setting Up The Monitor Set
ASSEMBLING AND PREPARING Setting Up the Monitor set Detaching the stand base Attaching the Stand Base Place the monitor's screen face down. To protect the screen from scratches, cover the surface with a soft cloth. Place the monitor's screen face down. CAUTION To protect the screen from scratches, cover Using a coin, turn the screw in the stand base... -
Page 7: Adjusting The Stand Height
ASSEMBLING AND PREPARING Adjusting the stand height Adjusting the angle Place the monitor mounted on the stand base Place the monitor mounted on the stand base in an upright position. in an upright position. Remove the tape attached at the bottom rear Adjust the angle of the screen. -
Page 8: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Using the Kensington locking device Lift the monitor and place it on the table in an The connector for the Kensington lock is located upright position. on the rear of the monitor. Install at least 10 cm away from the wall to For more information on installation and usage, ensure sufficient ventilation. -
Page 9: Detaching The Stand Body
Installing the wall mount plate This monitor has a VESA compatible mount on the Place the monitor's screen face down. To back. Most mounts will require an LG mounting protect the screen from scratches, cover the plate. surface with a soft cloth. -
Page 10: Mounting On A Wall
Please use 10 cm a LG wall mounting bracket when using a VESA mount. For more information, contact your local retail store or a qualified installer. -
Page 11: Using The Monitor Set
USING THE MONITOR SET USING THE MONITOR SET Connecting Input Signal Cable D-SUB OUT connection - PCoIP This monitor supports the *Plug and Play feature. D-SUB OUT can only mirror the image displayed *Plug and Play: A feature that allows you to RGB OUT on the monitor. -
Page 12: Dvi Connection - Pcoip
USING THE MONITOR SET DVI connection - PCoIP CAUTION Transfers digital video signals to another monitor. Connect the input signal Connect the monitor using the DVI cable as illus- cable and tighten in the trated below. direction of the arrow. To This connection is used to support an extended prevent disconnection monitor or replicate the image displayed on the... -
Page 13: Connecting Lan/Peripherals
USING THE MONITOR SET Connecting LAN/Peripherals NOTE LAN connection - PCoIP The LAN cable is sold separately. The following LAN cable type can be used: The LAN connection transmits PCoIP signals to Standard: IEEE 802.3 ETHERNET the monitor. Connect the router or switch to the When connecting the Earphone Out or Line monitor using a LAN cable as illustrated below. -
Page 14: Peripheral Device Connection
USING THE MONITOR SET Peripheral device connection NOTE Connect peripheral devices to the monitor using Peripheral devices are sold separately. USB, headphone, speaker, and microphone ports. The USB ports on the left and bottom of the monitor can be used to connect the key- board, mouse, and other USB devices. -
Page 15: Self Image Adjustment
USING THE MONITOR SET Self Image Adjustment Press the power button on the front to turn on the monitor. When powered on, the "Self Image Adjustment" function will run automatically (only available for analog [D-SUB input] signals). NOTE What is "Self Image Adjustment"? This func- tion runs when the monitor is connected for the first time and performs automatic image adjustment for each signal (only available for... -
Page 16: Customizing Settings
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing The Main Menus Press any button on the front of the monitor to display the MONITOR SETUP OSD menu. Press to select the desired menu item. To change the settings of the selected item press the buttons on the front of the monitor. To return to the upper menu or set other menu items, use the up arrow ( ) button. -
Page 17: Menu Settings
CUSTOMIZING SETTINGS MENU Settings Picture MENU PICTURE Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the OSD menu. BRIGHTNESS CONTRAST Set the options by pressing the buttons on the front of the monitor. -
Page 18: Color
CUSTOMIZING SETTINGS Color MENU COLOR Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. COLOR TEMP PRESET Press the MENU button to display the options in the PRESET WARM OSD menu. Set the options by pressing the buttons on the front GREEN of the monitor. -
Page 19: Display
CUSTOMIZING SETTINGS Display MENU DISPLAY Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the HORIZONTAL OSD menu. VERTICAL CLOCK Set the options by pressing the buttons on the front PHASE of the monitor. -
Page 20: Others
CUSTOMIZING SETTINGS Others MENU OTHERS Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the LANGUAGE English OSD menu. PCoIP WHITE BALANCE Set the options by pressing the buttons on the front FACTORY RESET of the monitor. -
Page 21: Mode Settings
CUSTOMIZING SETTINGS MODE Settings F-ENGINE Press any button on the front of the monitor to dis- MODE play the MONITOR SETUP OSD menu. Press the MODE button to display the options in the OSD menu. Set the options by pressing the buttons on the front NORMAL MOVIE INTERNET... -
Page 22: Photo Effect
CUSTOMIZING SETTINGS EXIT PHOTO EFFECT MODE Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MODE button to display the options in the OSD menu. NORMAL GAUSSIAN SEPIA MONOCHROME BLUR Set the options by pressing the buttons on the front of the monitor. -
Page 23: Auto Settings : D-Sub Input
CUSTOMIZING SETTINGS AUTO Settings : D-SUB Input Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. PROCESSING AUTO IMAGE ADJUSTMENT Press the AUTO button to automatically adjust the FOR OPTIMAL DISPLAY screen. CHANGE RESOLUTION TO 1280 x 1024 Select EXIT to leave the OSD menu. -
Page 24: Troubleshooting
Troubleshooting TROUBLESHOOTING Nothing is displayed on the screen Is the monitor's power cord plugged in? y Check if the power cord is correctly plugged in to the outlet. Is the power indicator on? y Check the power indicator. y Adjust the brightness and the contrast. Is the power indicator displaying as white? y If the monitor is in power saving mode, move the mouse or press any... - Page 25 Troubleshooting The image is displayed abnormally. Does the display area appear un- Pressing the AUTO button will automatically optimize the screen to the current centered? display mode. If you are not satisfied with the optimized screen, you can manually adjust the POSITION option in the OSD menu.
