Gigabyte GA-7A8DRH User Manual

Gigabyte GA-7A8DRH User Manual

Amd socket 940 dual processor motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
The author assumes no responsibility for any errors
or omissions that may appear in this document nor
does the author make a commitment to up
date the information contained herein.
Third-party brands and names are the property of
their respective owners.
Please do not remove any labels on motherboard, this
may void the warranty of this motherboard.
Due to rapid change in technology, some of the
specifications might be out of date before publication
of this booklet.
Before you install PCI cards, please remove the Dual
BIOS label from PCI slots if there is one.

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte GA-7A8DRH

Summary of Contents for Gigabyte GA-7A8DRH

  • Page 1 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to up date the information contained herein. Third-party brands and names are the property of their respective owners. Please do not remove any labels on motherboard, this may void the warranty of this motherboard.

  • Page 3: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-7A8DRH is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 4 (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Motherboard Model Number: GA-7A8DRH Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is...
  • Page 5 GA-7A8DRH AMD Socket 940 Dual Processor Motherboard USER’S MANUAL AMD Opteron Socket 940 Dual Processor Motherboard ™ Rev. 1001...

  • Page 6: Table Of Contents

    GA-7A8DRH Motherboard Table of Content Item Checklist ..................8 WARNING! ....................8 Chapter 1 Introduction ................9 Summary of Features .................. 9 GA-7A8DR-H Motherboard Layout ............11 Chapter 2 Hardware Installation Process ..........13 Step 1: Installing Processor and CPU Cooling Fan........14 Step1-1: Installing CPU ....................
  • Page 7 Table of Content Chapter 4 Technical Reference ............66 Block Diagram ................... 66 Chapter 5 Application Driver Installation ..........67 A. AMD Driver Pack Installation ..................67 B. Intel Network Driver Installation .................. 69 C. SCSI Driver Installation ..................... 71 Chapter 6 Appendix ................

  • Page 8: Item Checklist

    GA-7A8DRH Motherboard Item Checklist The GA-7A8DRH motherboard GC-SCSI 02 Card PATA Cable x 2 FDD Cable x 1 CD for motherboard driver & utility I/O shield x 1 GA-7A8DRH user’s manual SCSI cable x 1 Quick Reference Guide x 1 WARNING! Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips.

  • Page 9: Chapter 1 Introduction

    Form Factor 30.4cm x 26.9cm ATX size form factor, 6 layers PCB. Motherboard GA-7A8DRH Motherboard Support Dual Opteron processors (Sledge Hammer) The HyperTransport link of the AMD Opteron processor is capable of operating at 400, 800, 1200, and 1600 MT/s.
  • Page 10 GA-7A8DRH Motherboard Hardware Monitor Winbond W83791D CPU/System Fan Revolution detect CPU/System temperature detect System Voltage Detect Power Management Support Power Managerment Features Wake-on-LAN (WOL), USB, PCI, mouse Supports ACPI S1/S4/S5 functions On-Board VGA Build in ATI Rage XL with 8M SDRAM on board...

  • Page 11: Ga-7A8Drh Motherboard Layout

    Introduction GA-7A8DRH Motherboard Layout NN OO CC DD GA-7A8DRH...
  • Page 12 GA-7A8DRH Motherboard CPU1 IPMB1 CPU2 FDD1 AMD8131 COMB AMD8111 GLAN2 Intel 845GM GLAN1 Intel 82541GI VGA1 BIOS LPT1 EM638325TS-6 COMA1 PWR_FAN2 (Power Fan) USB3 PWR_FAN1 (Power Fan) KB_MS (Keyboard/Mouse) ITE8712 ATX2 (SSI power connector) CPU_FAN2 (CPU Fan) ATX1 (SSI power connector)

  • Page 13: Chapter 2 Hardware Installation Process

    Hardware Installation Process Chapter 2 Hardware Installation Process To set up your computer, you must complete the following steps: Step 1- Install the Central Processing Unit (CPU) Step 2- Install memory modules Step 3- Install expansion cards Step 4- Connect ribbon cables, cabinet wires, and power supply Step 5- Setup BIOS software Step 6- Install supporting software tools Step 2...

