Wall Mantel with Base and Trim
ASSEMBLY AND INSTALLATION INSTRUCTIONS
Important: Read entire instruction sheet before as-
sembling or installing mantel kit.
This mantel is only approved for use with any DESA
Heating Products 26" fireplace system. Do not use mantel
with any other product.
• Mantel pieces - unassembled and marked as follows:
Base #1
Right Side #2 with arrow
Right Front Leg #3 with arrow Top #7
Left Side #4 with arrow
• Hardware package
• Trim kit
• Trim kit hardware
• Bracket hardware kit
The hardware package 117197-03 contains the following:
• 2 - 3" screws
• 18 - 1
⁄
" screws
1
4
The bracket hardware kit 118983-01 contains the following:
• 13 - Brackets
• 2 - Flat brackets
• 36 - Wood screws
WS26CP and WD26CPA
Left Front Leg #5 with arrow
Header #6 with arrow
117197-03
GAB6094
102866-01
118983-01
www.desatech.com
Tools and items required:
• #2 Phillips driver bit (3
• Slotted screw driver
• Measuring tape
• Pencil
• Drill Driver
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement.
If hardware or trim is missing or damaged, contact DESA
Heating Products at 1-866-672-6040 for referral and war-
ranty information. You can also visit DESA Heating Products'
technical service web site at www.desatech.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
to assemble mantel. Damage to mantel will result if
other screws are used for this purpose.
WARNING: Use only 1/2" or 3/4" screws with brack-
ets in hardware pack 118983-01. Damage to mantel will
result if other screws are used for this purpose.
/
" minimum length)
1
2
/
" screws in pocket holes
1
4
Advertisement
Related Manuals for Desa Wall Mantel with Base and Trim WD26CPA
Summary of Contents for Desa Wall Mantel with Base and Trim WD26CPA
-
Page 1: Assembly And Installation Instructions
ASSEMBLY AND INSTALLATION INSTRUCTIONS Important: Read entire instruction sheet before as- sembling or installing mantel kit. This mantel is only approved for use with any DESA Heating Products 26" fireplace system. Do not use mantel with any other product. • Mantel pieces - unassembled and marked as follows:... -
Page 2: Assembling Mantel
ASSEMblING MANTEl Important: More than one person is required to lift assembled mantel. lift mantel by leg assemblies. lifting by header or mantel top could damage mantel. 1. Lay right front leg (#3) on floor. Position right side (#2) as shown in Figure 1. Align predrilled screw holes in front leg and side. Make sure ends are flush. Attach with two or three 1 " wood screws, depending on your model. Repeat for other leg using #4 and #5. 2. Each leg assembly will use 3 brackets for stability. Your bracket hardware kit will contain either 1/2" or 3/4" screws. Using two 1/2" or 3/4" screws, install a bracket in the center of each leg assembly and one at each end within 1" of but not over the last pocket hole (see Figure 2). 3. Place header (#6) between right and left leg assemblies (see Figure 3). The top of header must be flush with top of side leg assemblies. Attach header using 1... - Page 3 8. Place mantel assembly onto mantel base and center left to right with back of assembly flush with back of base (see Figure 7, page 3). Use 1 holes to attach mantel assembly to mantel base. Using brackets and 1/2" or 3/4" screws from this hardware kit (118983-01) attach support brackets to base and mantel assembly - one at each back corner of the leg sides and one on each leg front (see Figure 7). Leg Assembly Figure 5 - placing mantel assembly onto mantel top 1/2" or 3/4" Screw Figure 6 - adding Brackets to mantel top 119793-01B " screws in pocket "...
