PORTABLE GASOLINE
GENERATORS
OWNER'S OPERATION AND INSTALLATION MANUAL
Generator Models: RGH3000, RGH3000PR, RGH5500A, RGH5500AIE,
RGH7500AIE, and RGH11000AIE
IMPORTANT: Read and understand this manual before operating or servicing
generator. Improper use of generator can cause serious injury. Keep this
manual for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Desa Rgh3000, Rgh3000pr, Rgh5500a, Rgh5500aie, Rgh7500aie, And Rgh11000aie

Summary of Contents for Desa Rgh3000, Rgh3000pr, Rgh5500a, Rgh5500aie, Rgh7500aie, And Rgh11000aie

  • Page 1 ® PORTABLE GASOLINE GENERATORS OWNER’S OPERATION AND INSTALLATION MANUAL Generator Models: RGH3000, RGH3000PR, RGH5500A, RGH5500AIE, RGH7500AIE, and RGH11000AIE IMPORTANT: Read and understand this manual before operating or servicing generator. Improper use of generator can cause serious injury. Keep this manual for future reference.

  • Page 2: Safety Information

    ® PORTABLE GASOLINE GENERATORS SAFETY INFORMATION WARNINGS IMPORTANT: Read this owner’s manual and the engine owner’s manual carefully. Become famil- iar with this generator before try- ing to operate or service it. Know its uses, limitations, and any haz- ards involved. Improper use of generator can cause severe in- jury or death from explosion, fire, burns, electrical shock, or car-...

  • Page 3: Product Identification

    Run Lamp Hour Meter 120/240 Volt Receptacle Circuit Breaker Choke Lever Fuel Valve Lever Starter Grip Engine Engine ON/ OFF Switch Figure 1 - Portable Generator (Model RGH5500A Shown) Provision for Auto-Idle Switch Roll Cage Gas Tank Ground Alternator Oil Dipstick...

  • Page 4: General Information

    ® PORTABLE GASOLINE GENERATORS GENERAL INFORMATION Reddy portable generators are rugged and compact. These models provide dependable, trouble-free service. The alternators are brushless with revolving fields. Honda gaso- line engines provide long life under heavy use. Honda engines have overhead valves (OHV).

  • Page 5: Specifications

    SPECIFICATIONS MODEL RGH3000 Electrical Rated Wattage 2500 Rated Amperage 120 V 20.8 240 V –– Receptacle 120-V Duplex –– 120-V, 20-A Duplex –– 120-V, 15-A GFCI 120-V Twist-Lock 120/240-V Twist-Lock 120-V Full-Power Switch 120/240-V, 50-A General Honda Engine H.P. Honda Model GX160K1VX Fuel Type Gasoline...

  • Page 6: Generator Features

    ® PORTABLE GASOLINE GENERATORS GENERATOR FEATURES OIL ALERT SYSTEM The oil alert system protects the engine from low oil damage. This system automatically shuts down the engine and prevents engine restarting if the oil level falls too low. Note: When this happens, the engine switch remains in the ON position.

  • Page 7: Engine Oil

    GENERATOR FEATURES Continued 2. If the GFCI receptacle tests okay, re- store power by pushing the RESET button back in. The test lamp should work at this time . IMPORTANT: You must press the RESET button firmly and fully. It should lock into place. If the GFCI does not lock into place, do not use receptacle.
  • Page 8 ® PORTABLE GASOLINE GENERATORS HANDLES AND TOP COVER (Model RGH11000AIE) Follow the steps below to attach the handles and top cover to Model RGH11000AIE: 1. Remove the two bolts, lock nuts, and washers holding side panels to control panel end of roll cage. Insert bolts with washers through two holes in the handle and then back through roll cage and side screen panels (See Figure 8).

  • Page 9: Extension Cords

    BATTERY Continued MOUNTING BATTERY TO GENERATOR 1. Secure battery to generator by battery hold-down system. This system con- sists of the battery mounting bracket, hook bolts, and nut (see Figure 12). Note: Model RGH11000AIE battery is located on opposite side as shown (see Figure 13).

