TA780G M2+/TA780G M2+ HP/TA760G M2+
Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Biostar TA760G M2 PLUS

Summary of Contents for Biostar TA760G M2 PLUS

  • Page 1 TA780G M2+/TA780G M2+ HP/TA760G M2+ Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ............1 Before You Start ................1 Package Checklist ................1 Motherboard Features..............2 Rear Panel Connectors ..............3 Motherboard Layout................. 4 Chapter 2: Hardware Installation ..........5 Installing Central Processing Unit (CPU)........5 FAN Headers..................

  • Page 3: Chapter 1: Introduction

    TA780G M2+/TA780G M2+ HP/TA760G M2+ CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation.

  • Page 4: Motherboard Features

    Motherboard Manual OTHERBOARD EATURES SPEC Socket AM2+ / AM2 AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 AMD 64 Architecture enables 32 and 64 bit / Sempron / Phenom processors computing Athlon Max. Power: 125W Supports Hyper Transport 3.0 and Cool=n=Quiet Phenom Max.

  • Page 5: Rear Panel Connectors

    Board Size 215 mm(W) x 244 mm(L) Special RAID 0 / 1 / 1+0 support Features Biostar Reserves the right to add or remove support OS Support Windows XP / VISTA for any OS With or without notice. ANEL ONNECTORS...

  • Page 6: Motherboard Layout

    Motherboard Manual OTHERBOARD AYOUT JCFAN1 JKBM S1 JATXPWR2 JATXPWR1 JUSB1 JUSBV1 JUSBLAN1 JAUDIO1 780G/ JAUDIOF 1 760G JCDIN1 PEX1_1 PEX16_1 Codec JSFAN1 PCI1 SB700/ SATA5 SATA6 SB710 JUSB4 JSPDIF_OUT1 Super I/O SATA3 PCI2 SATA1 JUSB3 JUSB2 JPRNT1 JCOM1 SATA2 JCMOS1 FDD1 JUSBV2 JPANEL1...

  • Page 7: Chapter 2: Hardware Installation

    TA780G M2+/TA780G M2+ HP/TA760G M2+ CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Step 1: Remove the socket protection cap. Step 2: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 3: Look for the white triangle on socket, and the gold triangle on CPU should point towards this white triangle.
  • Page 8 Motherboard Manual Step 4: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1. This completes the installation. Note: Please update the BIOS to the latest version while using AM2+ CPUs.

  • Page 9: Fan Headers

    TA780G M2+/TA780G M2+ HP/TA760G M2+ FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.

  • Page 10: Installing System Memory

    Motherboard Manual NSTALLING YSTEM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 11 TA780G M2+/TA780G M2+ HP/TA760G M2+ B. Memory Capacity DIMM Socket DDR2 Module Total Memory Size Location DIMMA1 256MB/512MB/1GB/2GB/4GB DIMMB1 256MB/512MB/1GB/2GB/4GB Max is 16GB. DIMMA2 256MB/512MB/1GB/2GB/4GB DIMMB2 256MB/512MB/1GB/2GB/4GB C. Dual Channel Memory installation To trigger the Dual Channel function of the motherboard, the memory module must meet the following requirements: Install memory module of the same density in pairs, shown in the following table.

  • Page 12: Connectors And Slots

    Motherboard Manual ONNECTORS AND LOTS FDD1: Floppy Disk Connector The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cable. IDE1: Hard Disk Connector The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality.
  • Page 13 TA780G M2+/TA780G M2+ HP/TA760G M2+ PEX16_1: PCI-Express Gen2 x16 Slot PCI-Express 2.0 compliant. Maximum theoretical realized bandwidth of 8GB/s simultaneously per direction, for an aggregate of 16GB/s totally. PEX1_1: PCI-Express Gen2 x1 Slot PCI-Express 2.0 compliant. Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total. PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins.

