- Page 1 U-Series Installation Manual N195WU This manual describes how to install the LG U-Series network monitor in WMS 2011 OS Environment. Please read the safety information carefully before using the product. www.lg.com...
-
Page 2: Table Of Contents
A monitor that is connected through the video port of the server PC. You can use a monitor other than an LG U-Series monitor. y Standard Station LG U-Series monitor that is connected through the USB port of the server PC. y Station A monitor. -
Page 3: Software Installation Prerequisites
NETWORK MONITOR INSTALLATION SOFTWARE INSTALLATION PREREQUISITES To install the LG U-Series network monitor, you will need the following. Station 1 Station 2 Station 3 Station 4 U-Series Network Monitor Power Cord User Manual/ USB Cables (A-B Type) AC/DC adaptor Software Installation CD/... -
Page 4: System Requirements
NETWORK MONITOR INSTALLATION SYSTEM REQUIREMENTS: Make sure that the PC system meets the recommended requirements, listed below, prior to in- stalling the U-Series network monitor. System Requirements Intel Core i5 @3.2 GHz or higher 4 GB Windows MultiPoint Server2011 NOTE y The number of monitors that can be connected and the method used to connect multiple monitors can vary depending on the user environment and the server PC performance. -
Page 5: Installing Primary Station And Standard Stations
NETWORK MONITOR INSTALLATION INSTALLING PRIMARY STATION AND STANDARD STATIONS 1. Connecting the Server PC to the Main Monitor Primary Station Server PC D-SUB Cable USB Hub (sold separately) PS2-type Keyboard/Mouse USB-type Keyboard/Mouse (sold separately) (sold separately) Connect the regular monitor to the Server PC using a D-SUB or DVI cable. Connect the PS2-type keyboard and mouse to the PS2 port of the Server PC. -
Page 6: Connecting The Server Pc To Standard Monitors
NETWORK MONITOR INSTALLATION 2. Connecting the Server PC to Standard Monitors Server PC Primary Station Station 4 USB Cable Station 3 USB Cable Headphones USB Cable (sold separately) Station 2 USB Cable Microphone (sold separately) USB Memory (sold separately) Station 1 USB-type Mouse/Keyboard (sold separately) Connect the USB port of the server PC to the streaming port (located at the back of the monitor) of the... -
Page 7: Linking U-Series Monitors By Daisy Chaining
NETWORK MONITOR INSTALLATION 3. Linking U-Series Monitors by Daisy Chaining Server PC Primary Station USB Cable USB Cable Station 1 USB Cable USB-type Mouse Station 2 Station 3 (sold separately) Connect the USB mouse port (located at the back of the monitor) of the first U-Series monitor to the up- streaming port of the second monitor using an A-B-type USB cable. -
Page 8: Multipoint Manager
NETWORK MONITOR CONFIGURATION MultiPoint Manager Using MultiPoint Manager The MultiPoint Manager will run automatically upon booting the operating system. On the first boot after the installation of the operating system, MultiPoint Manager will start in mainte- nance mode. Add user accounts for multi-user. Adjust the screen resolution for each station accordingly. - Page 9 NETWORK MONITOR CONFIGURATION Precautions y This monitor does not support station partitioning. y Some keyboards and mouse devices may not be compatible with this monitor. y After adding a new U-Series monitor to an existing U-Series multi-computing environment, or after modifying its configuration (cable connection), you may need to reboot the PC to ensure normal op- eration.
