USER GUIDE
PrintServer for USB
with 4-Port Switch
PSUS4
Model:

Advertisement

Table of Contents
loading

Related Manuals for Linksys PSUS4 - PrintServer For USB

Summary of Contents for Linksys PSUS4 - PrintServer For USB

  • Page 1 USER GUIDE PrintServer for USB with 4-Port Switch PSUS4 Model:...

  • Page 2: About This Guide

    Glossary www.linksys.com/glossary Network Security www.linksys.com/security Copyright and Trademarks Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Product Overview Front Panel..........1 Back Panel .

  • Page 4: Chapter 1: Product Overview

    PrintServer to the factory default settings, Product Overview or to generate a diagnostic printout. To reset the factory default settings: Thank you for choosing the Linksys PrintServer for USB Unplug the PrintServer. with 4-Port Switch (PrintServer). The PrintServer will allow you to network your printers.

  • Page 5: Chapter 2: Configuration

    Configuration Chapter 2 The Setup Tab Chapter 2: The Setup screen is the first screen you see when you Configuration access the web-based utility. This screen allows you to change the PrintServer ‘s general settings. The PrintServer has been designed to be functional right out of the box with the default settings in the Setup Wizard.

  • Page 6: The Protocol Tab > Tcp/Ip

    Configuration Chapter 2 The Protocol Tab > TCP/IP allows computers to talk to each other using Ethernet. Typically only Macintosh computers use AppleTalk, Click the TCP/IP tab to view or change the TCP/IP values of although other platforms can be made to use it with extra the PrintServer.

  • Page 7: The Printer Tab > Internet Printing

    Configuration Chapter 2 Mail Server Domain Name Enter the name of the domain that you want to associate with the PrintServer. If you are unsure of Mail Server IP Address Enter the address of your mail the Domain Name, you can find it out by looking on any server in the Mail Server IP Address.

  • Page 8: The Status Tab > Device

    Configuration Chapter 2 Select Printer Logical Printer No: In the drop-down menu, select the logical printer number (1-3) you wish to configure. Click Get Data to update the display with the current data for the selected logical printer. Details Pre-string (Hex) Enter the printer control string (in hexadecimal characters) to be sent to the printer before each print job.

  • Page 9: Chapter 3: Internet Printing Protocol

    Internet Printing Protocol Chapter 3 Chapter 3: Internet Printing Protocol Overview Internet Printing Protocol (IPP) is a new standards- based system to allow remote printing from a PC to any accessible printer. Normally, the printer will be attached to a computer or other device that functions as an IPP Server. For client PCs, it is necessary to install a compatible IPP Client program.
  • Page 10 Internet Printing Protocol Chapter 3 To create additional IPP ports, repeat the entire • procedure. • The Proxy Server and other options are set individually for each IPP Port. Changing the IPP Port Settings After the IPP port is created, you can reach the Configure IPP Port screen by performing these steps: Open the Printers folder (click Start, click Settings,...
  • Page 11 Internet Printing Protocol Chapter 3 A printer problem has caused the IPP Server to cease • responding, and a restart (reboot) is required. • The Server’s IP Address has changed. • The Internet connection for the IPP Server is down. •...

  • Page 12: Chapter 4: Bi-Admin Management

    Bi-Admin Management Chapter 4 Chapter 4: Bi-Admin Management Overview The PrintServer is managed by a utility program called Bi-Admin on the PrintServer’s Setup CD. Fully compatible with Windows 98, Me, 2000, and XP, Bi-Admin allows you to change the PrintServer’s internal settings, check the unit’s status, and perform basic diagnostic tests.