  • Page 10: Standby Installation To Home Or Building

    ® PORTABLE GASOLINE GENERATORS STANDBY INSTALLATION TO HOME OR BUILDING WARNING: Have standby in- stallation performed by a skilled, licensed electrician. Do not let anyone else wire into a utility circuit. Personal injury, equip- ment damage, or damage to home could occur.

  • Page 11: Operation

    OPERATION GENERAL INFORMATION This generator is not large enough to power your entire home. Do not connect generator to any existing electrical circuits. Plug items directly into generator receptacles. Do not exceed amperage rating of receptacles. Only use grounded cords. DANGER: Use only in well- vented areas.
  • Page 12 ® PORTABLE GASOLINE GENERATORS OPERATION Continued PRESTART Operate generator on a firm, dry, and clean surface. The surface must be level. Protect generator from heavy dust, sand, dirt, rain, or snow. Do not locate generator near standing water and snow. Make sure area is well vented. WARNING: Only responsible adults should use generator.
  • Page 13 OPERATION Continued HONDA START Engine ENGINE SW Switch CIRCUIT BREAKER ON/push OFF Figure 24 - Engine Switch (Models RGH5500AIE, RGH7500AIE, RGH11000AIE Only) Choke Lever (Open Position) Figure 25 - Choke Lever Opened (Model RGH7500AIE Shown) AUTO-IDLE OPERATION IMPORTANT: Never start engine with elec- trical loads connected.

  • Page 14: High Altitude Operation

    ® PORTABLE GASOLINE GENERATORS OPERATION Continued HIGH ALTITUDE OPERATION This generator will not perform well at high altitudes without proper adjustment. See engine owner’s manual for details. ADDING ELECTRICAL LOADS IMPORTANT: Do not overload generator. Make sure total wattage of all electrical loads does not exceed rated wattage of generator.

  • Page 15: Maintenance And Repairs

    CAUTION: Shut off generator before performing maintenance. TROUBLESHOOTING Note: For additional help, visit DESA International’s technical service web site at www.desatech.com. OBSERVED PROBLEM No voltage when starting generator with no electrical load...

  • Page 16: Electrical Component Specifications

    ® PORTABLE GASOLINE GENERATORS ELECTRICAL COMPONENT SPECIFICATIONS Model RGH3000, RGH3000PR RGH5500A RGH5500AIE RGH7500AIE RGH11000AIE * Connect T2 (green) and T3 (black). Measure resistance between T1 (red) and T4 (yellow). Resistance between brown and white leads. † Remove diodes to check resistance. WIRING DIAGRAMS Figure 31 - Wiring Diagram, Models RGH3000 and RGH3000PR Figure 32 - Wiring Diagram, Models RGH5500A...
  • Page 17 WIRING DIAGRAMS Continued • To Solenoid • Figure 33 - Wiring Diagram, Model RGH5500AIE • To Solenoid Capacitor Figure 34 - Wiring Diagram, Model RGH7500AIE 106815 White Green/Yellow 120/240V 30A Switch Receptacle White Circuit Breaker White Black Circuit Breaker Hour Meter Yellow Black...
  • Page 18 ® PORTABLE GASOLINE GENERATORS WIRING DIAGRAMS Continued Auto-Idle Control Board Circuit Breaker White White Auto-Idle Solenoid Yellow Yellow Capacitor Figure 35 - Wiring Diagram, Model RGH11000AIE White Green 250V 30A Receptacle 250V 50A Receptacle Circuit Breaker Circuit Circuit Breaker Breaker White Black Black...

  • Page 19: Technical Service

    TECHNICAL SERVICE You may have further questions about in- stallation, operation, or troubleshooting. If so, contact DESA International’s Technical Service Department at 1-800-323-5190. You can also visit DESA International’s technical service site www.desatech.com. SERVICING THE ENGINE Honda parts and services should be handled by your nearest authorized engine service firm.

