6
Touch a picture you want for the back-
ground.
7
Select how to display the picture.
You can select the following items:
"Center":
Selected picture is displayed at the center of
the screen.
"Repeat":
Selected picture is repeated in a pattern to
cover the whole screen.
The background image starts changing. After
a short while, the new background image
appears.
❒ When you select images stored on the Pio-
neer DVD Map Disc, you cannot select the
layout method.
❒ When the picture starts to change, do not
turn off the vehicle engine until the mes-
sage appears to indicate that the picture
has finished changing.
8
Touch "Done".
On this screen, you can select the following
items:
"Select another Picture":
This is selected when you want to change to
another picture. Return to Step 5.
"Change another background":
Select if you want to successively change the
Splash Screen, Audio Operating screen back-
grounds or the navigation backgrounds.
Return to step 3.
❒ When the navigation system is reset, or the
language setting is changed, the back-
ground picture may change back to the
original picture. (There is also a possibility
that the system will revert to the original
picture for some other reason). If this hap-
pens, set the background picture again.
Setting the Vehicle Dynamics
Display
You can change the values displayed by the
instruments on the left and right of the Vehicle
Dynamics Display.
Until the sensor's initial learning is complete,
only the voltage and clock are available.
1
Switch to the Vehicle Dynamics Display.
➲ Changing the map display mode ➞
Page 35
2
Touch the left or right instrument.
Touch keys are displayed.
3
Touch the items you want to display.
You can select the following items.
Voltage:
Displays the power supply and voltage sup-
plied from the battery to this system.
Acceleration:
Displays acceleration in a forward direction.
The + sign indicates acceleration while the –
sign indicates deceleration.
Side Acceleration:
Displays acceleration in a side direction, such
as when turning. The + sign indicates a right
turn, while the – sign indicates a left turn.
Angular Velocity:
Displays the vehicle's turning angle over one
second (how far it has turned in a second).
Slope:
Displays the vehicle's vertical movement. The
+ side represents the rising angle, and the –
side the falling angle.
Direction:
Displays the direction your vehicle is traveling
in.
Clock:
Displays the current time.
67
