1.4 Panel Layout
1.4.1 The Front Panel
The Router's LEDs and the QSS button are located on the front panel (View from left to right).
Name
PWR
SYS
WLAN
WAN,
LAN 1-4
Slow Flash
QSS
Quick Flash
Note:
After a device is successfully added to the network by QSS function, the QSS LED will keep on for
about 5 minutes and then turn off.
TL-WR743ND
Figure 1-1 Front Panel sketch
Status
Off
Power is off.
On
Power is on.
On
The Router is initializing.
Flashing
The Router is working properly.
Off
The Router has a system error.
Off
The Wireless function is disabled.
Flashing
The Wireless function is enabled.
Off
There is no device linked to the corresponding port.
There is a device linked to the corresponding port but
On
there is no activity.
Flashing
There is an active device linked to the corresponding port.
A wireless device is connecting to the network by QSS
function. This process will last for about 2 minutes.
A wireless device has been successfully added to the
On
network by QSS function. The LED will keep on for about
5 minutes.
A wireless device failed to be added to the network by
QSS function.
Table 1-1 The LEDs Description
150Mbps Wireless AP/Client Router
Indication
- 4 -
