Flash inserts a keyframe that duplicates the contents of the Up frame.
6
Change or edit the button image for the Over state.
Repeat steps 5 and 6 for the Down frame and the Hit frames.
7
The Hit frame is not visible on the Stage, but it defines the area of the button that responds when clicked. The graphic
for the Hit frame must be a solid area large enough to encompass all the graphic elements of the Up, Down, and Over
frames. It can also be larger than the visible button. If you do not specify a Hit frame, the image for the Up state is
used as the Hit frame.
To create a disjoint rollover, in which moving the pointer over a button causes another graphic on the Stage to change,
place the Hit frame in a different location than the other button frames.
To assign a sound to a state of the button, select that state's frame in the Timeline, select Window > Properties >
8
Properties, and then select a sound from the Sound menu in the Property inspector.
9
When you finish, select Edit > Edit Document. To create an instance of the button in the document, drag the
button symbol from the Library panel.
See also
"Using sounds in Flash" on page 291
Enable, edit, and test buttons
By default, Flash keeps buttons disabled as you create them, to make it easier to select and work with them. When a
button is disabled, clicking the button selects it. When a button is enabled, it responds to the mouse events that you've
specified as if the SWF file were playing. You can still select enabled buttons. Disable buttons as you work, and enable
buttons to quickly test their behavior.
For a text tutorial about buttons, see Add Button Navigation and Animation on the Flash Tutorials page at
www.adobe.com/go/learn_fl_tutorials.
Enable and disable buttons
❖
Select Control > Enable Simple Buttons. A check mark appears next to the command to indicate buttons are
enabled. Select the command again to disable buttons.
Any buttons on the Stage now respond. As you move the pointer over a button, Flash displays the Over frame; when
you click within the button's active area, Flash displays the Down frame.
Select, move, or edit an enabled button
❖
Do one of the following:
• Use the Selection tool to drag a selection rectangle around the button.
• Use the arrow keys to move the button.
• If the Property inspector is not visible, select Window > Properties > Properties to edit the button in the Property
inspector, or Alt+double-click (Windows) or Option+double-click the button (Macintosh).
Test a button
❖
Do one of the following:
• Select Control > Enable Simple Buttons. Move the pointer over the enabled button to test it.
• Select the button in the Library panel, and click the Play button in the Library preview window.
FLASH CS3
221
User Guide
