MSI P35 NEO2-FR - Motherboard - ATX User Manual page 59

running programs, it will speed up automatically to make the program run smoothly
and faster. W hen the system is temporarily suspending or staying in the low load
balance, it will restore the default settings instead. Usually the Dynamic Overclocking
Technology will be powered only when users' PC need to run huge amount of data
like 3D games or the video process, and the CPU and PCIE frequency need to be
boosted up to enhance the overall performance.
CPU D.O.T3 step1/2/3 setting
Due to D.O .T can detec t the CPU loading and increase the f requency with 3
overclocking steps. These items allow users to select the speed up range of each
step.
PCIE D.O.T3 step1/2/3 setting
Due to D.O.T can detec t the PCIE loading and increas e the frequenc y with 3
overclocking steps. These items allow users to select the speed up range of each
step.
Important
Even though the Dynamic Overclocking Technology is more stable than
manual overclocking, basically, it is still risky. We suggest user to make
sure that your CPU can afford to overclocking regularly first. If you find the
PC appears to be unstable or reboot incidentally, it's better to disable the
Dynamic Overclocking or to lower the level of overclocking options. By the
way, if you need to conduct overclocking manually, you also need to disable
the Dynamic OverClocking first.
Intel EIST
The Enhanced Intel SpeedStep technology allows you to set the performance level of
the microprocessor whether the computer is running on battery or AC power. This
field will appear after you installed the CPU which support speedstep technology.
Adjust CPU FSB Frequency
This item allows you to set the CPU FSB frequency (in MHz).
Adjust CPU Ratio
This field appears only when the CPU supports this function. It is adjustable only
when Intel EIST set to Disable. This item allows you to set the CPU ratio.
Adjusted CPU Frequency
It shows the adjusted CPU frequency (FSB x Ratio). Read-only.
Advance DRAM Configuration
Press <Enter> to enter the sub-menu and the following screen appears.
BIOS Setup
3-21
