The OkiLAN 6120i Print Server enables Ethernet network users to connect to a network-configured printer. It
supports 10/100-megabit networks, TCP/IP Direct Printing and Server-Based Printing.
Note: Before using the parallel port, you must remove the OkiLAN 6120i from the printer —see your
on-line OkiLAN User's Guide for instructions on how to do this.
Installing the OkiLAN 6120i
1. Turn off printer power.
2. Unplug the power cord.
3. Detach the interface cable from the rear of the printer.
4. Pry off the breakaway panel next to the interface connector with a screwdriver
5. Insert the OkiLAN 6120i by sliding it along the rails in the recess of the printer, until it is plugged
into the socket in the rear of the recess.
OkiLAN 6120i Installation
Breakaway panel
1
Advertisement
Related Manuals for Oki ML320
Summary of Contents for Oki ML320
- Page 1 OkiLAN 6120i Installation The OkiLAN 6120i Print Server enables Ethernet network users to connect to a network-configured printer. It supports 10/100-megabit networks, TCP/IP Direct Printing and Server-Based Printing. Note: Before using the parallel port, you must remove the OkiLAN 6120i from the printer —see your on-line OkiLAN User’s Guide for instructions on how to do this.
- Page 2 6. Attach the 10/100Base-T UTP cable to the receptacle on the back of the OkiLAN 6120i. Attach the other end of the cable to the Network. 7. Plug the power cord into the power outlet (if provided).
-
Page 3: Printing A Configuration Sheet
Powering On the OkiLAN 6120i Turn printer power on. The red and green indicators on the OkiLAN 6120i blink during self-test. When self- test completes successfully, the red indicator goes off and the green indicator stays on. Green indicator Red indicator Printing a Configuration Sheet To print configuration information, press the Test button on the front of the OkiLAN 6120i. -
Page 5: Resetting To Factory Defaults
IC Radio Interference Statement 1. Turn off the printer. This Oki Data apparatus complies with the Class A limits for 2. Turn on the printer and wait for the print server to boot up radio interference as specified in the IC Radio Interference (about 30 seconds). - Page 6 Réinitialisation des paramètres aux Déclaration d'IC sur le brouillage radioélectrique valeurs définies par défaut Cet appareil Oki Data est conforme aux limitations de classe A concernant le brouillage radioélectrique spécifiées dans les réglementations d'Industrie Canada. 1. Mettez l'imprimante hors tension.
- Page 7 Estos servidores de impresión de red no son compatibles con Los cambios o modificaciones que no han sido expresamente TELNET. aprobados por Oki Data podrían invalidar la autoridad del usuario para operar este equipo. Volver a los valores por defecto de Declaraciones de Industry Canada (IC) fábrica...
- Page 8 Declarações da Industry Canada (IC) Restabelecimento das configurações da fábrica Declaração da IC sobre a interferência de rádio This Oki Data apparatus complies with the Class A limits for radio interference as specified in the IC Radio Interference 1. Desligue a impressora Regulations.