  • Page 14: Headers & Jumpers Setup

    Motherboard Manual CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin1-2 closed...
  • Page 15 TA780G M2+/TA780G M2+ HP/TA760G M2+ JATXPWR1: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground...
  • Page 16 Motherboard Manual JUSB2/JUSB3/JUSB4: Headers for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused) +5V (fused) USB- USB-...
  • Page 17 TA780G M2+/TA780G M2+ HP/TA760G M2+ JSPDIF_OUT1: Digital Audio-out Connector This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JAUDIOF1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC front panel.

  • Page 18: Clear Cmos Procedures

    Motherboard Manual JCDIN1: CD-ROM Audio-in Connector This connector allows user to connect the audio source from the variaty devices, like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc. Assignment Left Channel Input Ground Ground Right Channel Input JCMOS1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS safe setting and the CMOS data, please carefully follow the procedures to avoid damaging the motherboard.
  • Page 19 TA780G M2+/TA780G M2+ HP/TA760G M2+ JPRNT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3...
  • Page 20 Motherboard Manual JUSBV1/JUSBV2: Power Source Headers for USB Ports Pin 1-2 Close: JUSBV1: +5V for USB ports at JUSB1/JUSBLAN1. JUSBV2: +5V for USB ports at front panel (JUSB2/JUSB3/JUSB4). Pin 2-3 Close: JUSBV1: +5V STB for USB ports at JUSB1/JUSBLAN1. JUSBV2: +5V STB for USB ports at front panel (JUSB2/JUSB3/JUSB4). JUSBV1 Pin 1-2 close Pin 2-3 close...

  • Page 21: Chapter 4: Raid Functions

    TA780G M2+/TA780G M2+ HP/TA760G M2+ CHAPTER 4: RAID FUNCTIONS PERATING YSTEM Supports Windows XP Home/Professional Edition, and Windows Vista. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 22 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array. RAID 1 provides a hot-standby copy of data if the active volume or drive is corrupted or becomes unavailable because of a hardware failure.
  • Page 23 TA780G M2+/TA780G M2+ HP/TA760G M2+ RAID 1+0: RAID 1 drives can be stripped using RAID 0 techniques. Resulting in a RAID 1+0 solution for improved resiliency, performance and rebuild performance. Features and Benefits Drives: Minimum 4, and maximum is 6 or 8, depending on the platform. Benefits: Optimizes for both fault tolerance and performance, allowing for automatic redundancy.

  • Page 24: Chapter 5: T-Series Bios & Software

    Motherboard Manual CHAPTER 5: T-SERIES BIOS & SOFTWARE BIOS ERIES T-Series BIOS Features Overclocking Navigator Engine (O.N.E.) Memory Integration Test (M.I.T., under Overclock Navigator Engine) BIO-Flasher: Update BIOS file from USB Flash Drive or FDD Self Recovery System (S.R.S) Smart Fan Function !! WARNING !! For better system performance, the BIOS firmware is being continuously updated.
  • Page 25 TA780G M2+/TA780G M2+ HP/TA760G M2+ Manual Overclock System (M.O.S.) MOS is designed for experienced overclock users. It allows users to customize personal overclock settings. BIOS SETUP UTILITY PCIPnP Boot Main Advanced Chipset T-Series Exit T-Series Settings Options WARNING: Setting wrong values in below sections Normal may cause system to malfunction.

