Exploded View - BENDIX SINGLE ANCHOR PIN CAM BRAKE General Description Manual

13
18
16
FIGURE 2 - 15" SINGLE ANCHOR PIN S-CAM BRAKE
Key No. Description
1 Snap ring
2 Spacer washers
3 Yoke pin
4 Slack adjuster
5 Yoke
6 Cotter pin
7 Washer
8 Grease seal
9 Bushing
10 Cap screw
11 Lock washer
12 Chamber bracket and cam tube
13 Brake shoe assembly
14 Cam roller assembly
2
15
19
18
14
17
Qty.
1
# +reqd.
1
1
1
1
1
2
2
4
4
1
2
2
22
23
21
12
20
11
9
8
13
Key No. Description
15 Anchor pin
16 S-Cam shaft
17 Shoe return spring
18 Anchor spring
19 Spider
20 Dust shield
21 Rubber inspection plug
22 Cap Nut
23 Star Washer
24 Actuator
25 Mounting Nuts
26 Washers
3
5
2
4
6
7
8
24
9
10
26
25
1
Qty.
1
1
1
2
1
2
2
6
6
1
2
2
