Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 Setup Manua
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here and specially disclaims any implied warranties of merchantability or fitness
for any purpose. Further the vendor reserves the right to revise this publication
and to make changes to the contents here without obligation to notify any party
beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the brand
and product names are trademarks of their respective companies.
Dichiarazione di conformità
sintetica
Ai sensi dell'art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
l
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied

Advertisement

Table of Contents
loading

Summary of Contents for Biostar Hi-Fi A85S3

  • Page 1 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 Setup Manua FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ...............1 Before You Start................. 1 Package Checklist ..............1 Motherboard Specifications ............2 Rear Panel Connectors ............. 4 Motherboard Layout ..............5 Chapter 2: Hardware Installation ..........7 Install Central Processing Unit (CPU) ........7 Install a Heatsink ...............
  • Page 3: Chapter 1: Introduction

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 CHAPTER 1: INTRODUCTION 1.1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting.
  • Page 4: Motherboard Specifications

    10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability ALC662 Audio Codec 5.1 Channels, High Definition Audio, Biostar Hi-Fi AMD A85/A75 FCH: 6x USB 2.0 port (2 on rear I/Os and 4 via internal headers) 4x USB 3.0 port (2 on rear I/Os and 2 via internal headers) AMD A55 FCH: 8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
  • Page 5: Specifications

    1x Serial Port Header 1x Serial Port Header Form Factor microATX Form Factor, 244 mm x 191 mm Windows XP / Vista / 7/ 8 OS Support Biostar reserves the right to add or remove support for any OS with or without notice.
  • Page 6: Rear Panel Connectors

    Motherboard Manual 1.4 Rear Panel Connectors Hi-Fi A85S3 Hi-Fi A75S3 Hi-Fi A55S3 Note 1: HDMI / DVI-D / VGA Output require an AMD family processor with intedrated graphics. Note 2: The mainboard supports two independent display outputs. Note 3: Since the audio chip supports High Definition Audio Specification, the function of each audio jack can be defined by software.
  • Page 7: Motherboard Layout

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 1.5 Motherboard Layout Hi-Fi A85S3...
  • Page 8 Motherboard Manual Hi-Fi A75S3/Hi-Fi A55S3 Note1: ■ represents the 1st pin. Note2: HDMI connector is for Hi-Fi A85S3. DVI connector is for Hi-Fi A75S3 & Hi-Fi A55S3. Note3: The USB 3.0 header is only for Hi-Fi A85S3 and Hi-Fi A75S3...
  • Page 9: Chapter 2: Hardware Installation

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 CHAPTER 2: HARDWARE INSTALLATION 2.1 Install Central Processing Unit (CPU) Step 1: Locate the CPU socket on the motherboard Step 2: Pull the socket locking out from the socket and then raise the lever up to a 90-degree angel.
  • Page 10: Install A Heatsink

    Motherboard Manual Step 4: Hold the CPU down firmly, and then close the lever to locked the position 2.2 Install a Heatsink Step 1: Place the heatsink and fan assembly onto the retention frame. Match the heatsink clip with the socket mounting-lug. Hook the spring clip to the mounting-lug.
  • Page 11: Connect Cooling Fans

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 2.3 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 12: Install System Memory

    Motherboard Manual 2.4 Install System Memory A. DDR3 Modules Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. Step 2: Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 13 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 B. Memory Capacity DDR3 Module DIMM Socket Location Total Memory Size DDR3_A1 512MB/1GB/2GB/4GB/8GB/16GB Max is 32GB. DDR3_B1 512MB/1GB/2GB/4GB/8GB/16GB C. Dual Channel Memory Installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table.
  • Page 14: Expansion Slots

    Motherboard Manual 2.5 Expansion Slots PEX16_1: PCI-Express Gen2 x16 Slot PCI-Express 2.0 compliant. Maximum theoretical realized bandwidth of 8GB/s simultaneously per direction, for an aggregate of 16GB/s totally. PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins. PEX1_1: PCI-Express Gen2 x1 Slot PCI-Express 2.0 compliant.
  • Page 15: Jumper Setting

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 2.6 Jumper Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin1-2 closed...
  • Page 16: Headers & Connectors