  • Page 13: Starting The Bi-Admin Management Utility

    Bi-Admin Management Chapter 4 The Bi-Admin Management Utility Setup Complete When the Bi-Admin is installed, the screen will appear. Click Finish to continue. The Bi-Admin Management Utility screen will appear next. Any hardware found on the network will appear on the left-hand side of the screen.
  • Page 14 PrintServer. Follow these instructions to upgrade your PrintServer’s firmware: Download the firmware to your computer from the Verify Password Linksys website at www.linksys.com. After the password is successfully entered, the Printer Open the Bi-Admin Management utility. Status screen will appear. The Device Name will be Click Main, and then click Upgrade Firmware.
  • Page 15 Bi-Admin Management Chapter 4 Main Menu > Configuration Screen Tabs TCP/IP • You first need to specify whether the PrintServer’s IP The Configuration screen displays six tabs: System, TCP/IP, address will be automatically assigned via DHCP, or if it Apple Talk, NETBEUI, Internet Printing, and Port. The tabs is a fixed (also called static) IP address.
  • Page 16 Bi-Admin Management Chapter 4 To find your router’s IP address, consult your router’s NetBEUI • documentation. The IP Address and Subnet Mask are the same as those of any PC connected to the network. If you change the PrintServer’s IP address, make sure you that you reconnect to the PrintServer using the new IP address.
  • Page 17 Bi-Admin Management Chapter 4 Internet Printing Port • • Configuration > Internet Printing Tab Configuration > Port Tab Enter the address of your mail server in the Mail Server Select the number of the Selected Physical Port from IP Address field. (This value must be a fixed IP address.) the drop-down menu.
  • Page 18 Bi-Admin Management Chapter 4 InitDevice Option When you select InitDevice from the menu bar, these options are displayed: Reset Device • Restore to Factory Default • Attached Remote • Connected Protocol • If you click Attached Remote, the Attached Remote screen appears.

  • Page 19: Appendix A: Troubleshooting

    In order to upgrade the firmware with the latest features, in this chapter. If you have trouble printing, make sure that you need to go to the Linksys website and download the all Ethernet and USB cables connected to the PrintServer latest firmware at www.linksys.com.

  • Page 20: Appendix B: Specifications

    Specifications Appendix B Appendix B: Specifications Model PSUS4 Ports 4 10/100 RJ-45 Ports Auto MDI/MDI-X, USB, Power Buttons Reset LEDs Status, USB, 1-4 Cabling Type Category 5 or better, USB 1.1 cable with Type-B female and Type-A male connectors Environmental Dimensions 3.66"...

  • Page 21: Appendix C: Warranty Information

    Linksys’ entire liability under this limited warranty jurisdiction. will be for Linksys, at its option, to (a) repair the product TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT with new or refurbished parts, (b) replace the product...
  • Page 22 This limited warranty is governed by the laws of the jurisdiction in which the Product was purchased by you. Please direct all inquiries to: Linksys, P.O. Box 18558, Irvine, CA 92623. PrintServer for USB with 4-Port Switch...

  • Page 23: Appendix D: Regulatory Information

    Regulatory Information Appendix D Avis d’Industrie Canada Appendix D: Regulatory Information Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Le fonctionnement est soumis aux conditions suivantes : FCC Statement Ce périphérique ne doit pas causer d’interférences; This product has been tested and complies with the Ce périphérique doit accepter toutes les interférences specifications for a Class B digital device, pursuant to Part...

  • Page 24: User Information For Consumer Products Covered By Eu Directive 2002/96/Ec On Waste Electric And Electronic Equipment (Weee)

    úřady. Správná likvidace a recyklace pomáhá předcházet Linksys products. Consumers are required to comply with potenciálním negativním dopadům na životní prostředí a lidské this notice for all electronic products bearing the following zdraví.
  • Page 25 Regulatory Information Appendix D Eesti (Estonian) - Keskkonnaalane informatsioon Français (French) - Informations environnementales Euroopa Liidus asuvatele klientidele pour les clients de l’Union européenne Euroopa Liidu direktiivi 2002/96/EÜ nõuete kohaselt on La directive européenne 2002/96/CE exige que l’équipement seadmeid, millel on tootel või pakendil käesolev sümbol sur lequel est apposé...
  • Page 26 Regulatory Information Appendix D Lietuvškai (Lithuanian) - Aplinkosaugos informacija, Nederlands (Dutch) - Milieu-informatie voor klanten skirta Europos Sąjungos vartotojams in de Europese Unie Europos direktyva 2002/96/EC numato, kad įrangos, kuri ir De Europese Richtlijn 2002/96/EC schrijft voor dat apparatuur die kurios pakuotė...
  • Page 27 ľudí. Ak máte záujem o podrobnejšie WEB: For additional information, please visit informácie o likvidácii starého zariadenia, obráťte sa, prosím, na www.linksys.com miestne orgány, organizácie zaoberajúce sa likvidáciou odpadov alebo obchod, v ktorom ste si produkt zakúpili. PrintServer for USB with 4-Port Switch...

