OMNI Test Laboratories
SAVE THIS BOOK
This book is valuable. In addition to instruct-
ing you on how to install and maintain your
fireplace, it also contains information that will
enable you to obtain replacement parts or
optional accessory items when needed. Keep
it with your other important papers.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
Check local codes before installing this
fireplace.
Model (V)3612ST
Save this manual for future reference.
Save this manual for future reference.
SEE-THRU WOOD
BURNING FIREPLACE
INSTALLATION AND OPERATING
INSTRUCTIONS
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage, or loss
of life. Refer to this manual for correct instal-
lation and operational procedures. For as-
sistance or additional information consult a
qualified installer, service agency, or the
gas supplier.
WARNING: This fireplace is intended for use
with wood, or if a decorative gas appliance is
installed, burn propane or natural gas only.
WARNING: Always leave glass doors fully
opened or fully closed when operating the
appliance.