  • Page 26: Dram Timing Configuration

    Motherboard Manual CPU Frequency CPU Frequency is directly in proportion to system performance. To maintain the system stability, CPU voltage needs to be increased also when raising CPU frequency. CPU FID/VID Control Enter this function for more advanced CPU settings. DRAM Timing Configuration Enter this function for more advanced DRAM clock settings.
  • Page 27 TA780G M2+/TA780G M2+ HP/TA760G M2+ V6 Tech Engine This engine will make a good over-clock performance. BIOS SETUP UTILITY PCIPnP Boot Main Advanced Chipset T-Series Exit T-Series Settings Options WARNING: Setting wrong values in below sections Normal may cause system to malfunction. Automate OverClock Manual OverClock OverClock Navigator...
  • Page 28 Motherboard Manual Notices: Not all types of AMD CPU perform above overclock setting ideally; the difference will be based on the selected CPU model. B. Memory Integration Test (M.I.T.) This function is under “Overclocking Navigator Engine” item. MIT allows users to test memory compatibilities, and no extra devices or software are needed.
  • Page 29 TA780G M2+/TA780G M2+ HP/TA760G M2+ C. BIO-Flasher BIO-Flasher is a BIOS flashing utility providing you an easy and simple way to update your BIOS via USB pen drive or floppy disk. The BIO-Flasher is built in the BIOS chip. To enter the utility, press <F12> during the Power-On Self Tests (POST) procedure while booting up.
  • Page 30 Motherboard Manual D. Self Recovery System (S.R.S.) This function can’t be seen under BIOS setup; and is always on whenever the system starts up. However, it can prevent system hang-up due to inappropriate overclock actions. When the system hangs up, S.R.S. will automatically log in the default BIOS setting, and all overclock settings will be re-configured.
  • Page 31 TA780G M2+/TA780G M2+ HP/TA760G M2+ Smart Fan Calibration Choose this item and then the BIOS will automatically test and detect the CPU/System fan functions and show CPU/System fan speed. Control Mode This item provides several operation modes of the fan. Fan Ctrl OFF(℃) If the CPU/System temperature is lower than the set value, the CPU/ System fan will turn off.

  • Page 32: T-Series Software

    Motherboard Manual ERIES OFTWARE Installing T-Series Software 1. Insert the Setup CD to the optical drive. The drivers installation program would appear if the Autorun function has been enabled. 2. Select Software Installation, and then click on the respective software title.
  • Page 33 TA780G M2+/TA780G M2+ HP/TA760G M2+ eHot-Line (Optional) eHot-Line is a convenient utility that helps you to contact with our Tech-Support system. This utility will collect the system information which is useful for analyzing the problem you may have encountered, and then send these information to our tech-support department to help you fix the problem.
  • Page 34 If you are not using Outlook Express as your default e-mail client application, you may need to save the system information to a .txt file and send the file to our tech support with other e-mail application. Go to the following web http://www.biostar.com.tw/app/en-us/about/contact.php for getting our contact information.

  • Page 35: Bios Update

    TA780G M2+/TA780G M2+ HP/TA760G M2+ BIOS Update BIOS Update is a convenient utility which allows you to update your motherboard BIOS under Windows system. Show current BIOS information AWARD BIOS AMI BIOS Clear CMOS function (Only for AWARD BIOS) Save current BIOS to a .bin file Update BIOS with a BIOS file...
  • Page 36 Motherboard Manual <Update BIOS> Before doing this, please download the proper BIOS file from the website. For AWARD BIOS, update BIOS procedure should be run with Clear CMOS function, so please check on Clear CMOS first. Then click Update BIOS button, a dialog will show for asking you backup current BIOS.

  • Page 37: Chapter 6: Useful Help

    TA780G M2+/TA780G M2+ HP/TA760G M2+ CHAPTER 6: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system.

  • Page 38: Extra Information

    Motherboard Manual XTRA NFORMATION CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.

  • Page 39: Troubleshooting

    TA780G M2+/TA780G M2+ HP/TA760G M2+ ROUBLESHOOTING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, fan securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on keyboard does not turn on.