    Motherboard Manual 2.7 Headers & Connectors ATXPWR1: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V...
  • Page 17 These connectors connect to SATA hard disk drives via SATA cables. Hi-Fi A85S3 & Hi-Fi A75S3 satisfy the SATA 3.0 spec and with transfer rate of 6.0Gb/s. Hi-Fi A55S3 satisfies the SATA 2.0 spec and with transfer rate of 3.0Gb/s.
  • Page 18 SSRX2+ SSRX2- VBUS1 Note: The USB 3.0 header is only for Hi-Fi A85S3 and Hi-Fi A75S3 F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC front panel, and also can be connected with a wide range of simultaneously accessible external Plug and Play peripherals.
  • Page 19 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 F_AUDIO1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC front panel. This header supports HD and AC’97 audio front panel connector. HD Audio AC’97 Assignment Assignment...
  • Page 20 Motherboard Manual J_PRINT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3 Ground Ground Data 4...
  • Page 21: Chapter 3: Uefi Bios & Software

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 CHAPTER 3: UEFI BIOS & SOFTWARE 3.1 UEFI BIOS Setup For better system performance, the UEFI BIOS firmware is being continuously updated. The UEFI BIOS information described below in this manual is for your reference only and the actual UEFI BIOS information...
  • Page 22 Motherboard Manual 6. After the BIOS Update process is finished, click on OK to reboot the system. 7. While the system boots up and the full screen logo shows up, please press <Delete> key to enter BIOS setup. After entering the BIOS setup, please go to the Save & Exit, using the Restore Defaults function to load Optimized Defaults, and select Save Changes and Reset to restart the computer.
  • Page 23 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 2. Online Update Utility 1. Installing BIOS Update Utility from the DVD Driver. 2. Please make sure the system is connected to the internet before using this function. 3. Open BIOS Update Utility and click the Online Update button on the main screen.
  • Page 24 Note2: Shutting down or resetting the system while updating the BIOS will lead to system boot failure. The BIOSTAR BIOS Flasher is built in the BIOS ROM. To enter the utility, press <F12> during the Power-On Self Tests (POST) procedure while booting up.
  • Page 25 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 6. Select the proper BIOS file, and a message asking if you are sure to flash the BIOS file. Click Yes to start updating BIOS. 7. A dialog pops out after BIOS flash is completed, asking you to restart the system.
  • Page 26: Software

    Motherboard Manual 3.3 Software Installing Software 1. Insert the Setup DVD to the optical drive. The driver installation program would appear if the Autorun function has been enabled. 2. Select Software Installation, and then click on the respective software title. 3.
  • Page 27 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 After filling up this information, click “Send” to send the mail out. A warning dialog would appear asking for your confirmation; click “Send” to confirm or “Do Not Send” to cancel. If you want to save this information to a .txt file, click “Save As…” and then you will see a saving dialog appears asking you to enter file name.
  • Page 28 Exit Button: Exit the application Note: 1. Smart EAR is only supported by Windows 7/8 and BIOSTAR Hi-Fi series motherboards. 2. High/Low Gain Switch is only for “Front Panel Audio Header”, please make sure you are connecting your headphone to the front panel I/O.
  • Page 29: Chapter 4: Useful Help

    Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 CHAPTER 4: USEFUL HELP 4.1 Driver Installation After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD The setup guide will auto detect your motherboard and operating system.
  • Page 30: Ami Bios Beep Code

    Motherboard Manual 4.2 AMI BIOS Beep Code Boot Block Beep Codes Number of Beeps Description Continuing Memory sizing error or Memory module not found POST BIOS Beep Codes Number of Beeps Description Success booting. Display memory error (system video adapter) 4.3 Troubleshooting Probable Solution...
  • Page 31 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 32: Raid Functions

    Motherboard Manual 4.4 RAID Functions Operating System Supports Windows Vista , Windows 7 and Windows 8. Raid Arrays RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 33 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array. RAID 1 provides a hot-standby copy of data if the active volume or drive is corrupted or becomes unavailable because of a hardware failure.
  • Page 34 Motherboard Manual RAID 10: RAID 1 drives can be stripped using RAID 0 techniques.Resulting in a RAID 10 solution for improved resiliency, performance and rebuild performance. Features and Benefits Drives: Minimum 4, and maximum is 6 or 8, depending on the platform. ­...
  • Page 35 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.
  • Page 36: Amd Dual Graphics Technology

    Motherboard Manual 4.5 AMD Dual Graphics Technology AMD Dual Graphics Technology Introduction When user adds a PCIE display adapter, it can be integrated with IGD to show better performance. To make the two video devices work simultaneously and normally, please refer to the following setting. AMD Dual Graphics Requirement Operating System: Windows Vista / Windows 7 / Windows 8 Supported Dual Graphics Combinations:...
  • Page 37 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 AMD Dual Graphics Setup Step 1: Insert Dual Graphics-Ready graphics card into PEX16_1 slot. Step 2: Set the BIOS setting as follows: [Chipset]→[North Bridge]→[GFX Configuration] →[Surround View]→[Enabled] Step 3: Install Driver DVD Chipset Driver, and reboot the system. Activate AMD VISION Engine Control Center to make sure CrossFire has been enabled.
  • Page 38: Appendix: Specifications In Other Languages

