Momentum Cyclonic
B A G L E S S
U S E R ' S G U I D E
3 9 1 0 S E R I E S 2 2 0 - 2 4 0 V
3
Safety Instructions
4
Product View
5-6
Assembly
6-9
Operation
10-16
Maintenance and Care
17
Troubleshooting
18
Consumer Services
19
Replacement Parts
20
Warranty
ug603-2377_3910E_207.indd 1
ug603-2377_3910E_207.indd 1
V A C U U M
2/7/07 4:03:31 PM
2/7/07 4:03:31 PM
Advertisement
Table of Contents
Related Manuals for Bissell 3910
Summary of Contents for Bissell 3910
- Page 1 Momentum Cyclonic B A G L E S S V A C U U M U S E R ’ S G U I D E 3 9 1 0 S E R I E S 2 2 0 - 2 4 0 V Safety Instructions Product View Assembly...
- Page 2 Your BISSELL vacuum is well made, and we back it with a limited one year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll...
-
Page 3: Important Safety Instructions
(Spares may be obtained from Not intended for use by young children or infirm your BISSELL supplier). If for any reason the plug is cut persons without supervision. off, it must be disposed of, as it is an electric shock ■... -
Page 4: Product View
roduct view Handle Quick Release ™ Cord Wrap Hose and Cord Clip Dusting Brush/ Upholstery Tool Power Cord Carry Handle Stretch Hose Twist ‘n Crevice Tool Snap ™ Extension Wand Hose TurboBrush ™ Clean Filter Indicator Power Switch Curved (Select Models Only) Hose Wand Upper Tank... -
Page 5: A Ssembling Your Vacuum
CAUTION: ssembling your vacuum Do not plug in your vacuum cleaner until The only tool you’ll need to assemble your you are familiar with vacuum cleaner is a Phillips screwdriver. all instructions and Attach handle to vacuum operating procedures. Locate the handle and cord wrap. Remove the screw packet taped to the cord wrap. -
Page 6: Operation
ssembling your vacuum Twist 'n Snap Hose Attach vacuum hose and tools Line up the tabs on the base of the Twist ‘n Snap hose with the corresponding notches on the hose collar as shown. Turn the Twist ‘n Snap hose to the left to lock the hose into place. -
Page 7: Handle Positions
peration Handle positions Press the handle release pedal, located on the lower left side of the vacuum, with your foot to place your vacuum into one of three cleaning positions. Upright – For storage and above floor cleaning with tools. Tip: Normal Cleaning –... -
Page 8: Special On-Board Tools
peration Clean filter indicator Select Models Only The clean filter indicator tells you when the airflow in your vacuum is reduced due to dirty filters or a clog in the hose. The clean filter indicator will remain Clean green while the unit is running until the airflow is Filter reduced by a clog or dirty filter. - Page 9 peration Crevice Tool: Use in tight narrow spaces. Extension Wand: Use with desired attachment for a longer reach. Curved Hose Wand: Use with desired attachment for a longer reach or for cleaning hard to reach places. ™ TurboBrush : Use rotating brush action for small Tip: areas such as stairs and upholstery.
-
Page 10: Maintenance And Care
aintenance and care To maximize your cleaning performance and extend the life of your vacuum, it is very WARNING: important that you empty your dirt container and check and clean your filters frequently. To reduce the risk of electric Perform the following maintenance steps: shock, turn power switch OFF Empty the dirt container when the dirt reaches and disconnect plug from... - Page 11 aintenance and care Cleaning the pre-motor and post-motor HEPA media filter Unplug the vacuum from electrical outlet. The pre-motor filter protects the motor from dirt particles. It is located in the slide out tray underneath the dirt container. If the filter becomes dirty, pull out the tray, lift out the foam filter pad and clean it.
- Page 12 aintenance and care Check rotating floor brush and drive belt You should check your vacuum cleaners WARNING: rotating floor brush and drive belt regularly for wear or damage. You should also clean To reduce the risk of injury the brush and brush ends of strings, hair from moving parts, turn and carpet fibers.
- Page 13 Motor Pulley brush in the space between the bristles. NOTE: It is important that you use only genuine BISSELL replacement belts. Generic belts may not meet the exacting specifications required to keep your vacuum operating at its peak performance.
- Page 14 aintenance and care Maintaining TurboBrush The TurboBrush should be checked regularly for clogs or debris wrapping around the brush. Unplug the vacuum from electrical outlet. If a clog is present or debris is visible, unscrew the two screws on the back of the TurboBrush to remove the faceplate and clear any obstructions.
-
Page 15: Clearing Clogs
aintenance and care Clearing clogs Low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor, check for clogs. Unplug the vacuum from electrical outlet. Empty dirt container. - Page 16 aintenance and care Cleaning the upper tank Unplug the vacuum from electrical outlet. Remove the dirt container as instructed in "Empty Dirt Container" on page 10. Using a short Phillips screwdriver, take off the separator plate by removing the two screws that secure it to the upper tank.
-
Page 17: Troubleshooting
Other maintenance or service not included in the manual should be performed by an authorized service representative. Thank you for selecting a BISSELL product. Please do not return this product to the store. w w w . b i s s e l l . c o m ug603-2377_3910E_207.indd 17... - Page 18 In the UK, Australia, or New Zealand, call BISSELL Consumer Services at the numbers below and we will give you the location of a BISSELL Authorized Service Center in your area. For all other countries, contact your local in country distributor for questions, service, or repair.
-
Page 19: Replacement Parts
eplacement parts Item Part No. Part Name 32074 Style 7/9/10/12/14 Drive Belt (2-Pack) 203-1297 Headlight Bulb 203-1063 Crevice Tool 203-1228 Dusting Brush/Upholstery Tool 203-2302 TurboBrush, clear top with black brush roll 203-1022 Extension Wand 203-2303 Curved Hose Wand 203-2304 Twist 'n Snap Vacuum Hose (clear) 203-2305 Wide Window Foot Brush Roll (gray) 3290... -
Page 20: Limited One Year Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL Homecare, Inc., will replace (with new or remanufactured components), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for one year any defective or malfunctioning part do to manufacturers defect.