-
Page 26: Product Specification
Specifications PRODUCT SPECIFICATION LCD Screen Type 481.9 mm (19 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Diagonal length of the screen: 481 mm Pixel Pitch 0.294 mm x 0.294 mm Resolution Maximum Resolution 1280 x 1024 @ 60 Hz Recommended Resolution 1280 x 1024 @ 60 Hz Video Signal Horizontal Frequency... -
Page 27: Preset Mode
Product Specification Preset Mode Horizontal Frequen- Vertical Frequency Preset Mode Polarity (H/V) Remark cy (kHz) (Hz) 720 x 400 31.468 640 x 480 31.469 800 x 600 37.879 1024 x 768 48.363 Recommended 1280 x 1024 63.981 Mode Power Indicator Mode LED Color On Mode... -
Page 28: Proper Posture
Proper Posture PROPER POSTURE Proper posture for using the monitor Adjust the angle so that the screen is slightly lower than your eyes. Using the monitor for a prolonged period of time can cause eye fatigue. Take a 10-minute break every hour. -
Page 29: Using Pcoip Solution
Using PCoIP Solution USING PCOIP SOLUTION Figure 2-3 shows the network icon when ready. Connect Screen The Connect screen is shown during start-up, except when the portal has been configured for a managed start-up or auto-reconnect. The logo dis- played above the Connect button can be changed Figure 2-3. - Page 30 Using PCoIP Solution Selecting one of the options will produce a settings Network Tab window. The Network tab allows the administrator to config- ure the portal network parameters. NOTE The network parameters can also be con- figured using the Webpage Administration Interface.
- Page 31 Using PCoIP Solution y Gateway Label Tab The Gateway field contains the gateway IP ad- The Label tab allows the administrator or host to dress of the device. If DHCP is disabled, this field add customized information to the portal. is required.
- Page 32 Using PCoIP Solution Connection Management Tab Table 2-1 shows the configuration parameters that The Connection Management tab allows the can be used with one of the two methods. If an user to enable or disable the connection man- incorrect IP address or DNS name is provided, an agement and specify the connection manager's OSD message is displayed prompting the adminis- IP address.
- Page 33 Using PCoIP Solution Discovery Tab Session Tab The Discovery tab allows the administrator to eas- The Session tab allows the administrator to set the ily find a portal in the PCoIP system. method to connect the device to a peer device. NOTE NOTE The Discovery parameters can also be con-...
- Page 34 Using PCoIP Solution RDP Tab y Audio Mode The RDP tab allows the administrator to configure The Audio Mode field is used to set the audio play- the remote desktop protocol (RDP) specific set- back location of the RDP session. The available tings.
- Page 35 Using PCoIP Solution OSD Tab Reset Tab The OSD tab allows the administrator to modify the The Reset tab allows the administrator to reset all On Screen Display (OSD) parameters. configurable parameters stored in Flash. NOTE NOTE The OSD parameters can also be configured The Reset function can also be accessed using the Webpage Administration Interface.
- Page 36 Using PCoIP Solution Display Tab y Enable VMware View The Display tab allows the user to configure the The Enable VMware View option allows the user to EDID function of the monitor. configure the portal to use the VMware View Con- nection Server.
- Page 37 Using PCoIP Solution Event Log Tab Session Statistics Tab The Event Log tab allows the administrator to view The Session Statistics tab allows the administrator and delete the event log messages from the portal. to view the PCoIP specific statistics of the last ac- tive PCoIP session from the portal.
- Page 38 Using PCoIP Solution y Bytes Statistics Ping Tab y Bytes Sent The Ping tab allows the administrator to perform a The Bytes Sent field shows the total number ping test to the device and check if it can reach the of bytes sent in the last active session.
- Page 39 Using PCoIP Solution Information Window PCoIP Processor Revision In the Information window, the administrator can This shows the PCoIP processor's revision code. access the Version tab that contains the device TERA1x00 Revision A silicone is denoted by 0.0 related information. and TERA1x00 Revision B silicone is denoted by 1.0.
- Page 40 Using PCoIP Solution Mouse Tab Keyboard Tab The Mouse tab allows the user to modify the OSD The Keyboard tab allows the user to modify the and RDP session's mouse cursor speed setting. OSD and RDP session's keyboard repeat setting. NOTE NOTE The OSD keyboard setting does not affect...
- Page 41 Using PCoIP Solution Image The Image tab allows a user to change the image settings on the PCoIP system. NOTE The Image parameters can also be con- figured using the Webpage Administration Interface. Figure 2-24. Image y Minimum Image Quality The Minimum Image Quality slider allows the ad- ministrator to make compromises between image quality and frame rate when network bandwidth...
- Page 42 Make sure to read the Safety Precautions before using the product. Keep the Owner's Manual(CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET.