    – ‫اﻟﻤﻌﺎﻟﺞ‬ ‫اﻟﺤﺪ اﻷﻗﺼﻰ ﻟﻠﻄﺎﻗﺔ اﻟﺤﺮارﻳﺔ ﻓﻲ ﺗﺼﻤﻴﻢ‬ ‫اﻟﻤﻌﺎﻟﺠﺔ‬ ‫ﻟﻘﺎﺋﻤﺔ دﻋﻢ اﻟﻤﻌﺎﻟﺞ‬ www.biostar.com.tw ‫ﻳﺮﺟﻰ اﻟﺮﺟﻮع إﻟﻰ اﻟﻤﻮﻗﻊ‬ ‫اﻟﻤﺮآﺰﻳﺔ‬ AMD A85 FCH (Hi-Fi A85S3) ‫ﻣﺠﻤﻮﻋﺔ‬ AMD A75 FCH (Hi-Fi A75S3) ‫اﻟﺸﺮاﺋﺢ‬ AMD A55 FCH (Hi-Fi A55S3) 1866 1600 1333 1066 DDR3 ‫.
  • Page 39 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 ‫اﻟﻤﻮاﺻﻔﺎت‬ Hi-Fi A55S3 Hi-Fi A75S3 Hi-Fi A85S3 ‫ﺟﻴﺠﺎﺑﺎﻳﺖ‬ x SATA ‫وﺻﻠﺔ‬ ‫ﺟﻴﺠﺎﺑﺎﻳﺖ‬ x SATA ‫وﺻﻠﺔ‬ ‫ﺟﻴﺠﺎﺑﺎﻳﺖ‬ x SATA ‫وﺻﻠﺔ‬ ‫اﻟﺜﺎﻧﻴﺔ‬ ‫ﻟﺜﺎﻧﻴﺔ‬ ‫ا‬ ‫اﻟﺜﺎﻧﻴﺔ‬ ‫ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم‬ ‫ﻣﻮزع‬ ‫ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم‬ ‫ﻣﻮزع‬ ‫ﻧﺎﻗﻞ ﻣﺘﺴﻠﺴﻞ ﻋﺎم‬ ‫ﻣﻮزع‬ ‫دﺑﺎﺑﻴﺲ‬...
  • Page 40: French

    ALC662 Codec audio Canaux 5.1, écoute audio de haute définition, Biostar Hi-Fi AMD A85/A75 FCH Port 6x USB 2.0 (2 sur les I/O arrières et 4 en interne) Port 4x USB 3.0 (2 sur les I/O arrières et 2 en interne) AMD A55 FCH Port 8x USB 2.0 (4 sur les I/O arrières et 4 en interne)
  • Page 41 1x Embase port série Facteur Facteur d'encombrement microATX, 244 mm x 191 mm d'encombrement Windows XP / Vista / 7/ 8 Support SE Biostar se réserve le droit d’ajouter ou d'enlever le support pour toute SE avec ou sans préavis.
  • Page 42: German

    CPU-Unterstütz Maximale CPU TDP (Thermal Design Power): 100 Watt www.biostar.com.tw * Bitte konsultieren Sie für CPU-Unterstützungsliste AMD A85 FCH (Hi-Fi A85S3) Chipset AMD A75 FCH (Hi-Fi A75S3) AMD A55 FCH (Hi-Fi A55S3) Unterstützt zweikanaliges DDR3 800/ 1066/ 1333/ 1600/ 1866 2 x DDR3 DIMM-SpeicherSlot, Max.
  • Page 43 1x Header für Druckerport 1x Serieller Port-Header 1x Serieller Port-Header Formfaktor microATX Formfaktor, 244 mm x 191 mm Windows XP / Vista / 7/ 8 OS-Unterstützu Biostar reserves the right to add or remove support for any OS with or without notice.
  • Page 44: Italian

