24 VAC SYSTEM CONTROL KIT
Designed for use on SWG Series Power Vent Hoods for controlling Natural
Gas and L.P. Gas State Industries water heaters.
I
TEMS INCLUDED IN KIT
1) Junction box with mounted pressure switch and relay base.
1) 24 VAC Relay
1) Ft. Length of 1/4 inch aluminum tubing
1) 1/4 inch tubing connector
1) Flexible conduit connector
1) GSK-3 Spillage Switch
THESE INSTRUCTIONS MUST REMAIN WITH EQUIPMENT
Model: CK-51
:
DO NOT DESTROY
Advertisement
Related Manuals for Field Controls 46298500
Summary of Contents for Field Controls 46298500
- Page 1 24 VAC SYSTEM CONTROL KIT Model: CK-51 Designed for use on SWG Series Power Vent Hoods for controlling Natural Gas and L.P. Gas State Industries water heaters. TEMS INCLUDED IN KIT 1) Junction box with mounted pressure switch and relay base. 1) 24 VAC Relay 1) Ft.
-
Page 2: Mounting Junction Box
MOUNTING JUNCTION BOX The junction box can be mounted at the venter or remotely mounted away from the venter. (See Figure 1 & Figure 2) 1. Remove one of the knockouts from the side of the junction box where the pressure switch is mounted. - Page 3 WIRING (See Diagrams A-C State Industries Water Heaters) Wire the venter motor and controls in accordance with the National Electrical Code, manufacturer's recommendations and/or applicable local codes. UNITS MUST BE GROUNDED. Check ground circuit to make certain that the unit has been properly grounded.
- Page 4 Diagram B Page 4...
- Page 5 Diagram C Page 5...
-
Page 6: Pressure Switch Adjustments
PRESSURE SWITCH ADJUSTMENTS With the venter airflow set and the appliance operating at the best operating efficiency, adjust the pressure switch by rotating the adjustment screw clockwise until the burner shuts off, then rotate the adjustment screw counterclockwise until the burner fires. Rotate the adjustment screw an additional 1/4 turn counterclockwise to ensure proper switch setting. - Page 7 INSTALLATION INFORMATION CK-51 MODEL NO.:_____________________________________________________________ INSTALLER'S NAME:______________________________________________________ INSTALLER'S COMPANY:__________________________________________________ INSTALLER'S PHONE NO.:_________________________________________________ DATE OF INSTALLATION: _________________________________________________ Page 7...
- Page 8 Page 8 P/N 46298500 Rev A 01/01...