  • Page 14: Step 1: Installing Processor And Cpu Cooling Fan

    GA-7A8DRH Motherboard Step 1: Installing Processor and CPU Cooling Fan Before installing the processor and cooling fan, adhere to the following cautions: 1. The processor will overheat without the heatsink and/or fan, resulting in permanent irreparable damage. 2. Never force the processor into the socket.
  • Page 15 Hardware Installation Process Figure 3. A1 pin location on the Socket and Processor.Move the socket lever to the locked position while holding pressure on the center of the processor. Step 4. When the processor installation is completed, apply thermal grease to the processor(as shown in Figure 4) prior to installing the heatsink.

  • Page 16: Step1-2: Installing Cooling Fan

    GA-7A8DRH Motherboard Step1-2: Installing Cooling Fan Step 1. Attach th cooling fan clip to the processor scoket. Align the heatsink assembly with the support frame mating with the backer plate standoffs as shown in Figure 5&6. Step 2. Coonect the processor fan cable to the processor fan connector.
  • Page 17 Hardware Installation Process Figure 8. Recommended cooling fan Figure 9. Air Flow direction...

  • Page 18: Step 2: Install Memory Modules

    GA-7A8DRH Motherboard Step 2: Install memory modules Before installing the processor and heatsink, adhere to the following warning: Please note that the DIMM module can only fit in one direction due to the one notches. Wrong orientation will cause improper installation. Please change the insert orientation.

  • Page 19: Installation Step

    Hardware Installation Process Total Memory Sizes With Registered DDR DIMM Devices used on DIMM 1 DIMMx64/x72 2 DIMMsx64/x72 3 DIMMsx64/x72 4 DIMMsx64/x72 64 Mbit (4Mx4x4 banks) 256 MBytes 512 MBytes 768 MBytes 1 GBytes 64 Mbit (2Mx8x4 banks) 128 MBytes 256 MBytes 384 MBytes 512 MBytes...
  • Page 20 GA-7A8DRH Motherboard Table 1. Vaild DIMM Configuration for 64 bit Mode DIMM 0 (MB) DIMM 2 (MB) 1024 1024 1024 2048 2048 2048 4096 4096 4096 Note: X = Do not populate Table 2. Vaild DIMM Configuration for 128 bit Mode...

  • Page 21: Ddr Introduction

    Hardware Installation Process DDR Introduction DDR memory is a great evolutionary solution for the PC industry that builds on the existing SDRAM architecture, yet make the awesome advances in solving the system performance bottleneck by doubling the memory bandwidth. Nowadays, with the highest bandwidth of 3.2GB/s of DDR400 memory and complete line of DDR400/333/266/200 memory solutions, DDR memory is the best choice for building high performance and low latency DRAM subsystem that are suitable for servers, workstations, and full range of desktop PCs.

  • Page 22: Step 3: Install Expansion Cards

    GA-7A8DRH Motherboard Step 3: Install expansion cards 1. Read the related expansion card’s instruction document before install the expansion card into the computer. 2. Remove your computer’s chassis cover, screws and slot bracket from the computer. 3. Press the expansion card firmly into expansion slot in motherboard.

