FLY

Garmin Pilot provides full en-route navigation capabilities on its moving map.
The ability to view navigation data such as ETE, ETA, crosstrack error, and distance
information. Pilots can also navigate with Garmin's patented panel view, a GPS-driven
instrument panel with graphical HSI directional display and indicators for groundspeed,
geometric altitude and vertical speed. Touch and hold any location on the map and
the Radial Menu provides quick and easy access to navigation information, including
airports, navaids, current METARs, and airspace. The Radial Menu also provides a
ready means of navigating direct-to, create user waypoints or graphically edit the route
of flight. After takeoff, pilots can continue to view real-time weather information by
wirelessly connecting to SiriusXM Weather through the Baron Mobile Link
with a satellite weather receiver (sold separately, subscription required).

MAP PAGE

The Map Page is comprised of Map Pane and an option for split-screen. The Split-
screen option allows the Map Page to be divided between the Map Pane and one of
five options including Widgets, Panel, Charts, Active Navlog, or SafeTaxi. The Split-
screen feature is available in either portrait or landscape screen orientation.

MAP SETTINGS AND CONTROLS

The Map Menu provides basic Map Settings as well as map Overlay Opacity,
graphical flight plan editing, and split-screen controls. The Map Pane has a number of
buttons that control the base map type, map overlays, and map page view. The table
below shows the Map Pane controls.