    10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo ALC662 Codec Audio Canali Audio di Alta Definizione 5.1, Biostar Hi-Fi Piattaforma AMD A85/A75 FCH: Slot 6x USB 2.0 (2 nei ingressi/ uscite posteriore e 4 da distributori interni) Slot 4x USB 3.0 (2 nei ingressi/ uscite posteriore e 2 da distributori interni)
  • Page 45 Distributore Slot Serie x1 Fattore di Forma Fattore di Forma microATX, 244 mm x 191 mm Windows XP / Vista / 7/ 8 Supporto SO Biostar si riserva il diritto di aggiungere o ritirare il supporto per qualsiasi SO con o senza preavviso.
  • Page 46: Japanese

    10/ 100/ 1000 Mb/s オートネゴーシエーション、半/全 二重通信 ALC662 オーディオ コーデ ック 5.1 チャンネル, ハイ デフィニション オーディオ, Biostar Hi-Fi AMD A85/A75 FCH: 6x USB 2.0 ポート (後部 I/O に2つ 及び 内蔵ヘッダー経由に4つ) 4x USB 3.0 ポート (後部 I/O に2つ 及び 内蔵ヘッダー経由に2つ) AMD A55 FCH: 8x USB 2.0 ポート...
  • Page 47 Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3 仕様 Hi-Fi A85S3: Hi-Fi A75S3: Hi-Fi A55S3: 6x SATA 6.0Gb/s コネクタ 6x SATA 6.0Gb/s コネクタ 6x SATA 3.0Gb/s コネクタ 2x USB 2.0 ヘッダー 2x USB 2.0 ヘッダー 2x USB 2.0 ヘッダー 1x USB 3.0 ヘッダー 1x USB 3.0 ヘッダー...
  • Page 48: Polish

    10/ 100/ 1000 Mb auto negocjacja, pojemność dupleks Połowe / Pełny ALC662 Codec Audio Kanały Audio wysokiej Definicji 5.1, Biostar Hi-Fi Płyta AMD A85/A75 FCH: 6 x złącza USB 2.0 (2 przez tylne porty wejścia/ wyjścia oraz 4 przez wewnętrzne porty) 4 x złącza USB 3.0 (2 przez tylne porty wejścia/ wyjścia oraz 2 przez wewnętrzne porty)
  • Page 49 Złącze port drukarki x1 Port szeregowy x1 Port szeregowy x1 Obudowa Obudowa microATX, 244 mm x 191 mm Windows XP / Vista / 7/ 8 Obsługa OS Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z wypowiedzeniem lub bez wypowiedzenia.
  • Page 50: Portuguese

    10/ 100/ 1000 Mb auto negociação, capacidade duplex Metade / Cheio ALC662 Codec de Audio Canais de Áudio de Alta Definição 5.1, Biostar Hi-Fi Plataforma AMD A85/A75 FCH: Porta 6x USB 2.0 (2 nas entradas/saídas traseiras e 4 pelos Dispositivos internos) Porta 4x USB 3.0 (2 nas entradas/saídas traseiras e 2 pelos Dispositivos internos)
  • Page 51 Dispositivo Porta Série x1 Fator de Fôrma Fator de Fôrma microATX, 244 mm x 191 mm Windows XP / Vista / 7/ 8 Suporte OS Biostar reserva seu direito de adicionar ou retirar o suporte para qualquer OS com ou sem notificação.
  • Page 52: Russian

    центрального Максимальный термопакет центрального процессора (TDP): 100 ватт www.biostar.com.tw процессора * Перечень поддержки центрального процессора смотрите на AMD A85 FCH (Hi-Fi A85S3) Набор AMD A75 FCH (Hi-Fi A75S3) микросхем AMD A55 FCH (Hi-Fi A55S3) Поддерживает двухканальный DDR3 800/ 1066/ 1333/ 1600/ 1866 2 гнезда...
  • Page 53 1 контакт последовательного 1 контакт последовательного порта порта Конструктив Форм-фактор microATX, 244 мм x 191 мм Windows XP / Vista / 7/ 8 Поддержка ОС Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с уведомлением или без.
  • Page 54: Spanish

    10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo ALC662 Códec Audio Canales Audio de Alta Definición 5.1, Biostar Hi-Fi Plataforma AMD A85/A75 FCH: Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores internos) Ranura 4x USB 3.0 (2 en las entradas/salidas posteriores y 2 por los distribuidores internos) Plataforma AMD A55 FCH: Ranura 8x USB 2.0 (4 en las entradas/salidas posteriores y 4 por los distribuidores internos)
  • Page 55 Distribuidor Ranura Serie x1 Factor de Forma Factor de Forma microATX, 244 mm x 191 mm Windows XP / Vista / 7/ 8 Soporte OS Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin notificación. 2012/12/12...