  • Page 23: Step 4: Connect Ribbon Cables, Cabinet Wires, And Power Supply

    Hardware Installation Process Step 4: Connect ribbon cables, cabinet wires, and power supply Step4-1:I/O Back Panel Introduction...
  • Page 24 GA-7A8DRH Motherboard PS/2 Keyboard and PS/2 Mouse Connector This connector supports standard PS/2 PS/2 Mouse Connector keyboard and PS/2 mouse. (6 pin Female) PS/2 Keyboard Connector (6 pin Female) USB Connector Before you connect your device(s) into USB connector(s), please make sure your device(s) such as USB keyboard,mouse, scanner, zip, speaker..
  • Page 25 Hardware Installation Process LAN Connectors LAN 1: Gigabit Ethernet 10/100/1000 LAN 2: Giagbit Ethernet 10/100/1000 LAN1 LAN2 LAN1/LAN2 LED Description LAN Port Status Description LAN 1 Yellow LED Blink LAN1 active Yellow LED On LAN1 connected Green LED On LAN1 at Speed 100MB/1000MB Green LED Off LAN1 at speed 10MB LAN 2...

  • Page 26: Step4-2: Connectors Introduction

    GA-7A8DRH Motherboard Step4-2: Connectors Introduction...
  • Page 27 Connector Introduction A) AXT1 L) WOM1 B) ATX2 M) WOL1 C) IDE1 N) CPU_FAN1 D) IDE2 O) CPU_FAN2 E) USB1 P) COMB F) SYS_FAN1 Q) GSMI1 G) SYS_FAN2 R) IPMB1 H) F_Panel S) IPMB2 I) FDD1 T) SMBUS1 J) PWR_FAN1 U) Battery K) PWR_FAN2...
  • Page 28 GA-7A8DRH Motherboard A ) ATX1 PIN No. Definition +3.3V +3.3V 5VSB +12V +12V +3.3V +3.3V -12V PSON AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
  • Page 29 Connector Introduction C / D) IDE 1/2 Please connect first harddisk to IDE1 and connect CDROM to IDE2. The red stripe of the ribbon cable must be the same side with the Pin1. E) USB1 PIN No. Definition -Data 0 +Data 0 +Data 1 9 10...
  • Page 30 GA-7A8DRH Motherboard F / G) SYS_FAN1/2 (System FAN) SYS_FAN1 Pin No. Definition +12V Sense SYS_FAN2 I) FDD1 (Floppy Connector) Please connect the floppy drive ribbon cables to FDD. It supports 360K,720K,1.2M,1.44M and 2.88Mbytes floppy disk types. The red stripe of the ribbon cable must be the same side with the Pin1.
  • Page 31 Connector Introduction H) F_Panel1 (2X10 Pins) Please connect the power LED, PC speaker, reset switch and power switch etc of your chassis front panel to the front panel jumper according to the pin assignment below. IDE Hard Disk Power Sleep LED Active LED MPD+ HD -...
  • Page 32 GA-7A8DRH Motherboard J / K) PWR_FAN1/2 (Power Fan Connectors) This connector allows you to link with the cooling fan on the system case to lower the system temperature. PWR_FAN2 Pin No. Definition +12V Sense PWR_FAN1 L) WOM1 (Wake on Moderm Connector) Pin No.
  • Page 33 Connector Introduction M) WOL1 (Wake On LAN Connector) This connector allows the remove servers to manage the system that installed this mainboard via your network adapter which also supports WOL. Pin No. Definition +5V SB Signal N / O) CPU_FAN 1/2 (CPU Fan Connectors) Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating.The CPU fan connector supports Max.
  • Page 34 GA-7A8DRH Motherboard P) COMB Pin No. Definition NDCDB NSINB NSOUTB NDTRB NDSRB- NRTSB- NCTSB- NRIB- Q) GSMI1 This connector is for the IPMI function and must bundle with IPMI module.
  • Page 35 Connector Introduction R / S) IPMB1/2 (IPMB Connectors) IPMB2 IPMB1 Pin No. Definition Serial Clock Serial Data T) SMBUS1 (SMBus Connector) Pin No. Definition Data Clock...
  • Page 36 GA-7A8DRH Motherboard U) Battery CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the If you want to erase CMOS... 1.Turn OFF the computer and unplug the power manufacturer’s instructions.