  • Page 40: Appendix: Spec In Other Languages

    Motherboard Manual APPENDENIX: SPEC IN OTHER LANGUAGES ERMAN Spezifikationen Sockel AM2+ / AM2 AMD Athlon 64 / Athlon 64 FX / Althlon 64 Die AMD 64-Architektur unterstützt eine 32-Bit- und X2 / Sempron / Phenom Prozessoren 64-Bit-Datenverarbeitung Athlon Max. Power: 125W Unterstützt Hyper Transport 3.0 und Cool’n’Quiet Phenom Max.
  • Page 41 Platinengröß 215 mm (B) X 244 mm (L) Sonderfunkti Unterstützt RAID 0 / 1 / 1+0 onen Biostar behält sich das Recht vor , ohne Ankündigung OS-Unterstü Windows XP / VISTA die Unterstützung für ein Betriebssystem tzung hinzuzufügen oder zu entfernen.

  • Page 42: French

    Motherboard Manual RENCH SPEC Socket AM2+ / AM2 Processeurs AMD Athlon 64 / Athlon 64 FX L'architecture AMD 64 permet le calcul 32 et 64 bits / Althlon 64 X2 / Sempron / Phenom Prend en charge Hyper Transport 3.0 et Cool’n’Quiet Athlon Max.
  • Page 43 215 mm (l) X 244 mm (H) carte Fonctionnal ités Prise en charge RAID 0 / 1 / 1+0 spéciales Biostar se réserve le droit d'ajouter ou de supprimer le Support SE Windows XP / VISTA support de SE avec ou sans préavis.

  • Page 44: Italian

    Motherboard Manual TALIAN SPECIFICA Socket AM2+ / AM2 Processori AMD Athlon 64 / Athlon 64 FX L’architettura AMD 64 abilita la co mputazione 32 / Althlon 64 X2 / Sempron / Phenom e 64 bit Athlon Max. Power: 125W Supporto di Hyper Transport 3.0 e Cool’n’Quiet Phenom Max.
  • Page 45 215 mm (larghezza) x 244 mm i scheda (altezza) Caratterist iche Supporto RAID 0 / 1 / 1+0 speciali Sistemi Biostar si riserva il diritto di aggiungere o operativi Windows XP / VISTA rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.

  • Page 46: Spanish

    Motherboard Manual PANISH Especificación Conector AM2+ / AM2 La arquitectura AMD 64 permite el procesado de 32 y Procesadores AMD Athlon 64 / Athlon 64 64 bits FX / Athlon 64 X2 / Sempron / Phenom Soporta las tecnologías Hyper Transport 3.0 y Athlon Max.
  • Page 47 215 mm. (A) X 244 Mm. (H) la placa Funciones Admite RAID 0 / 1 / 1+0 especiales Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows XP / VISTA soporte de cualquier SO con o sin aviso previo. operativo...

  • Page 48: Especificações

    Motherboard Manual ORTUGUESE ESPECIFICAÇÕES Socket AM2+ / AM2 A arquitectura AMD 64 permite uma computação de Processadores AMD Athlon 64 / Athlon 64 32 e 64 bits FX / Althlon 64 X2 / Sempron / Phenom Suporta as tecnologias Hyper Transport 3.0 e Athlon Max.
  • Page 49 215 mm (L) X 244 mm (A) da placa Característi Suporta as funções RAID 0 / 1 / 1+0 especiais Sistemas A Biostar reserva-se o direito de adicionar ou remover operativos Windows XP / VISTA suporte para qualquer sistema operativo com ou sem suportados aviso prévio.

  • Page 50: Polish

    Motherboard Manual OLISH SPEC Socket AM2+ / AM2 AMD Athlon 64 / Athlon 64 FX / Althlon 64 Architektura AMD 64 umożliwia przetwarzanie 32 i 64 Procesor X2 / Sempron / Phenom Procesory bitowe Athlon Max. Power: 125W Obsługa Hyper Transport 3.0 oraz Cool’n’Quiet Phenom Max.
  • Page 51 Port DVI Wymiary 215 mm (S) X 244 mm (W) płyty Funkcje Obsługa RAID 0 / 1 / 1+0 specjalne Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows XP / VISTA odwoływania obsługi dowolnego systemu operacyjne operacyjnego bez powiadomienia.

