Engineering validation test report
Hide thumbs Also See for M6VCT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
E
NGINEERING
CHANGE CONTROL
Description of Change
Initial Release
Project:
M6 VCT VIA 694T For Socket 370 ATX Motherboard
Date:
2001/8/24
Owner:
Biostar Group
TEL: 886-2-2218-0150 FAX: 886-2-2218-1552
Contact:
Home Page:
1
M6 VCT
V
ALIDATION
COVER SHEET
Revision
0.90
1.0
http://www.biostar.com.tw
T
R
EST
EPORT
Sections/Pages Affected
Date
2001/4/24
2001/8/16

Advertisement

Table of Contents
loading

Related Manuals for Biostar M6VCT

Summary of Contents for Biostar M6VCT

  • Page 1 EPORT COVER SHEET CHANGE CONTROL Description of Change Revision Sections/Pages Affected Date Initial Release 0.90 2001/4/24 2001/8/16 Project: M6 VCT VIA 694T For Socket 370 ATX Motherboard Date: 2001/8/24 Owner: Biostar Group TEL: 886-2-2218-0150 FAX: 886-2-2218-1552 Contact: Home Page: http://www.biostar.com.tw...