  • Page 37: Step4-3: Jumper Setting Introduction

    Jumper Setting Step4-3: Jumper Setting Introduction 1 ) JP1 4 ) JP7 2 ) JP2 5 ) CLR_CMOS1 (Clear CMOS) 3 ) JP4 PCI-X 66MHz PCI-X 100MHz PCI-X 133MHz PCI-X 1.2 JP2 PIN2-3 short JP2 PIN1-2 short JP2 PIN1-2 short 82545GM JP7 PIN1-2 short JP7 PIN2-3 short...
  • Page 38 GA-7A8DRH Motherboard 1) JP1 (PCI-X Bus Speedy Function) 1-2 close: Enable PCI-X 3 & 4 and SCSI 100/133 Mhz (default) 2-3 close: Enable PCI-X 3 & 4 and SCSI 66Mhz 2) JP2 (PCI-X Bus Speedy Function) 1-2 close: Enable PCI-X 1 & 2 and 545GM 100/133 Mhz (default) 2-3 close: Enable PCI-X 1 &...
  • Page 39 Jumper Setting 3) JP4 (PCI-X Bus Speedy Function) 1-2 close: Enable PCI-X 3 & 4 and SCSI at 100 Mhz (default) 2-3 close: Enable PCI-X 3 & 4 and SCSI at 133 Mhz 4) JP7 (PCI-X Bus Speedy Function) 1-2 close: Enable PCI-X 1&2 and 545GM 100 Mhz (default) 2-3 close:Enable PCI-X 1 &...
  • Page 40 GA-7A8DRH Motherboard 5) CLR_CMOS1 (Clear CMOS Function) You may clear the CMOS data to its default values by this jumper. Default value doesn’t include the “Shunter” to prevent from improper use this jumper. To clear CMOS, temporarily short 1-2 pin.

  • Page 41: Chapter 3 Bios Setup

    BIOS Setup Chapter 3 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.

  • Page 42: Getting Help

    GA-7A8DRH Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.

  • Page 43: Main

    BIOS Setup Main Once you enter Phoenix BIOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu. PhoenixBIOS Setup Utility Main Advanced Security...

  • Page 44: Legacy Diskette A

    GA-7A8DRH Motherboard Legacy Diskette A This category identifies the type of floppy disk drive A that has been installed in the computer. Disabled Disable this device. 360KB, 5 inch AT-type high-density drive; 360K byte capacity 1.2MB, 3 inch AT-type high-density drive; 1.2M byte capacity 720K, 3 inch double-sided drive;...
  • Page 45 BIOS Setup Multi-Sector Transfer This field displays the information of Multi-Sector Transfer Mode. Disabled: The data transfer from and to the device occurs one sector at a time. Auto: The data transfer from and to the device occurs multiple sectors at a time if the device supports it.

  • Page 46: System Memory

    GA-7A8DRH Motherboard System Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512K for systems with 512K memory installed on the motherboard, or 640 K for sy stems with 640K or more memory installed on the motherboard.

  • Page 47: Advanced

    BIOS Setup Advanced PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Boot Summary Screen [Disabled] Item Specific Help Onboard USB controller [Enabled] 4GB Memory Hole Adjust [Auto] 4GB Memory Hole Size [64MB] Multiprocessor Specification [1.4] MP Table uses PCI entries [Yes] After Power Failure [Power On]...
  • Page 48 GA-7A8DRH Motherboard Boot Summary Screen This item displays the system configuration on boot. Enabled Set this item to enabled to displays the system configuration on boot. (Default) Disabled Disable this function. Onboard USB Controller This option allows user to enable onboard USB controller. Note that disabled resources will be freed up or other users.
  • Page 49 Connector and Jumper Setting Introduction MP Table uses PCI entries This option allows user to configure the MP Table with PCI interrupt entries. MP Table uses with PCI interrupt entries. (Default) Disable this function. After Power Failure This option provides user to set the mode of operation if an AC / power loss occurs. Power On System power state when AC cord is re-plugged.

