Desa Victorian VV36EN Series Owner's Operation And Installation Manual

Desa direct-vent fireplace owner's operation and installation manual (v)v36en, (v)v42en, (v)v36ep, (v)v42ep
Hide thumbs Also See for Victorian VV36EN Series:

Advertisement

Quick Links

For more information, visit www.desatech.com
For more information, visit www.desatech.com
NATURAL GAS "VICTORIAN" MODEL (V)V36EN,
PROPANE/LP GAS "VICTORIAN" MODEL (V)V36EP,
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not
prohibited by state or local codes.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
(V)V42EN SERIES
(V)V42EP SERIES
Save this manual for future reference.
Save this manual for future reference.
DIRECT-VENT FIREPLACE
OWNER'S OPERATION AND
TM
INSTALLATION MANUAL
WARNING: Improper installation, ad-
justment, alteration, service, or mainte-
nance can cause injury or property
damage. Refer to this manual for cor-
rect installation and operational proce-
dures. For assistance or additional in-
formation consult a qualified installer,
service agency, or the gas supplier.
— Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
— This appliance is only for use with
the type of gas indicated on the rating
plate. This appliance is not convertible
for use with other gases, unless a
certified kit is used.
