Summary of Contents for Belkin SCREENCAST F7D4501
- Page 1 TV ADAPTER FOR INTEL ® WIRELESS DISPLAY SCREENCAST User Manual F7D4501 8820-00810 Rev. A01...
-
Page 2: Table Of Contents
FCC Statement..........14 Belkin International, Inc., Limited 1-Year Product Warranty ..15... -
Page 3: Getting Started
GeTTInG sTarTed Introduction Thank you for purchasing the ScreenCast TV Adapter for Intel Wireless Display. We created this product to help you wirelessly transmit your favorite content from your laptop to the best screen in your house—your living-room TV. Before the ScreenCast TV Adapter, you may have needed a long cable or simply crowded around your laptop screen to share movies, pictures, and surf the Web. -
Page 4: What's In The Box
GeTTInG sTarTed What’s in the box? What’s not in the box? • ScreenCast TV Adapter for Intel Wireless Display • An Intel Wireless Display (WiDi) laptop • Y ou need a WiDi laptop to use the ScreenCast TV Adapter. The • Power Supply (attached to ScreenCast TV Adapter) latest generation WiDi laptops support streaming of DVD and Blu-ray™ content to your TV in 1080p quality. Check with your • Quick Install Guide PC vendor on which generation of WiDi your PC supports. -
Page 5: What Else Should I Know
GeTTInG sTarTed What else should I Know? • I ntel Wireless Display is a technology that enables a second display for Intel Wireless Display-ready (WiDi) computers. A simple way of thinking about it is as a replacement for a cable to a secondary monitor. • O nce connected, your laptop operates in all the standard Windows 7 multiple monitor modes: duplicate (mirror) ® images, extended (a second screen for more desktop space), or projector (laptop screen off and duplicate screen on). • I ntel WiFi hardware and Intel My WiFi Technology (Intel MWT) software allows both an easy connection to the ScreenCast TV Adapter and a standard connection to a wireless access point for Internet connectivity. -
Page 6: Adapter Setup
adaPTer seTUP Where to Place Your screenCast TV adapter Plugging everything Together • Your ScreenCast TV Adapter and TV need to be close • Connect your ScreenCast TV Adapter to your TV with enough together to allow you to connect them with an RCA the HDMI cable (included in the box) or RCA cables or HDMI cable (provided). The ScreenCast TV Adapter also (sold separately), and connect the power supply to needs to have an available power outlet within range. the ScreenCast TV Adapter and a nearby outlet. • For best results, keep your ScreenCast TV Adapter within line-of-sight of wherever you plan to use your WiDi laptop (sold separately)—this will help ensure... -
Page 7: Software-First-Time Setup
adaPTer seTUP software—first-Time setup 1. Turn on your TV and switch it to the A/V input where your ScreenCast TV Adapter is connected. Then push the power button on the back of the Adapter. You should then see a screen that looks like this:... - Page 8 adaPTer seTUP 2. On your WiDi laptop, launch the Intel Wireless Display software. On some laptop PCs, this may be a switch at the top of the keyboard. Other PCs may require you to start a program from a shortcut on the desktop or in the system tray. Refer to your PC manufacturer’s documentation for specific details on your model.
- Page 9 adaPTer seTUP 3. When you click to connect to the ScreenCast TV Adapter, a screen will appear on your TV with a 4-digit security code. A similar screen appears on your PC requesting that code. Enter the 4-digit code into the appropriate box on your laptop screen.
- Page 10 adaPTer seTUP 4. Name the ScreenCast TV Adapter. Naming it will allow you to easily find it in a list of available adapters should you have more than one within range. Use a name that is easy to remember like “Living Room WiDi”. If you choose not to name it, the device will be set to a factory-default name.
- Page 11 ScreenCast TV Adapter with Belkin to receive updates and support. 6. Once you have the display configured the way you want and you’ve registered your product, click “Complete.”...
-
Page 12: Using Your Screencast
UsInG YOUr sCreenCasT How to Use It Playing Content on Your TV 1. Simply press the Intel Wireless Display button on your • This is the easy part. Once you are connected, you can use WiDi laptop or click on the desktop WiDi icon, and your TV as though it is a second screen for your laptop PC. Any the rest is automatically handled by your PC. -
Page 13: Options For Using The Tv Screen
UsInG YOUr sCreenCasT Options for Using the TV screen You have three basic options for how to use your TV and laptop screens. • Mirroring or “cloning” (displaying the same content on both • Extended monitor—this allows you to keep using your laptop screen screens)—useful for when you want to use your laptop’s while sending content over to your TV for a larger group to see. keyboard or mouse while showing content to other people. -
Page 14: What Else Do I Need To Know
UsInG YOUr sCreenCasT What else do I need to Know? Protected Content Output (HdCP) • Version 2.0+ of Intel Wireless Display supports High- Bandwidth Digital Copyright Protection (HDCP). This support happens between the PC and the ScreenCast TV Adapter and between the ScreenCast TV Adapter and the TV. If any part of this chain is broken, the content may not play on the TV screen. -
Page 15: Using The Reset Button
This will require that ELEMENTS SHOWN IN BLACK: you complete the setup process a second time and BLACK re-pair your laptop and ScreenCast TV Adapter. ELEMENTS SHOWN IN GRAY: PANTONE 429 C BOTTOM DO NOT MAKE CHANGES WITHOUT PERMISSION FROM BELKIN IDG. -
Page 16: Information
Of COnfOrMITY WITH fCC rUles • Reorient or relocate the receiving antenna. fOr eleCTrOMaGneTIC COMPaTIbIlITY We, Belkin International, Inc., of 12045 E. Waterfront Drive, Playa • Increase the distance between the equipment and the receiver. Vista, CA 90094, declare under our sole responsibility that the product, f7d4501, to which this declaration relates, complies with • C onnect the equipment to an outlet on a circuit different... -
Page 17: Belkin International, Inc., Limited 1-Year Product Warranty
What is not covered by this warranty? 1-Year Product Warranty All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines that the Belkin product has been improperly installed, altered in any way, or tampered What this warranty covers . - Page 18 Belkin reserves the right to review the damaged Belkin product. Some states do not allow limitations on how long an implied All costs of shipping the Belkin product to Belkin for inspection warranty lasts, so the above limitations may not apply to you.
-
Page 19: Technical Support
InfOrMaTIOn Technical support http://www.belkin.com/support http://www.belkin.com/uk/support australia http://www.belkin.com/au/support new Zealand http://www.belkin.com/au/support singapore 1800 622 1130 europe http://www.belkin.com/uk/support... - Page 20 © 2011 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. HDMI is a trademark or registered trademark of HDMI Licensing LLC in the United States and other countries. Intel Wireless Display requires a compatible laptop PC, a TV adapter featuring Intel Wireless Display, and a TV with an available HDMI or Composite AV input. Compatible...