  • Page 50: Chipset Configuration

    GA-7A8DRH Motherboard Chipset Configuration PhoenixBIOS Setup Utility Advanced Chipset Configuration Item Specific Help Setup Warning Setting items on this menu to incorrect values may cause your system to malfunction. DRAM Bank Interleaves [Disabled] Node Memory Interleaves [Disabled] ECC: [Enabled] Dram ECC:...
  • Page 51 BIOS Setup DRAM Bank Interleaves Interleaves memory blocks across dram chip selects. BIOS will auto detect capability on each node. Auto BIOS auto-detection. Disabled Disabling DRAM bank interleaves function. (Default) Node Memory Interleaves Interleaves memory blocks across processor nodes. BIOS will auto detect capability of memory system.
  • Page 52 GA-7A8DRH Motherboard Chip-Kill This option provide user to function Chip-Kill ECC on nodes without all x4 ECC capable DIMMs. Chip-Kill ECC Enabled Enable function. (Default) Disabled Disable this function. DCACHE ECC Scrub CTL This option allows user to set the rates of background scrubbing for DCACHE lines.

  • Page 53: Keyboard Configuration

    BIOS Setup Keyboard Configuration PhoenixBIOS Setup Utility Advanced Keyboard Configuration Item Specific Help NumLock [Auto] Keyboard auto-repeat rate [30/sec] Keyboard auto delay [1/2 sec] F1: Help : Select Item + -: Change Values F5: Setup Defaults Esc: Exit : Select Menu Enter: Select Sub-Menu F10: Save&Exit...

  • Page 54: I/O Device Configuration

    GA-7A8DRH Motherboard I/O Device Configuration PhoenixBIOS Setup Utility Advanced I/O Device Configuration Item Specific Help Serial Port A [Auto] Parallel Port [Auto] PS/2 Mouse [Enabled] F1: Help : Select Item + -: Change Values F5: Setup Defaults Esc: Exit : Select Menu...

  • Page 55: Pci Configuration

    BIOS Setup PCI Configuration PhoenixBIOS Setup Utility Advanced PCI Configuration Item Specific Help PCI Device, Slot #1 PCI Device, Slot #2 PCI Device, Slot #3 PCI Device, Slot #4 PCI Device, Slot #5 PCI Device, Slot #6 82541 PXE Function [Disabled] 82545 PXE Function [Enabled]...
  • Page 56 GA-7A8DRH Motherboard Enable Master Enable selected device as a PCI bus mater. selected device as a PCI bus mater. Enabled Enable (Default) Disabled Disable this function. Latency Timer Minimum guranteed time slice allotted units of PCI bus clocks. Option 0040h (Default), 0020h, 0060h, 00A0h, 00C0h, 00E0h.

  • Page 57: Hardware Monitor

    BIOS Setup Hardware Monitor PhoenixBIOS Setup Utility Advanced Hardware Monitor Item Specific Help System Temperature C /082 CPU0 Temperature C /114 CPU1 Temperature CPU FAN 0 CPU FAN 1 System Fan 1 System Fan 2 Power Fan 1 Power Fan 2 VCORE 1.190V VCC3.3V...
  • Page 58 GA-7A8DRH Motherboard CPU FAN 0 / 1 Speed This field indicates the RPM (Ratio Per Minute) of current CPU 0/1 speed. System FAN 0 / 1 Speed This field indicates the RPM (Ratio Per Minute) of current System 0/1 speed.

  • Page 59: Console Redirection

    BIOS Setup Console Redirection PhoenixBIOS Setup Utility Advanced Console Redirection Item Specific Help Com Port Address [Disabled] Console Connect [Direct] Baud Rate [19.2K] Flow Control [CTS/RTS] Console Type [ANSI] Continue C.R. after POST: [Off] F1: Help : Select Item + -: Change Values F5: Setup Defaults Esc: Exit : Select Menu...

