Motherboard Features - Biostar A760G M2 PLUS Setup Manual

Motherboard Manual
1.3 M
OTHERBOARD
A780G M2+ SE/A780V M2+ SE/A760G M2+
Socket AM2+ / AM2
AMD Athlon 64 / Athlon 64 FX / Athl o n 64 x2 /
Sempron / Phenom processors
CPU AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0 and PowerNow
Athl o n Max. Power:125W; Phenom Max. Power:95W
Support HyperTransport 3.0
FSB
Supports up to 5.2 GT/s Bandwidth
AMD 780G (A780G M2+ SE)
AMD 780V (A780V M2+ SE)
Chipset AMD 760G (A760G M2+)
AMD SB700 (A780G M2+ SE & A780V M2+ SE)
AMD SB710 (A760G M2+)
ITE 8718F
Provides the most commonly used legacy Super I/O
functionality
Super I/O Low Pin Count Interface
Environment Control initiatives
H/W Monitor
ITE's "Smart Guardian" function
DDR2 DIMM Sl o ts x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
Main 1GB/2GB/4GB DDR2
Memory Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (for AM2+ CPU only)
Registered DIMM and ECC DIMM is not supported
ATI Radeon HD 3200 (A780G M2+ SE)
ATI Radeon 3100 (A780V M2+ SE)
ATI Radeon 3000 (A760G M2+)
Max Shared Video Memory i s 512MB
Graphics
DX10/HDCP (A780G M2+ SE & A780V M2+ SE
only) support
Hybrid CrossFireX support
UVD support (for A780G M2+ SE only)
Integrated I DE Controller
IDE Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
Integrated Serial ATA Controller
SATA II Data transfer rates up to 3 Gb/s
SATA Version 2.0 specificati o n compliant
Real t ek RTL 8111C (A780G M2+ SE & A760G M2+)
Real t ek RTL 8102EL (A780V M2+ SE)
10 / 100 /1000 Mb/s auto negotiation (A780G M2+
LAN
SE & A760G M2+)
10 / 100 Mb/s auto negotiati o n (A780V M2+ SE)
Half / Full duplex capability
2
F
EATURES
Socket AM2+ / AM2
AMD Athlon 64 / Athlon 64 FX / Athl o n 64 x2 /
Sempron / Phenom processors
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 2.0 and PowerNow
Athl o n Max. Power:125W; Phenom Max. Power:95W
Support HyperTransport 2.0
Supports up to 2.0 GT/s Bandwidth
AMD 740G
AMD SB700
ITE 8718F
Provides the most commonly used legacy Super I/O
functionality
Low Pin Count Interface
Environment Control initiatives
H/W Monitor
ITE's "Smart Guardian" function
DDR2 DIMM Sl o ts x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (for AM2+ CPU only)
Registered DIMM and ECC DIMM is not supported
ATI Radeon 2100
Max Shared Video Memory i s 512MB
HDCP support
Integrated I DE Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specificati o n compliant
Real t ek RTL 8102EL
10 / 100 Mb/s auto negotiati o n
Half / Full duplex capability
A740G M2+ SE
