2. To bypass the Setup Wizard, select No, and then click Next. The Quick Setup screen displays:
Figure 1-5
3. Enter the settings in each Quick Setup screen. These settings are described in
4. Click Finish to save the settings and reboot the modem router.
The following table describes the settings for the Quick Setup screens.
Table 1-2. Quick Setup Screen Settings
Screen Name
Quick Setup
Configure Internet Connection-
Connection Type
Configure Internet Connection-
WAN IP Settings
Configuring Your Internet Connection
ADSL2+ Modem Router DM111PSPv2 User Manual
Settings
Enter the following settings:
• VPI. The Virtual Path Identifier (VPI) identifies the virtual path
between endpoints in an ATM network. The valid range is from 0 to
255.
• VCI. The Virtual Channel Identifier (VCI) identifies the virtual channel
endpoints in an ATM network. The valid range is from 32 to 65535
(1 to 31 is reserved for well-known protocols).
Enter the following settings. For information about these settings, see
Table 5-3 on page 5-4.
• Protocol
• Encapsulation Type
Enter the following settings. For information about these settings, see
Table 5-1 on page 5-2.
• Obtain IP Address Automatically
• WAN IP Address
• Enable NAT
• MTU
v1.0, December 2008
Table 1-2.
1-7