  • Page 52: Russian

    Motherboard Manual USSIAN СПЕЦ Гнездо AM2+ / AM2 (централь Архитектура AMD 64 разрешать обработка данных Процессоры AMD Athlon 64 / Athlon 64 ный на 32 и 64 бит FX / Althlon 64 X2 / Sempron / Phenom процессор Поддержка Hyper Transport 3.0 и Cool’n’Quiet (Максимальный...
  • Page 53 215 мм (Ш) X 244 мм (В) панели Специальн ые техническ Поддержка RAID 0 / 1 / 1+0 ие характери стики Biostar сохраняет за собой право добавлять или Поддержк Windows XP / VISTA удалять средства обеспечения для OS с или без а OS предварительного уведомления.

  • Page 54: Arabic

    Motherboard Manual RABIC ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻡﻘﺒﺲ‬AM2+ / AM2 ‫ﻡﻌﺎﻟﺠﺎت‬AMD Athlon 64 / Athlon 64 FX / Sempron / ‫ﺗﻤﻜﻦ ﺗﻘﻨﻴﺔ‬AMD 64 ‫ﺑﺖ‬ ‫و‬ ‫إﺟﺮاء اﻟﻌﻤﻠﻴﺎت اﻟﺤﺎﺳﻮﺑﻴﺔ ﺑﺴﺮﻋﺔ‬ ‫اﻟﻤﻌﺎﻟﺠﺔ‬ ‫وﺡﺪة‬ Phenom / Althlon 64 X2 ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬Hyper Transport 3.0 Cool’n’Quiet ‫و‬ ‫اﻟﻤﺮآﺰیﺔ‬ Athlon Max.
  • Page 55 ‫ﻡﻘﺒﺲ ﺹﻮت‬ ‫ﻋﺪد‬ ‫ﻡﻨﺎﻓﺬ‬ ‫ارﺗﻔﺎع‬ ‫ﻡﻢ‬ ‫ﻋﺮض‬ ‫ﻡﻢ‬ ‫اﻟﻠﻮﺡﺔ‬ ‫ﺡﺠﻢ‬ ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬RAID 0 / 1 / 1+0 ‫ﻡﺰایﺎ ﺥﺎﺹﺔ‬ ‫ﺗﺤﺘﻔﻆ‬Biostar ‫ﺑﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إزاﻟﺔ اﻟﺪﻋﻢ ﻷي ﻥﻈﺎم ﺗﺸﻐﻴﻞ ﺑﺈﺥﻄﺎر أو‬ Windows XP / VISTA ‫اﻟﺘﺸﻐﻴﻞ‬ ‫أﻥﻈﻤﺔ‬ ‫دﻋﻢ‬ ‫ﺑﺪون إﺥﻄﺎر‬...

  • Page 56: Japanese

    Motherboard Manual APANESE 仕様 Socket AM2+ / AM2 AMD 64アーキテクチャでは、 32ビットと64ビット計算が可 AMD Athlon 64 / Athlon 64 FX / Althlon 64 能です X2 / Sempron / Phenom プロセッサ ハイパートランスポート3.0とクールアンドクワイアットを Athlon Max. Power: 125W サポートします Phenom Max. Power: 95W 5.2 GT/sのバンド幅までハイパートランスポ ート3.0をサポートします...
  • Page 57 USBコネクタ ます 電源コネクタ(24ピン) 電源コネクタ(4ピン) プリンタポートコネクタ 各コネクタは1つのプリンタポートをサポートします シリアルポートコネクタ PS/2キーボード PS/2マウス VGAポート 背面パネル LANポート USBポート オーディオジャック DVIポート ボードサイ 215 mm (幅) X 244 mm (高さ) ズ RAID 0 / 1 / 1+0 のサポート 特殊機能 Biostarは事前のサポートなしにOSサポートを追加または削 OSサポート Windows XP / VISTA 除する権利を留保します。 2009/01/15...
