chapter 4
The ScanGear CS
Settings
Top Page
Glossary
Contents
Index
The Tabs and Sheets
4
Click the Main tab, Tone tab, or the Scanner tab to open the Main
sheet, Tone sheet, or Scanner sheet. Use the settings on each
sheet to perform important settings for scanning.
The name of your scanner (FB630U or FB636U) will
appear on the Scanner tab.
Note
Status Bar
5
Reading from left to right, the status bar displays the following
important information:
• Message Area: Displays messages about the current status of
the driver or a simple explanation of the button or setting
you point to.
• Scan Mode: Displays the option selected for the Scan Mode
on the Main sheet.
• Resolution: Displays the option selected for Scan Resolution
on the Main sheet.
• Width: Displays the current Width setting in the Selection
box on the Main sheet.
• Height: Displays the current Height setting in the Selection
box on the Main sheet.
• Size: Displays the file size of the uncompressed image with
the current settings you have selected.
31