  • Page 28: Appendix E: Software End User License Agreement

    Software End User License Agreement Appendix E Appendix E: Software End THE RETURN PROCESS AND POLICIES OF THE PARTY FROM WHICH YOU PURCHASED SUCH PRODUCT OR SOFTWARE. User License Agreement IN THE EVENT THAT YOU HAVE ELECTED TO OBTAIN A SUBSCRIPTION LICENSE, AS INDICATED IN YOUR ORDER, YOU ADDITIONALLY AGREE TO BE BOUND BY THE “TERMS Cisco Products...
  • Page 29 Software End User License Agreement Appendix E of the Software or its related Documentation, or business dealings with, or participation in promotions electronically transfer the Software or Documentation of advertisers found through the Software and any from one computer to another or over a network; (ii) alter, other terms, conditions, warranties, or representations merge, modify, adapt, decrypt or translate the Software or associated with such dealings, are solely between you and...
  • Page 30 Software End User License Agreement Appendix E In addition, Cisco may collect and store detailed IS PROVIDED “AS IS” WITH ALL FAULTS AND WITHOUT information regarding your network configuration WARRANTY OF ANY KIND. Without limiting the foregoing, and usage for the purpose of providing you technical Cisco does not warrant that the operation of the product networking support.
  • Page 31 Service. in any purchase order or elsewhere. 4. WARRANTY DISCLAIMER FOR SERVICES. TO THE Linksys, Cisco and the Cisco Logo and other trademarks EXTENT NOT PROHIBITED BY APPLICABLE LAW THE contained in the Software and Documentation are SERVICES ARE PROVIDED ON AN “AS-IS”...
  • Page 32 Software End User License Agreement Appendix E TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND freedom to share and change free software--to make sure the software is free for all its users. This General Public MODIFICATION License applies to most of the Free Software Foundation’s This License applies to any program or other work software and to any other program whose authors which contains a notice placed by the copyright...
  • Page 33 Software End User License Agreement Appendix E If the modified program normally reads commands Accompany it with the information you received as interactively when run, you must cause it, when to the offer to distribute corresponding source code. started running for such interactive use in the most (This alternative is allowed only for noncommercial ordinary way, to print or display an announcement distribution and only if you received the program...
  • Page 34 Software End User License Agreement Appendix E If, as a consequence of a court judgment or allegation not specify a version number of this License, you of patent infringement or for any other reason (not may choose any version ever published by the Free limited to patent issues), conditions are imposed on Software Foundation.
  • Page 35 Software End User License Agreement Appendix E GNU LESSER GENERAL PUBLIC LICENSE To protect each distributor, we want to make it very clear that there is no warranty for the free library. Also, if the Version 2.1, February 1999 library is modified by someone else and passed on, the recipients should know that what they have is not the Copyright (C) 1991, 1999 Free Software Foundation, Inc.
  • Page 36 Software End User License Agreement Appendix E freedom and the wherewithal to run that program using a You may copy and distribute verbatim copies of the modified version of the Library. Library’s complete source code as you receive it, in any medium, provided that you conspicuously and The precise terms and conditions for copying, distribution appropriately publish on each copy an appropriate...
  • Page 37 Software End User License Agreement Appendix E Thus, it is not the intent of this section to claim When a “work that uses the Library” uses material from rights or contest your rights to work written entirely a header file that is part of the Library, the object code by you;...
  • Page 38 Software End User License Agreement Appendix E Use a suitable shared library mechanism for linking You may not copy, modify, sublicense, link with, or with the Library. A suitable mechanism is one that distribute the Library except as expressly provided (1) uses at run time a copy of the library already under this License.
  • Page 39 Software End User License Agreement Appendix E software distributed through that system in reliance NO WARRANTY on consistent application of that system; it is up to BECAUSE THE LIBRARY IS LICENSED FREE OF CHARGE, the author/donor to decide if he or she is willing to THERE IS NO WARRANTY FOR THE LIBRARY, TO THE distribute software through any other system and a EXTENT PERMITTED BY APPLICABLE LAW.
  • Page 40 Software End User License Agreement Appendix E The OpenSSL toolkit stays under a dual license, i.e. both This product includes cryptographic software written by the conditions of the OpenSSL License and the original Eric Young (eay@cryptsoft.com). This product includes SSLeay license apply to the toolkit. See below for the software written by Tim Hudson (tjh@cryptsoft.com).
  • Page 41 Software End User License Agreement Appendix E BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
