Gigabyte GSmart MW702 Quick Manual

Quick guide - gsmart mw702 english version
Hide thumbs Also See for GSmart MW702:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Manual

Getting to Know Your Device

No.
Item
1
Touch Screen
2
Talk/Send Key
Function
Display screen. Use
stylus to select items on
the screen.
You can make or
answer a call by
pressing Talk/Send key,
or go to Phone Dialer
screen.
3
End Key
Windows Flag
4
Key
5
GPS Key
6
Navigation Key
7
LED Indicator1
8
LED Indicator2
MW702│01
Press this key to end a
call or to return to
Today screen from any
screen.
Press the Windows
key to open Start menu
options.
Long press this key to
execute GPS function
or application. OK as
default.
Press up, down, left
and right directions to
navigate. Tap the
center key to execute
the selected function or
application.
The LED indicator
indicates the status of
your device by showing
different colors.
Green: Mobile network
is detected.
Red: Charging
activated.
The LED indicator
indicates the status of
your device by showing
different colors.
Blue: Bluetooth is
activated.
Orange: Wi-Fi is
activated.
Purple: Notification,
GPS signal is detected.

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte GSmart MW702

Summary of Contents for Gigabyte GSmart MW702

  • Page 1: Getting To Know Your Device

    Getting to Know Your Device Press this key to end a call or to return to End Key Today screen from any screen. Press the Windows Windows Flag key to open Start menu options. Long press this key to execute GPS function GPS Key or application.
  • Page 2 Press and hold Power Micro SD card You can insert your key for a few seconds slot Micro SD card here. Power On/Off to power on/off your Plug in headset, and device. then you can listen to Use USB connector to the FM radio, music 15 Headset Plug synchronize data with...

  • Page 3: Insert The Battery & Sim Card

    Push and slide out the cover to replace 19 Battery Cover battery and unlock SIM card hatch. Insert the Battery & SIM Card Before inserting/removing a SIM card, please make sure that MS802 is powered off and is not connected to any power supply. 1.
  • Page 4 5. Pop up-menu You have missed calls. This allows you to access an item quickly. Tap the selected item to perform an action. Voice call in active. To cancel this pop-up menu, tap other areas of this screen. GPRS is in range. GPRS is connected.

  • Page 5: Install And Charge Battery

    Tab. You have one or more instant message(s). Power On System volume. Press Power On / Off key on the top of the device to turn on the device. Phone volume. Power Off Volume Ringer is on. Press and hold Power On / Off Key on the top of the device for about 5 seconds while the power Ringer is off.

  • Page 6: Specifications

    Select Start > Messaging > Menu > Options > Storage tab. If you have inserted a memory card, check “When available, use this storage card to store attachments”, and the attachments will be saved to memory card automatically. Specifications Item Specification About System Information...
  • Page 7 Charging Up to 4 hours time Modem dial-up Display Characteristics Mini USB 2.0 2.8”, 65,536 TFT LCD touch Type panel Image Resolution 320 x 240 pixels JPEG, GIF, PNG, BNP, Format WBMP Max Size Band Depends on available RAM (per) Band EDGE;...
  • Page 8 Type JPEG Pixels 3.0 mega pixels Auto Focus (Rear Camera) Macro Mode Video Recording Message Windows Live Messenger E-mail External Memory Type Micro SD Card Max Size Maximum to 4GB If this document is modified, please download Operating Temperature the latest version on the GSmart official website.
