Pentax 17251 - Optio W60 Digital Camera Connection Manual

PC Connection
Manual
You can transfer images and movies captured with your digital camera to your computer and
then display and manage them by installing the software included on the provided CD-ROM
to your computer and connecting your digital camera to your computer with the USB cable.
This section explains how to install the provided software "ACDSee for PENTAX" and
"ACDSee 2 for Mac", and the other necessary preparations for enjoying your digital camera
pictures and movies on your computer.
PENTAX and Optio are trademarks of HOYA CORPORATION.
© 2008 ACD Systems Ltd. All rights reserved. ACDSee and the ACDSee logo are trademarks
of ACD Systems Ltd. in Canada, the U.S., Europe, Japan and other countries.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United
States and other countries.
Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the
United States and/or other countries.
Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and other
countries.
All other brands or product names are trademarks or registered trademarks of their respective
companies.
Software Provided
Windows
• ACDSee for PENTAX 3.0 (Image viewing/managing/editing software)
Macintosh
• ACDSee 2 for Mac (Image viewing/managing software)
53391 H02-200806 Printed in China
Step 2
Windows
Installing the Software
Install the image viewing/managing/editing software (ACDSee for PENTAX 3.0).
• Make sure your PC meets the system requirements before installing the software.
• When multiple accounts have been setup in Windows 2000, Windows XP or Windows
Vista, log on with an account that has administrative rights before installing the software.
1
Turn your PC on.
2
Insert the CD-ROM (S-SW81) into the CD-ROM drive.
The language selection screen appears.
If you are using Windows Vista
When the [AutoPlay] screen appears, display the language selection screen following the
steps below.
1) Click [Run setup.exe].
2) Click [Allow].
The language selection screen appears.
If the language selection screen does not appear
Display the language selection screen following the steps below.
1) Double-click [My Computer] on the desktop.
2) Double-click the [CD-ROM drive (S-SW81)] icon.
3) Double-click the [Setup.exe] icon.
3
Choose a language from the displayed screen.
The "ACDSee for PENTAX 3.0" installation screen appears.
Windows Users Macintosh Users
Step 1
First, check the system requirements for the provided software.
Step 2 Step 2
Install the image viewing/managing/ Install the image viewing/managing
editing software (ACDSee for software (ACDSee 2 for Mac) on your
PENTAX 3.0) on your PC. Macintosh.
Step 3
Set up your digital camera for connecting with your computer.
Step 4 Step 4
*on reverse side *on reverse side
Connect the camera and your PC, Connect the camera and your
and transfer images. Macintosh, and transfer images.
Step 5 Step 5
*on reverse side *on reverse side
Use the supplied software to view, Use the supplied software to view
manage or edit images transferred to and manage images transferred to
your PC. You can also enjoy laying your Macintosh.
out and printing images or creating
slide shows.
You are recommended to use an AC adapter connected to a power outlet when
connecting the camera to a computer. If the battery runs out of power while images are
being transmitted to the computer, the image data may be lost or damaged. When using
an AC adapter, make sure that the AC plug cord is properly connected to the camera.
4
Click [Install].
Setup screen appears. Follow the on-screen guidance and
enter the registration information.
5
Click [Finish].
ACDSee for PENTAX 3.0 installation is complete.
To continue, click [Exit] on the install window to close the
window and restart Windows.
Step 1
Windows, Macintosh
System Requirements
Windows System Requirements
USB connection and the included application software do not support Windows 95,
Windows 98, Windows 98SE, Windows Me and Windows NT.
USB connection
• OS : Windows 2000, Windows XP, Windows Vista (The OS must be
preinstalled and updated to the latest version.)
• USB port must be standard equipment
∗
Driver installation is unnecessary.
Application Software
<ACDSee for PENTAX 3.0>
(Nine languages: English, French, German, Spanish, Italian, Russian, Chinese [traditional
and simplified], Korean, Japanese)
• OS : Windows 2000, Windows XP or Windows Vista
• CPU : Pentium III or higher
• Memory : 256 MB minimum (512 MB or more recommended)
• Hard Disk space : 100 MB minimum (1 GB or more recommended)
• CD-ROM drive
• Monitor : Display adapter capable of displaying a minimum of 256 colors
• Internet Explorer 5.0 or later
∗
DirectX 9.0 or later and Windows Media Player 9.0 or later are required to play the movies.
∗
The OS must be preinstalled and updated to the latest version.
∗
Operation is not guaranteed on all computers meeting the system requirements.
∗
The system requirements describe the minimum environment for playing and editing
movies.
The versions of Internet Explorer, Windows Media Player and DirectX required for use of "ACDSee for
PENTAX 3.0" are not included in the provided CD-ROM (S-SW81). Visit the following sites to download
necessary items and install/update them on your PC.
• Internet Explorer
http://www.microsoft.com/windows/products/winfamily/ie/default.mspx
• Windows Media Player
http://www.microsoft.com/windows/products/winfamily/mediaplayer/default.mspx
• DirectX
http://www.microsoft.com/windows/directx/default.mspx
Step 2
Macintosh
Installing the Software
Install the image viewing/managing software (ACDSee 2 for Mac).
1
Turn your Macintosh on.
2
Insert the CD-ROM (S-SW81) in the CD-ROM drive.
3
Double-click the CD-ROM (S-SW81) icon.
4
Double-click the [ACDSee Installer] icon.
The language selection screen appears.
Double-click the [Master Installer] icon to display the language selection screen.
5
Choose a language from the displayed screen.
The "ACDSee 2 for Mac" installer screen appears.
6
Click [Install].
The setup screen appears. Follow the on-screen guidance to
input registration information and install the software.
Macintosh System Requirements
USB connection
• OS : Mac OS X (Ver. 10.1.2 - 10.5) (The OS must be preinstalled and
updated to the latest version.)
• USB port must be standard equipment
∗
Installation of the driver is not necessary.
Application Software
<ACDSee 2 for Mac>
(Six languages: English, French, German, Spanish, Italian, Japanese)
• OS : Mac OS X (ver. 10.3 - 10.5)
• CPU : Power Macintosh 233 MHz or higher
• Memory : 8 MB minimum
• Hard Disk space : 6 MB minimum
• CD-ROM drive, QuickTime 4.0 or later
∗
The OS must be preinstalled and updated to the latest version.
∗
Operation is not guaranteed on all computers meeting the system requirements.
Step 3
Windows, Macintosh
Setting Up Your Digital Camera
Setting the USB Connection Mode to [PC]
These settings must be configured before connecting to a computer. These settings
cannot be configured while the camera is connected to the computer with a USB cable.
1
Press the 3 button.
Setting
2
Press the four-way controller (5) to display the
Folder Name
USB Connection
[W Setting] menu.
Video Out
3 Brightness Level
Use the four-way controller (23) to select [USB
Power Saving
Auto Power Off
Connection].
MENU Cancel Cancel Cancel
4
Press the four-way controller (5).
A pull-down menu appears.
5
Use the four-way controller (23) to select [PC].
6
Press the 4 button.
Product Registration on the Internet
If your computer is connected to the Internet, please click
[Product Registration] on the setup screen in Step 2 .
A world map for Internet Product Registration is displayed.
Click the displayed country or region and then follow the
instructions to register your product.
Thank you very much for your cooperation.
Only customers in displayed countries and regions can register their products on the
Internet Product Registration.
2/3
Date
PC
PictBridge
5sec
3min
OK OK OK OK
