cadillac escalade ext
2010
models
Escalade EXT AWD
enGine And drivetrAin
Gen IV 6.2L Vortec V8 VVT engine with Active Fuel Management: 403 hp @ 5700 rpm and 417 lb.-ft. of
torque @ 4300 rpm, E85 FlexFuel-capable
1
All-Wheel-Drive system: 40/60 front/rear torque split and full-time operation
Hydra-Matic 6L80 heavy-duty six-speed automatic transmission with electronically controlled shifts plus
Driver Shift Control manual mode and Tow/Haul mode
Rear locking differential
mAximum cAPAcities And dimensions
Bed height (in.)
Bed length with Midgate up (in.)
Bed length with Midgate down (in.)
Bed width (in.)
Fuel tank (gal. approx.)
Payload (lbs.)
2
Seating
Trailering (lbs.)
3
Key stAndArd FeAtures
exterior, chAssis And susPension
brakes Four-wheel disc, antilock braking system, twin-piston front calipers
Frame All-welded, fully boxed ladder-type
level control Automatic electronic rear level control system
lighting system Xenon High-Intensity Discharge (HID) headlamps and halogen fog lamps
mirrors Exterior rearview, heated, power-adjustable, power-folding, curb view assistance, LED turn-signal
indicators, puddle lamps and automatic dimming driver side
road-sensing suspension Coil-over-shock front/5-link rear with bi-modal monotube shocks and computer-
controlled real-time damping
stabilitrak With rollover mitigation Computer-controlled, four-channel electronic stability control system
traction control All-speed with brake and engine intervention
ultrasonic rear Parking Assist
interior
Adaptive remote start/Keyless Access Includes two remote transmitters, remote start, climate control
system and heated seat activation
Silver Lining
1 E85 is a combination of 85% ethanol and 15% gasoline. Go to gm.com/biofuels to see if there is an E85 fuel station near you. 2 Maximum payload capacity includes weight of driver, passengers, optional equipment and cargo. 3 Maximum trailer weight ratings are calculated
assuming a base vehicle, plus driver. See your Cadillac dealer for additional details. 4 Always use safety belts and the correct restraint for your child's age and size. Even in vehicles equipped with the Automatic Occupant Sensing System, children are safer when properly secured in a
rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with a passenger air bag. See the Owner's Manual and child safety seat instructions for more safety information. 5 Go to gm.com/bluetooth
to find out which phones are compatible with the vehicle. 6 Map coverage available in the United States, U.S. Virgin Islands, Puerto Rico and Canada. 7 Call 1-888-4ONSTAR (1-888-466-7827) or visit onstar.com for details and system limitations. 8 Not available in certain areas.
Visit onstar.com for coverage map. 9 OnStar Hands-Free Calling requires a Hands-Free Calling-enabled vehicle, existing OnStar service contract and prepaid minutes or enrollment in a shared minutes plan. Not available in certain markets. Calls may be made to the U.S. and Canada
only. 10 XM Radio requires a subscription, sold separately by XM after the first 90 days. XM Radio U.S. service only available in the 48 contiguous United States and the District of Columbia. For more information, visit gm.xmradio.com. 11 Use only GM-approved tire and wheel
combinations. Unapproved combinations may change the vehicle's performance characteristics. For important tire and wheel information, go to gmaccessorieszone.com or see your dealer for details.
GM, the GM Logo, Cadillac, the Cadillac Logo, and the slogans, emblems, vehicle model names, vehicle body designs and other marks appearing in this document are the trademarks and/or service marks of General Motors, its subsidiaries, affiliates or licensors. Bose, AudioPilot
and Cabin Surround are registered trademarks of the Bose Corp. OnStar and Directions & Connections are registered trademarks of OnStar LLC. The Bluetooth word mark is a registered trademark owned by Bluetooth SIG, Inc. and any use of such mark by Cadillac is under
license. SIRIUS, XM and all related marks and logos are trademarks of SIRIUS XM Radio Inc. and its subsidiaries. ©2010 General Motors. All rights reserved. GM reserves the right to make changes at any time and without notice in prices, colors, materials, equipment, specifications,
models and availability.
select sPeciFicAtions
AvAilAble exterior colors (Premium color requires AdditionAl cost)
interior (continued)
Adjustable Pedals Power-adjustable, with memory
Air bags
Dual-stage driver and front passenger, front-impact; Automatic Occupant Sensing System; driver
4
and front passenger seat-mounted side-impact for thorax and pelvic protection; and head-curtain side-
impact with rollover protection for all outboard passenger rows
Audio system Bose® 5.1 Cabin Surround® Sound System; AudioPilot® noise compensation technology;
eight speakers equalized to Escalade's interior; steering wheel audio controls; independent rear-seat audio
controls with two earphone jacks
bluetooth® Wireless technology
climate control Dual-zone automatic electronic with individual settings for driver and front passenger
dvd-based navigation
6
Full-featured 8-inch-diagonal touch-screen DVD-based navigation system
25.0
driver information center (dic)
63.0
onstar
7
Directions & Connections Plan with Turn-by-Turn Navigation
97.6
rearview camera Automatic operation when vehicle is put in Reverse
50.0
seating Front seats with leather seating surfaces, heated and cooled seatbacks and cushions with three
31
temperature settings, 14-way power-adjustable, including four-way power lumbar; and memory settings
1,150
for two drivers
5
seating Second-row bench seat with folding center armrest and leather seating surfaces
7,500
steering Wheel controls Audio system, cruise control, OnStar
tilt Wheel Power-adjustable steering column
tire Pressure monitoring system Includes individual sensors with specific pressures displayed in Driver
Information Center
xm radio
With three trial months
10
Premium collection
Power-retractable running boards
rear-seat entertainment system In-dash DVD with roof-mounted flip-down 8-inch-diagonal screen, two
2-channel wireless headphones, auxiliary audio/video jacks, remote, and game plug-in
luxury collection
lighting system IntelliBeam headlamps with automatic high-/low-beam switching
magnetic ride control Coil-over-shock front/5-link rear with magneto-rheological fluid-filled shocks and
computer-controlled real-time damping
steering Wheel Heated
sunroof Power, tilt-sliding with Express-Open/-Close and sunshade
Wheels 22-inch
seven-spoke chromed aluminum with P285/45R22 blackwall performance touring tires
11
Black Raven
To learn more, please visit
5
For select phones
8
standard for the first year
7
and Hands-Free Calling
White Diamond Tricoat
(Premium color)
2010
ESCALADE Ext
cAdillAc.com
9
buttons
10CADEXTSPE02
