Card Turn Up
Follow the steps in this section to verify card turn up. If one or more of the Cisco Transport Controller
(CTC) software screen conditions according to
on page 7
Verify Successful Turn Up of the TCC-I Card
Verify that power is applied to the shelf assembly.
Step 1
Verify that the TCC-I card has been installed in the correct slot (Slot 7 or slot 11).
Step 2
The TCC-I card takes several minutes to reboot and display the amber standby LED after rebooting.
Note
Note When a second TCC-I card is inserted into the shelf, it will synchronize its software, its backup
software, and its database with the active TCC-I.
If its software version does not match the version on the active TCC-I, the newly inserted TCC-I will
copy from the active TCC-I. This copying will take about 15 to 20 minutes.
If its backup software version does not match the version on the active TCC-I, the newly inserted
TCC-I will copy the backup software from the active TCC-I. This copying, again, will take about 15
to 20 minutes.
Copying the database from the active TCC-I will take about 3 minutes.
So, depending on the software existing in the new TCC-I, booting it up will take between 3 and about
40 minutes.
Verify that the card appears in the correct slot on the CTC software screen.
Step 3
Verify that the card is white on the CTC software screen.
Step 4
Verify that the card is shown in Inventory on the CTC software screen.
Step 5

Removal Procedures

Use this section if you are installing or removing the TCC-I card for the first time. After you become
familiar with ONS 15454 SDH card installation and boot up, use this section as a reference.
Always use the supplied electrostatic discharge (ESD) wristband when working with an ONS 15454
Caution
SDH. Plug the wristband cable into the ESD jack located on the lower right outside edge of the shelf
assembly and ensure the shelf assembly is properly grounded.
Hazardous voltage or energy may be present on the backplane when the system is operating. Use caution
Caution
when servicing.
78-14610-01
are not met, re-install the card. Replace the unit if the faulty state persists.
"Verify Successful Turn Up of the TCC-I Card" section
Installing ONS 15454 SDH TCC-I Cards
Removal Procedures
