chapter 5
What is on
the ScanGear CS
Main Window?
Top Page
Glossary
Contents
Index
• Units. Click the down-arrow and select a unit to measure the
scanning area. Changing the Units setting does not affect the
image in the Preview Area.
• Width and Height. The width and height of the current
selection, or if there is no selection, the maximum output
size, measured from the upper left corner of the image in the
Preview Area and based on the current paper size. To change
the Width and Height settings, click the Crop button on the
toolbar and select a section of the image in the preview area,
or just type the desired dimensions into the Width and
Height text boxes.
• Scale. Allows you to specify the output size of the selected
image 25% to 200% (preset to 100%) as a percentage of the
original Width and Height. Click the up or down arrow to
increase or decrease the percentage. If the image in the
Preview Area is 4" x 2" and you select 50% then the output
image will be 2" x 1".
44
