PORTABLE GASOLINE GENERATORS
ILLUSTRATED
PARTS LIST
For Models RGH3000 and
RGH3000PR Alternator
Assembly
This list contains replaceable parts used in
your generator. When ordering parts, fol-
low the instructions listed under Replace-
ment Parts on page 19 of this manual.
KEY PART
NO. NUMBER
099722-02
1 100074-01
2 100445-01
3 22616009
4 27002002S
5 26333000
6 099863-01
7 099701-01
8 099848-01
9 17587000
10 099891-01
11 099861-01
12 099842-01
13 26310000
† Includes fastening hardware.
* Includes reference numbers 1 through 22.
** Parts not available. Included in alternator assembly.
®
6
7
DESCRIPTION
Alternator Assembly*
Top Cover
120V, 15A Duplex (GFCI)
Receptacle †
Circuit Breaker, 20 Amp †
Capacitor
Screw, M4 x 20
Terminal Block
Screw, M5 x 13
End Plate
Ground Lug
Flanged Nut, 8mm
Bottom Cover
Draw Bolt
Screw, M6 x 16
1 7
2
5
15
13
7
8
9
10
7
KEY PART
QTY. NO. NUMBER
1 14 27001005S
1 15 WLE-4
16 **
1 17 27001002
1 18 27001009S
1 19 **
20 27001006
1
1 21 26327006
13 22 WLE-5
1
PARTS AVAILABLE - NOT SHOWN
1
1
099866-03
1
099866-04
1
099867-02
4
20
4
3
17
16
15
13
12
11
DESCRIPTION
Engine Flange
Lock Washer, 1/4"
Stator
Bearing
Diode
Rotor
Fan
Bolt, 5/16-24 x 5/8"
Lock Washer, 5/16"
Safety Information Decal
Safety Information Decal
Operation Decal
22
14
21
20
19
18
QTY.
1
4
1
1
2
1
1
4
4
1
1
1
