PFAFF
update instructions
Version: pcv50_15493_5177
Note this instruction is only valid if you are updating from version 14278 or later.
The update is available to all registered Pfaff
sewing and embroidery
creative vision
TM
machine owners. You need the Pfaff
Embroidery Machine Communication CD which
came with your Pfaff
sewing and embroidery machine, or 4D
Embroidery Software, version 8.1 and above.
The software must be installed on a personal
computer, running Windows
Vista.
Your machine must be registered using 4D
Configure on the computer with the machine
connected. Internet updates for the machine can
only be received via the Smart Update feature in
4D Configure.
TM
If you need assistance registering your machine,
full instructions are found in the Internet FAQs.
Open 4D Organizer. From the Help menu,
TM
select Internet FAQs. Enter "HC020" in the
Search box and choose "all FAQ" for the Search.
Download
1. Connect your creative vision
embroidery machine to the computer with the
USB Cable. Turn your machine on. Make sure
the embroidery machine communication icon
at the bottom right of your computer screen
is active (active
If you don't find the Embroidery
Machine tray icon
Open 4D Configure. Click on the
TM
Send 1 tab and click on the "Embroidery
Machine Communication" button.
creative vision
®
®
®
creative vision
TM
TM
XP or Windows
®
TM
sewing and
TM
, not active ).
® If you have an inactive Embroidery
Machine tray icon
Make sure your machine is turned on and
connected to your computer.
Please Note: You must use the same USB port
on your computer as when you activated
the Embroidery Machine Communication at
installation.
®
2. Connect your computer to the Internet.
3. Open the program 4D
(Go to Start/All Programs/4D Embroidery
System/4D Configure).
4. Click on "Smart Update". You may be asked
if your system has a dongle. Answer No.
5. The program starts searching for the latest
update version for your machine and a list
with suggested downloads is presented.
6. Click on "Download" and save the download
to your computer. Note the location saved in.
Update
1. Double click the creative vision
pcv50_15493_5177.exe to start the update.
2. Follow the quick start guide instructions on
your computer screen:
a. Connect the sewing machine to the computer
with the USB cable. Make sure the machine is
switched off.
™
Configure
TM
update
TM