  • Page 20: Illustrated Parts List

    ® PORTABLE GASOLINE GENERATORS ILLUSTRATED PARTS LIST For Models RGH3000 and RGH3000PR Alternator Assembly This list contains replaceable parts used in your generator. When ordering parts, fol- low the instructions listed under Replace- ment Parts on page 19 of this manual. PART NUMBER DESCRIPTION...
  • Page 21 ILLUSTRATED PARTS LIST For Models RGH5500A, RGH5500AIE, and RGH7500AIE Alternator Assembly This list contains replaceable parts used in your generator. When or- dering parts, follow the instruc- tions listed under Replacement Parts on page 19 of this manual. RGH5500A RGH5500AIE 099723-02 099844-01 099701-01...
  • Page 22 ® PORTABLE GASOLINE GENERATORS ILLUSTRATED PARTS LIST For Model RGH11000AIE Alternator Assembly This list contains replaceable parts used in your generator. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. * Part not available by itself. Must purchase Alternator Assembly. ** Standard hardware item available from local hardware store.
  • Page 23 ILLUSTRATED PARTS LIST For Models RGH3000 and RGH3000PR Roll Cage This list contains replaceable parts used in your generator. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. 106815 PART NUMBER DESCRIPTION 105155-01 Roll Cage 099754-01 Engine Spreader...
  • Page 24 ® PORTABLE GASOLINE GENERATORS ILLUSTRATED PARTS LIST For Models RGH5500A, RGH5500AIE, and RGH7500AIE Fuel Tank and Roll Cage 106815...
  • Page 25 ILLUSTRATED PARTS LIST For Models RGH5500A, RGH5500AIE, and RGH7500AIE Fuel Tank and Roll Cage KEY RGH5500A RGH5500AIE 25954001 107021-01 WP-4C 107110-01 099701-01 19508001 25985005 099743-01 106063-01 103880-01 NEC-5C 14138000 099853-02 WLE-5 WLI-3 WP-5C HC5-14C 099756-01 099750-01* 099749-01* NEC-5C* 100410-01 M10908-74 M10908-74* HC4-16C 099965-01...
  • Page 26 ® PORTABLE GASOLINE GENERATORS ILLUSTRATED PARTS LIST For Model RGH11000AIE Fuel Tank and Roll Cage 106815...
  • Page 27 ILLUSTRATED PARTS LIST For Model RGH11000AIE Fuel Tank and Roll Cage This list contains replaceable parts used in your generator. When ordering parts, fol- low the instructions listed under Replace- ment Parts on page 19 of this manual. 106815 OWNER’S MANUAL PART NUMBER DESCRIPTION...
  • Page 28 ® PORTABLE GASOLINE GENERATORS ILLUSTRATED PARTS LIST For Models RGH5500A, RGH5500AIE, and RGH7500AIE Control Panel This list contains replaceable parts used in your generator. When order- ing parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NUMBER FOR MODEL RGH5500A RGH5500AIE...
  • Page 29 ILLUSTRATED PARTS LIST For Model RGH11000AIE Control Panel This list contains replaceable parts used in your generator. When order- ing parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NUMBER 103182-01 22616009 099833-01 100410-01 22261000 100445-01 103183-01...
  • Page 30 ® PORTABLE GASOLINE GENERATORS ILLUSTRATED PARTS LIST For Solenoid and Control Board Assemblies and Mounting Control Board Assembly and Mounting Solenoid Assembly and Mounting 106815...
  • Page 31 ILLUSTRATED PARTS LIST For Solenoid and Control Board Assemblies and Mounting This list contains replaceable parts used in your generator. When ordering parts, fol- low the instructions listed under Replace- ment Parts on page 19 of this manual. PART NUMBER 100105-01 26499000 100321-01...

  • Page 32: Warranty Information

    DESA International’s liability is hereby limited to the purchase price of the product and DESA International shall not be liable for any other damages whatsoever including indirect, incidental, or consequential damages.