  • Page 60: Flow Control

    GA-7A8DRH Motherboard Baud Rate This option allows user to set the specified baud rate. Options 300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, 115.2K. Flow Control This option provide user to enable the flow control function. None Not supported. XON/OFF Software control.

  • Page 61: Security

    BIOS Setup Security PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Supervisor Password Is: Clear Item Specific Help User Password Is: Clear Set Supervisor Password [Enter] Set User Password [Enter] Password on boot [Disabled] Fixed disk boot sector [Normal] Diskette access [Supervisor] F1: Help : Select Item...
  • Page 62 GA-7A8DRH Motherboard Set User Password You can only enter but do not have the right to change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

  • Page 63: Boot

    BIOS Setup Boot PhoenixBIOS Setup Utility Main Advanced Security Boot Exit + Removable Device Item Specific Help CD-ROM Drive + Hard Drive IBA GE Slot 0018 V1217 IBA GE Slot 0E18 V1217 F1: Help : Select Item + -: Change Values F5: Setup Defaults Esc: Exit : Select Menu...

  • Page 64: Exit

    GA-7A8DRH Motherboard Exit PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Exit Saving Changes Item Specific Help Exit Discarding Changes Load Settup Default Discard Changes Save Changes F1: Help : Select Item + -: Change Values F5: Setup Defaults Esc: Exit...

  • Page 65: Exit Discarding Changes

    BIOS Setup Exit Discarding Changes This option allows user to exit system setup without changing any previous settings values in CMOS. The previous selection remain in effect. This will exit the Setup Utility and restart your compuetr when selecting this option. Press <Enter>...

  • Page 66: Chapter 4 Technical Reference

    GA-7A8DRH Motherboard Revision History Chapter 4 Technical Reference Block Diagram...

  • Page 67: Chapter 5 Application Driver Installation

    Driver Installation Revision History Chapter 5 Application Driver Installation AMD Driver Pack Installation Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe.
  • Page 68 GA-7A8DRH Motherboard 6. In the Driver Selection window, select 5. Select the Destination folder and click the driver you want to intall and click “Next”. “Next”. 7. Ready to install the application. Click 8. Installation completed. Click “Finish” “Next” 9. Click “Yes” to restrat your computer.

  • Page 69: Intel Network Driver Installation

    Driver Installation Intel Network Driver Installation Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. Installation Procedures: 1.
  • Page 70 GA-7A8DRH Motherboard 5.Slect either Typical or Custom Setup 6. Ready to install the program. Click type and click “Install” "Next". Step 5. Note that user can select either Typical or Custom Setup Types. Typical setup type allows users to install basic connectivity and the adapter management utility. Custom setup type embraces installing features and subfeatures user selects, including modern utilities, manage ment components and drivers.

  • Page 71: Scsi Driver Installation

    Driver Installation SCSI Driver Installation Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. 2.Select the folder that the operating you are using.

  • Page 72: Chapter 6 Appendix

    GA-7A8DRH Motherboard Revision History Chapter 6 Appendix Appendix : Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communications Riser BIOS Boot Specification BIOS Basic Input / Output System Central Processing Unit...
  • Page 73 Appendix Acronyms Meaning Input / Output IOAPIC Input Output Advanced Programmable Input Controller Industry Standard Architecture Local Area Network Logical Block Addressing Light Emitting Diode Megahertz MIDI Musical Instrument Digital Interface Memory Translator Hub Memory Protocol Translator Network Interface Card Operating System Original Equipment Manufacturer PCI A.G.P.
  • Page 74 GA-7A8DRH Motherboard Technical Support/RMA Sheet Customer/Country: Company: Phone No.: Contact Person: E-mail Add. : Model name/Lot Number: PCB revision: BIOS version: O.S./A.S.: Hardware Mfs. Model name Size: Driver/Utility: Configuration Memory Brand Video Card Audio Card CD-ROM / DVD-ROM Modem Network...
