EarthStone 110 Modular Installation Instructions

MODEL 110 Modular
WOOD-FIRED OVEN
Model 110 Modular Oven Includes:
Floor Tiles (25)
5 - 12" X 6"
20 - 12" X 12"
Oven Pieces:
Primary Hood
Dome Pieces (2)
Side Wall Pieces (4)
Front Entrance Piece
Additional Items:
Steel Entrance Plate (black)
Thick Cast Aluminum Door
Dial Temperature Gauge (probe 3ft)
Refractory Cement (22 lb / 10 kg Bag)
Galvanized Metal Flashing
High Heat Silicone Tube
Plywood Spacers
Refractory Cement (container)
Package of Fire Starters
Stainless Steel Pizza Peel
4" x16" Screened Vent
Installation Instructions and Video/DVD
>
43" Interior cooking area
>
Wall and dome elements are a dense
superior high temperature refractory material
composed of 80" alumina and other advanced
elements for extra durability, heat retention
and longevity.
>
High Thermal Mass for excellent heat
retention.
>
Hearth Floor Tiles - "Pierre de Boulanger"
are cold pressed at 8,500 psi and ceramitized
at 2800F degrees.
>
Large oven entrance opening allows for
maximum visibility and easy usage.
>
Shipping Weight: 1,700 lb
24"
4"
51 1/2"
55 1/2"
10 1/4"
20 1/2"
51 1/2"
E S
ARTH
WOOD-FIRE OVENS
6717 San Fernando Road
Glendale CA 91201
Tel: 800-840-4915 - 818-553-1134
earthstoneovens.com
